Case 480C 480CK Parts Manual [Tractor Loader Backhoe]

$6.95

Availability: Instant Download
Requirements: Adobe Reader
Size: 22.568 Mb
Language: English
Format: PDF

Category: Tags: ,

Complete Service Parts Manual For Case IH International Case 480C 480CK Tractor Loader Backhoe. Manual Include detailed illustrations, exploded views, part number identification. Help to understand how to Repair Overhaul Disassembly and Assembly Replacement and Change Servicing Rebuilding your Case.

= Clickable index
= Bookmarks
= Searchable Text
= Printable
= Zoomable

MODELS Covered

JI Case IH International Tractor

Case 480C

Case 480CK

1976 1977 1978 1979 1980

SECTIONS covered

General
Revision Record Log
Section Index
Location Of Serial Numbers
General Information
Parts Information Multi-Language
Dealers Owners Record

Engine
Radiator, Fan 8C Mounting Parts
Muffler 8C Exhaust System
Air Cleaner 8C Air Intake Parts
Pre-Cleaners
Cold Start System
Intake Mainfield, 188 Diesel Engine, With Sealing Washers
Exhaust Manifold, 188 Diesel Engine
Water Pump & Thermostat, 188 Diesel Engine
Timing Gear Cover, 188 Diesel Engine
Oil Filter, 188 Diesel Engine, Float Type
Oil Filter, 188 Diesel Engine, Fixed Screen Type
Cylinder Head 8C Cover, 188 Diesel Engine
Valve Mechanism, 188 Diesel Engine
Cylinder Block, 188 Diesel Engine, Prior To Engine Serial Number 2836084, Mechanical Shuttle Only
Cylinder Block, 188 Diesel Engine, Engine Serial Number 2836084 8C After
Camshaft, 188 Diesel Engine, Used Engine Serial Number 2850355 8C After
Crankshaft, 188 Diesel Engine
Pistons, 188 Diesel Engine, Prior To Engine Serial Number 2836084
Pistons, 188 Diesel Engine, Used Engine Serial Number 2836084 8C After
Engine Gasket Kits, 188 Diesel Engine, Valve Grind Kit
Engine Mounting

Fuel System
Fuel Tank 8C Fuel Lines
Throttle Control Linkage 8C Fuel Shut-Off Cable
Fuel Injection 8C Filter System, 188 Diesel Engine
Fuel Filter, 188 Diesel Engine
Injection Pumps, 188 Diesel Engine
Injection Pump Drive, 188 Diesel Engine
Injection Nozzles, 188 Diesel Engine, Used Engine Serial Number 2835235 And After

Electrical
L102693 Alternator, Delco-Remy Number 1103125, Uses Metric Hardware, 188 Diesel Engine
D77810 Alternator, Delco-Remy Number 1102927, Uses U.S. Standard Hardware, 188 Diesel Engine
A135714 Alternator, Delco-Remy Number 1102886, 188 Diesel Engine
R29870 Starter, Delco-Remy, 188 Diesel Engine
Starter 8C Alternator Mounting
Electrical Circuit, Front Harness, Alternator, Starter And Battery
Electrical Circuit, Main Harness And Instrument Panel, Before Tractor Serial Number 8967053
Electrical Circuit, Main Harness And Connections, Tractor Serial Number 8967053 And After
Instrument Panel 8C Covers, Tractor Serial Number 8967053 And After
Electrical Circuit, Main Harness 8C Connections, Models W_ Flasher Lamps, Before Tractor S_N 8967053
Electrical Circuit, Main Harness 8C Connections, Models W_ Flasher Lamps, Trac. S_N 8967053 And After
Power Shuttle Electrical Circuit
Instrument Cluster
Hourmeter Electrical System
Canopy Electrical System 8C Lamps
Cab Electrical System 8C Lamps
Electrical System 8C Lamps Without Canopy Or Cab
Tractor Lamps, D49733 Stop And Tail Lamp
Tractor Lamps, D88684 Rear Flood Lamp
Cab Heater Lines 8C Defroster, Before Tractor Serial Number 8967053
Cab Heater Lines 8C Defroster, Tractor Serial Number 8967053 And After
Cab Heater 8C Defroster
Window Defroster Fan, With Four Bolt Base
Window Defroster Fan, With Three Bolt Base
Front 8C Rear Windshield Wipers
Windshield Wiper Motors, Front Windshield Wiper Motor Only
Rotating Beacon 8C Circuit, Before Tractor Serial Number 8967053
Rotating Beacon 8C Circuit, Tractor Serial Number 8967053 And After
Rotating Beacon
Electric Horn
Backup Alarm
Dipper Lamp, Used With Non-Extendable Dipper
Dipper Lamp, Used With Extendable Dipper

