Part of the New Holland Repair Manuals.
This is the full factory repair manual for the Ford New Holland 455C, 555C and 655C tractor loader backhoes, the same service information a dealer technician works from. It covers the whole machine: the 3-cylinder diesel in the 455C and the 4-cylinder diesel (naturally aspirated and turbocharged) in the 555C and 655C, the cooling and lubrication systems, the fuel system, the clutch and transmission, the front axle and four-wheel drive, the steering, the rear axle, differential and brakes, the loader, the backhoe and their hydraulic systems, and the full electrical section with the wiring diagrams. Every section carries the specifications and clearances, the functional adjustments, the fault finding and the step-by-step removal, overhaul and installation procedures, so you can chase a hydraulic, transmission or engine problem and put it right instead of guessing.
What's Inside This Ford New Holland Ford New Holland 455C 555C 655C Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction, Specifications and Special Tools | General Service Instructions, Safety Precautions, Machine Specifications and Capacities, Standard Torque Values, Special Tools, Model Coverage 455C 555C 655C | |
| Diesel Engine | 3-Cylinder Diesel (455C) and 4-Cylinder Diesel (555C, 655C, Turbocharged) Description and Operation, Cylinder Head and Valves, Pistons and Connecting Rods, Crankshaft and Main Bearings, Camshaft, Timing Gears and Backlash, Engine Overhaul and Clearances | |
| Cooling and Lubrication | Cooling System Description, Radiator, Thermostat and Water Pump, Coolant Draining and Refill, Oil Pump and Oil Pan Sump, Oil Flow and Pressure, Filters and Service | |
| Fuel System | Diesel Fuel Injection Description, Injection Pump and Drive Gear Timing, Injectors and Nozzles, Fuel Lift Pump, Filters and Bleeding, Fuel Tank, Throttle Linkage, Fault Diagnosis | |
| Clutch and Transmission | Clutch, Transmission Power Flows and Lubrication Oil Flow, Synchroniser, Oil Cooler and Transmission Cooling, Gear Selection, Description and Operation, Fault Diagnosis, Overhaul | |
| Front Axle, Four-Wheel Drive and Steering | Four-Wheel Drive Front Axle, Planetary Reduction and Wheel Hubs, Axle Shaft, Differential Crown Wheel and Pinion, Drive Shaft, Steering Swivel Pin Bearings, Steering Cylinder and Track Rods, Hydrostatic Steering, Overhaul | |
| Rear Axle, Differential and Brakes | Rear Axle Housing, Differential and Final Drive, Rear Wheel Hubs, Service Brakes and Parking Brake, Brake Adjustment and Bleeding, Description, Fault Diagnosis, Overhaul | |
| Hydraulic System | Main Hydraulic Pump, Control Valves and Relief Settings, Oil Flow and Circuits, Pressure Testing, Hydraulic Reservoir and Filters, Fault Diagnosis, Overhaul | |
| Loader | Front Loader Frame and Mounting, Boom and Bucket Cylinders, Loader Control Valve and Linkage, Lift and Crowd Circuits, Adjustment, Seal Replacement, Overhaul | |
| Backhoe | Backhoe Frame, Controls and Mounting, Boom, Dipper and Bucket Cylinders, Swing and Stabiliser Cylinders, Backhoe Control Valve, Circuit Operation, Adjustment, Overhaul | |
| Electrical System | Wiring Diagrams, Starting and Charging Systems, Battery, Alternator and Starter Motor, Lighting, Gauges and Warning Devices, Switches and Sensors, Fault Diagnosis |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| 455C | ||
| Engine - 455C | 3-cylinder diesel | |
| 555C, 655C | ||
| Engine - 555C / 655C | 4-cylinder diesel (naturally aspirated or turbocharged) | |
| All models | ||
| Machine Configuration | Tractor loader backhoe (loader front, backhoe rear) | |
| Drive | Two-wheel drive or four-wheel drive front axle | |
| Oversize Pistons Available | 0.010 in (0.25 mm) and 0.020 in (0.51 mm) | |
Ford New Holland Ford New Holland 455C 555C 655C Common Problems This Manual Covers
Backhoe or loader moves slowly or lacks digging and lifting force.
The Hydraulic System section covers the pump output, the control-valve relief settings and the circuit pressures with the pressure-testing procedure to find whether the pump, a relief valve or a leaking cylinder is causing the slow or weak movement.
Manual Section: Hydraulic SystemTransmission slips or loses power in forward or reverse.
The Clutch and Transmission section covers the clutch, the transmission power flows and lubrication oil flow, the synchroniser and the oil cooler, with the description, fault diagnosis and step-by-step overhaul to trace and correct slipping, harsh shifts and lost drive in forward or reverse.
Manual Section: Clutch and TransmissionEngine runs rough, smokes or loses power.
The Diesel Engine and Fuel System sections cover the injection pump timing, the injectors and the compression and valve condition with the diagnosis and overhaul to cure rough running, smoke and power loss.
Manual Section: Diesel EngineSteering is stiff, heavy or unresponsive.
The Front Axle, Four-Wheel Drive and Steering section covers the hydrostatic steering circuit, the steering cylinder seals and the track rods with the checks and overhaul to restore normal steering.
Manual Section: Front Axle, Four-Wheel Drive and SteeringFrequently Asked Questions
The backhoe or loader is slow or weak - what does the manual cover?
The Hydraulic System, Loader and Backhoe sections cover the main pump, the control valves and relief settings, and the boom, dipper, bucket, swing and stabiliser cylinders, with the pressure testing, seal replacement and overhaul to fix slow or weak movement.
The transmission slips or loses drive - is that in the manual?
Yes. The Clutch and Transmission section covers the clutch, the transmission power flows, the synchroniser and the oil cooler, with the description, fault diagnosis and overhaul to trace slipping or lost drive on the 455C, 555C or 655C.
Does this manual give the engine clearances and overhaul procedures?
Yes. The Diesel Engine section covers both the 3-cylinder engine in the 455C and the 4-cylinder engine in the 555C and 655C, with cylinder head, pistons, crankshaft, camshaft and timing-gear procedures, the clearances and the oversize part sizes for a full overhaul.
Steering has gone stiff or unresponsive - what should I check?
The Front Axle, Four-Wheel Drive and Steering section covers the hydrostatic steering, the steering cylinder and track rods and the swivel pin bearings, with the checks and overhaul for stiff or unresponsive steering.
Which models does this manual cover and does it include wiring diagrams?
It covers the Ford New Holland 455C, 555C and 655C tractor loader backhoes and includes the full Electrical System section with the wiring diagrams, starting and charging systems and fault diagnosis.
Is this Ford New Holland 455C, 555C, 655C Repair Manual a digital download?
A 1087-page Repair Manual in searchable PDF format (292 MB), available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Can I print this Ford New Holland 455C, 555C, 655C manual?
No restrictions at all. Print individual pages, full chapters, or the entire manual. The PDF is completely unlocked.
