Part of the Case Operator Manuals.
This is the complete factory repair and operator's manual set for the Case 570LXT Series 2 loader landscaper. It is organized into the standard Case service groups and covers the machine from the diesel engine and radiator, through the electrical system with the Denso starter, batteries, instrument cluster, and alternator, the two- and four-wheel-drive steering with its specifications, pressure checks, control valve, and cylinders, the power train with the Carraro transmission, the rear axle and planetaries, and the wheels and tires, the brakes, and the full loader hydraulics with the loader control valve, three-point hitch control valve, auxiliary control valve, and the optional ride control accumulator and solenoid. It carries standard torque specifications, fluids and lubricants, specifications, pressure checks, troubleshooting, and step-by-step removal and installation, alongside the R-134a air conditioning service and the operator's manual for day-to-day running and maintenance.
What's Inside This Case 570LXT Series 2 Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| General | Standard Torque Specifications, Fluids and Lubricants | |
| Engine | Engine and Radiator Removal and Installation | |
| Electrical | Removal and Installation of Electrical Components, Electrical Specifications and Troubleshooting, Batteries, Starter Motor (Denso), Instrument Cluster, Alternator | |
| Steering | Removal and Installation of Steering Components, Steering Specifications Pressure Checks and Troubleshooting, Steering Control Valve, Steering Cylinders, Front Axle Two Wheel Drive, Front Axle Four Wheel Drive | |
| Power Train | Removal and Installation of Power Train Components, Standard Transmission Specifications Pressure Checks and Troubleshooting, Wheels and Tires, Rear Axle and Planetaries, Standard Carraro Transmission | |
| Brakes | Removal and Installation of Brake Components, Master Cylinder, Parking Brake and Pedal Adjustments | |
| Hydraulics | Removal and Installation of Hydraulic Components, Hydraulic Specifications Troubleshooting and Pressure Checks, Cleaning the Hydraulic System, Hydraulic Pump, Loader Control Valve, Cylinders, Three Point Hitch Control Valve, Auxiliary Control Valve, Accumulator and Solenoid Valve for Optional Ride Control | |
| Mounted Equipment | Pedals and Levers, Air Conditioning Troubleshooting and Service for R-134a Systems, Loader | |
| Operator's Manual | Machine Operation, Controls and Instruments, Daily Maintenance and Lubrication, Operating Instructions |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Engine | Turbocharged diesel with radiator-mounted cooling | |
| Transmission | Carraro transmission with rear axle and planetaries | |
| Drive | Two-wheel drive or four-wheel drive front axle | |
| Loader Hydraulics | Loader control valve with three-point hitch, auxiliary control valve, and optional ride control | |
| Air Conditioning | R-134a refrigerant system |
Case 570LXT Series 2 Common Problems This Manual Covers
Slow or hesitant forward and reverse engagement, especially after sitting
Start with the transmission strainer and clean it, since a clogged strainer is a common cause of shuttle hesitation on the Carraro transmission, then check the standard transmission pressures against spec before removing the transmission. A strainer or control fault often mimics internal clutch wear, so confirm pressures first.
Manual Section: Power TrainLoader is slow, weak, or feels jerky
Confirm hydraulic pump output and system pressure using the hydraulic specifications and pressure checks, then service the loader control valve and the cylinders. If the machine has the optional ride control, check the ride control accumulator and solenoid valve, since a failed accumulator can make the loader feel jerky. Clean the hydraulic system if contamination is suspected before replacing the pump.
Manual Section: HydraulicsSteering heavy, slow, or wandering
Use the steering specifications, pressure checks, and troubleshooting, then service the steering control valve and the steering cylinders. Confirm the steering supply and relief pressures before replacing the control valve, and follow the two- or four-wheel-drive front axle procedure that matches your machine if the axle itself needs work.
Manual Section: SteeringNo-start, no-charge, or instrument fault
Use the electrical specifications and troubleshooting with the wiring information, then check the batteries, the Denso starter motor, and the alternator against spec. Confirm the fault at the circuit before replacing a component, since a battery, connection, or charging fault often presents as a starter or instrument failure.
Manual Section: ElectricalFrequently Asked Questions
The machine is slow to engage forward or reverse. What does the manual give me?
Work the power train troubleshooting. Slow or hesitant engagement on the Carraro transmission, especially after the machine has sat, commonly comes from a clogged transmission strainer or the control valve, so check and clean the strainer and verify the standard transmission pressures against spec before removing the transmission. The removal and service procedures follow if a rebuild is needed.
Are the loader hydraulics and optional ride control covered?
Yes. The Hydraulics group covers the hydraulic pump, the loader control valve, the cylinders, the three-point hitch control valve, the auxiliary control valve, and the accumulator and solenoid valve for the optional ride control, plus hydraulic specifications, troubleshooting, pressure checks, and cleaning the hydraulic system. That gives you the full loader circuit including the ride control option if your machine is fitted with it.
Does this set include the operator's manual as well as the repair manual?
Yes. This is a combined set: the factory service (repair) manual for teardown and rebuild plus the operator's manual for running the machine, daily controls, and routine maintenance and lubrication. That means you have both the shop procedures and the day-to-day operating and service intervals in one document.
My steering is heavy or the front axle needs work. Is two- and four-wheel drive covered?
Yes. The Steering group has the steering specifications, pressure checks, and troubleshooting, the steering control valve, the steering cylinders, and both the two-wheel-drive and the four-wheel-drive front axle, so you can check pressures before replacing a valve and follow the procedure that matches whichever axle your machine is built with.
Is the air conditioning service covered?
Yes. The manual includes air conditioning troubleshooting and system service for R-134a refrigerant systems, so you can diagnose and service the cab climate system to factory procedure rather than guessing at a refrigerant or component fault.
What do I get after purchasing this Case 570LXT Series 2 manual?
Immediate download of the complete 1199-page searchable Repair and Operator's Manual (441 MB). Access it on any device, from a laptop at your desk to a phone in the field.
Are there any print restrictions on this Case 570LXT Series 2 manual?
No restrictions at all. Print individual pages, full chapters, or the entire manual. The PDF is completely unlocked.