Steering
Steering Wheel 8C Steering Column
Steering Hydraulic Circuit, Steering Pump To Control Valve
Steering Hydraulic Circuit, Control Valve To Cylinders
Power Steering Pump
Steering Column And Control Valve
A137503 Steering Cylinders, With Single Groove Piston
D128454 Steering Cylinders, With Double Groove Piston
Front Axle And Spindles
Rear Wheels & Tires, 13.6 X 24 And 14.9 X 24 Fixed Disc Wheel
Front Wheel Hub And Bearings
Front Wheels 8C Tires, 6.50 X 16, 7.50 X 16 And 8.00 X 16 Tires
Rear Wheels 8C Tires, 13.6 X 24 And 14.9 X 24 Fixed Disc Wheel.

Power Train
Torque Converter & Housing
Power Shuttle Cooling System
Power Shuttle, Housing, Pinion Cage, And Output Shaft
Power Shuttle, Housing & Oil Pan
Power Shuttle, Input Shaft 8C Forward Clutch
Power Shuttle, Charging Pump 8C Reverse Clutch
Clutch, Mechanical Shuttle 8C Related Parts
Clutch Housing, Two Speed Mechanical Shuttle
Shuttle Housing, Two Speed Mechanical Shuttle
Shuttle Input Gear, Two Speed Mechanical Shuttle
Shuttle Countershaft, Two Speed Mechanical Shuttle
Range Output Shaft, Two Speed Mechanical Shuttle
Clutch Pedal 8C Linkage
Shuttle Control, Power Shuttle Models Only
Shuttle Control, Mechanical Shuttle Models Only
Drive Shafts, Before Tractor Serial Number 8956868
Transaxle 8C Differential Lock
Transmission Housing, Transaxle
Shifter Mechanism, Transaxle
Main Shaft, Transaxle
Countershaft, Transaxle
Differential, Transaxle, Mechanical Shuttle
Differential, Transaxle, Power Shuttle
Differential Lock, Transaxle
Rear Axle, Transaxle

Breakes
Differential Brake Housing & Brake, Transaxle
Differential Brake Lever 8C Lock, Transaxle
Brake Pedals 8C Brake System, Power Shuttle Models Only
Brake Pedals 8C Brake System, Mechanical Shuttle Models Only
Brake Master Cylinder
Parking Brake

Hydraulics
Equipment Hydraulic Circuit, Reservoir To Loader Valve
Equipment Hydraulic Circuit, Rear Equipment And Return Lines
Equipment Hydraulic Circuit, Special Parts Used Without Loader Or With Pto
Loader Lift Cylinder Hydraulic Circuit, Before Tractor Serial Number 8968653
Loader Lift Cylinder Hydraulic Circuit, Tractor Serial Number 8968653 And After
Loader Bucket Cylinder Hydraulic Circuit
Backhoe Swing 8C Stabilizer Cylinder, Hydraulic Circuit
Backhoe Boom Cylinder Hydraulic Circuit
Backhoe Dipper Cylinder Hydraulic Circuit
Backhoe Bucket Cylinder Hydraulic Circuit
Backhoe Extendable Dipper Hydraulic Circuit, Backhoe Valve To Couplings
Backhoe Extendable Dipper Hydraulic Circuit, Couplings To Dipper Extension Cylinder
Boom Lock Hydraulic Circuit
Three-Point Hitch Valve Hydraulic Circuit
Three-Point Hitch Cylinder Hydraulic Circuit
Three-Point Hitch Anti-Leakdown Kit
Pto Hydraulic Cooling System, Before Tractor Serial Number 8967327
Pto Hydraulic Cooling System, Tractor Serial Number 8967327 And After
Pto Hydraulic Circuit And Control
Pto Motor 8C Motor Housing
Pto Shield 8C Speed Indicator
D58538 Dana Hydraulic Pump
D48950 Cessna Hydraulic Pump
D49241 8C D80083 Trw Hydraulic Pumps
D73079 Warner Hydraulic Pump

