Need the factory operator instructions for your International Harvester 574 Tractor? All 122 pages of this IH 574 Operator Manual (OEM #1084039R1) cover both the C-200 gasoline and D-239 diesel variants in factory detail. Open to a full section on instruments and controls: every gauge, warning light, lever, and pedal explained before you ever turn the key. You also get the complete three-point hitch operating procedure, PTO hookup, auxiliary valve connections, and detailed hydraulic power steering operation, plus a structured troubleshooting section covering hard starts, low power, overheating, and oil pressure loss across both engine types. Your preventive maintenance schedule runs four tiers: the first 10 hours, every 100 hours, every 200 hours, and a 1,000-hour full-service interval, all charted in the lubrication guide. Your machine is not supposed to sit in the field waiting on a forum post. Search any spec by keyword, jump to any section, open on any device.
What's Inside This International Harvester 574 Tractor, International 574 Tractor, C-200, D-239 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction | 9 | Left Side View, Terms of Location, Optional Equipment |
| Safety Suggestions | 10 | - |
| Instruments and Controls | 11 | Gauges, Levers, Pedals, Switches, Warning Lights |
| Before Operating Your New Tractor | 12 | Tractor Break-In Procedure, Lubrication, Pneumatic Tires, Engine Cooling System, Fuel System, Instrument and Controls |
| Driving the Tractor | 13-19 | Adjusting the Deluxe Cushion Seat and Suspension Seat, Transmission Range and Speed Levers, Stopping the Tractor, Using the Brakes |
| Gasoline Engine and Fuel System | 20-23 | Fuel System, Starting the Engine, Engine Oil Pressure Gauge, Stopping the Engine, Carburetor, Solenoid Fuel Shut-Off Valve |
| Diesel Engine and Fuel System | 24-31 | Starting the Engine, Changing the Ether Fluid Container, Fuel Filters |
| Basic Hydraulic System with Power Steering | 32 | Hydraulic Power, Filter and Relief Valve, Flow Divider Valve, Auxiliary Valve, Steering Wheel Rotation, Manual Steering |
| Hydraulic Controls for Three-Point Hitch | 33-35 | Position Control Lever (Inside Lever), Draft Control (Outside Lever) |
| Three-Point Hitch | 36-41 | Lift Links and Leveling Crank, Coupling the Equipment, Example of Operating the Three-Point Hitch with Draft Control |
| Auxiliary Valves and Remote Cylinders | 42-44 | Connecting Hoses to Junction Ports on Valves, Operating Double-Action Cylinders |
| Hitching Trailing Equipment to the Tractor | 45-47 | Swinging Drawbar, Power Take-Off |
| Cooling System | 50-52 | Adding Water, Heat Indicator, Cleaning, Rust Prevention, Belt Tension, Water Pump |
| Air Cleaning System | 53-55 | Dry-Type Air Cleaner, Automatic Dust Unloader, Filter Element Removal, Filter Element Cleaning, Crankcase Breather, Inspection |
| Electrical System | 56-61 | Ignition System (Gasoline Engine Only), Lighting System, Battery |
| Minor Engine Service Operations | 62-66 | Valve Clearance Adjustment, Transmission and Speed Range Lever Linkage Adjustment, Governor Linkage Adjustments |
| Rear Wheels | 68-72 | Rear Wheel Hubs and Studs, Power Adjusted Rear Wheels, Assembling the Rear Wheel Double-Bead Rims |
| Weights | 73-75 | Rear Wheel Weights (Two-Piece) |
| Pneumatic Tires | 76-77 | Load Capacity, Front Tires, Rear Tires, Inflation, Traction and Weights, Tire Chains |
| Clutches (Synchromesh Transmission) | 80 | Engine Clutch, Clutch Pedal Travel, Clutch Release Bearing, Clutch Release Shaft |
| Storing the Tractor | 81 | Diesel Engine, Gasoline Engines, Removing From Storage, Cold Weather Precautions |
| Cold Weather Precautions | 82-83 | Lubrication, Fuel System, Cooling System, Antifreeze Solutions |
| Trouble Shooting | 84-92 | Hard to Start, Engine Operates Irregularly or Knocks, Lack of Power, Engine Overheats, No Oil Pressure, Oil Dilution or Uses Too Much Oil, Using Too Much Fuel |
| Lubrication | 93-96 | Hydraulic Fluid Filter |
| Lubrication Table | 97 | Point of Lubrication, Capacity, Anticipated Temperatures, Lubricant, Alternator-Generator, Lubrication Fittings |
| Lubrication Guide | 98-101 | Daily or After Every 10 Hours of Operation, After Every 100 Hours of Operation, After Every 200 Hours of Operation, Synchromesh Transmission |
| Preventive Maintenance Guide | 102-105 | After the First 10 Hours of Operation, After Every 100 Hours of Operation, After Every 200 Hours of Operation, Periodic or After Every 1000 Hours of Operation |
| Specifications | 106-109 | Ground Speeds, Miles per Hour, Capacities (U. S. Measure - Approximate), Front Wheels and Tread |
| Optional Equipment | 110 | Auxiliary Hydraulic Valves and Manifold, Independent Power Take-Off, Differential Lock, Swinging Drawbar, Front End Weights, Wheel Weights |