Chassis Attachments
Gresen…Loader Control Valve, Usedon Models .With Dual Co
Parker Loader Control Valve, Used On Models With Single Control Lever
Parker Loader Control Valve, Loader Lift Spool
Parker Loader Control Valve, Loader Bucket Spool
Parker Loader Control Valve, Main Relief Valve
Parker Loader Control Valve, Load Check Valve
Backhoe Control Valve, Used With Single Lever Control
Backhoe Control Valve, Outlet Section
Backhoe Control Valve, Stabilizer Section
Backhoe Control Valve, Bucket And Dipper Sections
Backhoe Control Valve, Swing Section
Backhoe Control Valve, Boom Section
Boom Lock Valve
Relief Valve 8C Mounting Plate, Models Without Loader
D71668 8C D75308 Relief Valves
Three-Point Hitch Control Valve
Three-Point Hitch Control Valve, Inlet Section
Three-Point Hitch Control Valve, Lift Section
Three-Point Hitch Control Valve, Pitch, Tilt 8C Implement Sections
Extendable Dipper Control Valve
Pto Selector Valve
D71952 Pto Hydraulic Motor
D90093 Pto Hydraulic Motor
D73910 8C D84789 Hydraulic Oil Filters
Hydraulic Quick Disconnect Couplings
G35002 8C G35003 Loader Lift Cylinders, With Two Piece Piston
G101206 8C G101207 Loader Lift Cylinders, With One Piece Piston
G100859 8C G100860 Loader Bucket Cylinders, With Two Piece Piston
G101208 8C G101209 Loader Bucket Cylinders, With One Piece Piston
G33552 Backhoe Stabilizer Cylinders, Models Without Extendable Dipper, With Two Piece Piston
G101200 Backhoe Stabilizer Cylinders, Models Without Extendable Dipper, With One Piece Piston
G35007 Backhoe Stabilizer Cylinder, Models With Extendable Dipper, With Two Piece Piston
G101204 8C G102294 Backhoe Stabilizer Cylinders, Models W_ Extendable Dipper, W_ One Piece Piston
G100073 Backhoe Swing Cylinders, With Two Piece Piston
G101285 8C G104127 Backhoe Swing Cylinders, With One Piece Piston
G33209 Backhoe Boom Cylinder, With Two Piece Piston
G101198 Backhoe Boom Cylinder, With One Piece Piston
G33596 Backhoe Dipper Cylinder, With Two Piece Piston
G101202 Backhoe Dipper Cylinder, With One Piece Piston
G33291 Backhoe Bucket Cylinder, With Two Piece Piston
G101199 Backhoe Bucket Cylinder, With One Piece Piston
G33204 Backhoe Dipper Extension Cylinder, With Two Piece Piston
G101203 Backhoe Dipper Extension Cylinder, With One Piece Piston
G33456 Three-Point Hitch Lift Cylinder, With Two Piece Piston
G101189 Three-Point Hitch Lift Cylinder, With One Piece Piston
G33351 Three-Point Hitch Tilt Cylinder, With Two Piece Piston
G101188 Three-Point Hitch Tilt Cylinder, With One Piece Piston
G33128 Three-Point Hitch Pitch Cylinder
Loader Controls, Dual Control Levers, Used With Gresen Loader Control Valve
Loader Controls, Single Control Lever, Used With Parker Loader Control Valve
Loader Lift Frame & Related Parts
Loader Buckets
Loader Blade
Front Counterweight
Rear Counterweight
Backhoe Mounting Frame
Backhoe Stabilizers
Backhoe Swing Tower 8C Boom
Backhoe Dipper 8C Bucket
Backhoe Extendable Dipper
Backhoe Buckets, Trenching Buckets
Backhoe Buckets, Bellhole Buckets
Backhoe Control Tower With Foot Swing, Console And Pedal Guards
Backhoe Controls With Foot Swing, Control Levers And Linkage
Backhoe Controls Tower With Hand Swing, Console
Backhoe Controls With Hand Swing, Control Levers And Linkage
Extendable Dipper Controls
Three-Point Hitch Controls
Three-Point Hitch Frame And Attaching Parts
Three-Point Hitch Draft Arm, Linkage And Cylinders
Swinging Drawbar
Chassis
Fenders, Step 8C Tool Box
Battery Compartment 8C Valve Mounting Plate
Floor Plates 8C Firewall
Seat Mounting Parts 8C Seat Belts
Seat 8C Armrests
D58296 Seat
Hood 8C Radiator Shroud
Engine Side Panels
Noise Reduction Pads
Cab 8C Mounting Parts
Rear Closure Panels
Cab Frame 8C Rear Window
Cab Doors, Windows 8C Related Parts
Cab Glass 8C Molding
Rops Canopy
Slow Moving Vehicle Emblem, Used On Models With Backhoe
Decals, Before Serial Number 8980751, Basic Tractor
Decals, Before Serial Number 8980751, Equipment
Decals, Serial Number 8980751 And After
