This is the Kubota factory workshop manual for the RTV500 utility vehicle, the compact 4x4 side by side built around Kubota's hydrostatic transmission. Its 336 pages cover the whole machine: engine mechanism and servicing, the transaxle and HST, front and rear brakes, front axle and suspension, manual steering and the full electrical system with both old and new type wiring diagrams.Every system pairs a description of how it works with a servicing chapter holding troubleshooting charts, servicing specifications, tightening torques and disassembly procedures. Concrete numbers back it up, such as the 1.35 L engine oil capacity, the 8.5 L transmission fluid capacity and the 0.13 to 0.17 mm cold valve clearance, so you can chase an overheating, transmission or charging fault to the right part and reassemble to spec.It downloads instantly as a PDF, ready to print or read on any device.
What's Inside This Kubota RTV500 Manual
| System | Pages | Key Topics |
|---|---|---|
| General | 21-85 | Product Identification (Engine Identification, Emission Label, Cylinder Number, Model Name and Serial Numbers, Wiring, Battery, Fuse, Connector, Handling of Circuit Tester, Color of Wiring) |
| Engine | 86-98 | Engine Body (Cylinder Head, Combustion Chamber, Camshaft, Crankcase, Piston and Piston Rings, Connecting Rod, Crankshaft, Balancer, Flywheel) |
| Engine Servicing | 99-138 | Troubleshooting (Engine Body, Electronic Control Fuel Injection), Servicing Specifications |
| Transaxle | 139-167 | Structure, Power Train (Hydrostatic Transmission, Linkage, Range Gear Shift Section, Front Wheel Drive Section, Rear Axle Section), Rear Suspension (Structure) |
| Transaxle Servicing | 168-209 | Preparation, HST Assembly, Transaxle Case |
| Brakes | 210-217 | General Outline, Front Brake, Rear Brake, Master Cylinder, Brake Oil, Parking Brake |
| Brakes Servicing | 218-244 | Troubleshooting, Servicing Specifications, Tightening Torques, Checking and Adjusting (Brake Pedal, Brake Fluid, Brake Pad, Parking Brake Lever) |
| Front Axle | 245-248 | Structure Overview (Front: Axle, Suspension), Front Axle Component Description, Front Suspension Component Description (Function) |
| Front Axle Servicing | 249-269 | Front Wheels, Tie-Rod End, Drive Shaft Joint, Front Wheel Drive Gears, Front Differential Gear, Bearings, Gears, Front Wheel Alignment |
| Steering | 270-273 | Structure Overview (Steering Linkage, Manual Steering), Steering Linkage Description, Manual Steering Description |
| Steering Servicing | 274-279 | Troubleshooting, Tightening Torques, Disassembling and Servicing (Preparation, Disassembling and Assembling) |
| Electrical System | 280-301 | Wiring Diagram (Old Type, New Type), Starting System (Starter, Safety Switch), Alternator, Ic Regulator |
| Electrical System Servicing | 302-336 | Battery, Main Switch, Starter, Safety Switch, Relays, Alternator, Lighting System, Cooling System |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Lock nut torque | 39 to 45 N-m | p. 35 |
| Rear wheel mounting screw torque | 108.4 to 121.9 N-m | p. 35 |
| Engine Oil Capacity (Filter Exchanged) | 1.35 L | p. 33 |
| Transmission Fluid Capacity | 8.5 L | p. 33 |
| Coolant Capacity (with recovery tank) | 1.8 L | p. 33 |
| Engine Oil Pressure (At Idle Speed) | More than 98 kPa | p. 106 |
| Engine Oil Pressure (At Rated Speed) | 200 to 390 kPa | p. 106 |
| Valve Clearance (Cold) | 0.13 to 0.17 mm | p. 103 |
| Brake Pedal Free Travel | 7 to 14 mm | p. 223 |
| Brake Pad Thickness (Front) | 3.94 mm | p. 221 |
| Brake Disc Thickness (Front) | 5.3 to 5.7 mm | p. 221 |
| Parking Brake Lever Free Play | 1 notch | p. 221 |
Kubota RTV500 Common Problems This Manual Covers
Engine overheating
An RTV500 worked hard in hot weather can run over temperature from a clogged radiator, a weak water pump or low coolant. The Engine Servicing section covers troubleshooting and oil pressure checks to find the cause.
Manual Section: Engine Servicing p. 99Weak or no drive from the HST
Loss of drive, creeping in neutral or sluggish travel usually points to the hydrostatic transmission or its linkage. The Transaxle Servicing section covers HST troubleshooting, specifications and assembly.
Manual Section: Transaxle Servicing p. 168Hard starting or rough running
Starting trouble and stumbling under load can come from the electronic control fuel injection or the engine body itself. The Engine Servicing section includes troubleshooting for both the engine body and the fuel injection system.
Manual Section: Engine Servicing p. 99Spongy or weak brakes
A soft pedal or long stopping distance often means worn pads, low fluid or air in the lines. The Brakes Servicing section covers bleeding, the 3.94 mm pad wear limit and pedal free travel adjustment.
Manual Section: Brakes Servicing p. 218Dead battery or no charge
A battery that keeps going flat points to the charging system, a faulty alternator or the IC regulator. The Electrical System Servicing section covers charging troubleshooting and component testing.
Manual Section: Electrical System Servicing p. 302Loose or wandering steering
Play at the wheel and vague tracking usually mean worn steering linkage or loose fasteners. The Steering Servicing section covers troubleshooting, tightening torques and disassembly.
Manual Section: Steering Servicing p. 274Frequently Asked Questions
Which machine does this manual cover?
It covers the Kubota RTV500 utility vehicle. Every specification, procedure and wiring diagram is specific to that model.
Is this the full factory service manual?
Yes. It is the complete 336 page Kubota workshop manual, covering the engine, transaxle and HST, brakes, front axle, steering and electrical system, each with a description and a servicing chapter.
Does it cover the hydrostatic transmission?
Yes. The Transaxle Servicing section covers HST troubleshooting, servicing specifications, tightening torques and the disassembly and assembly of the HST and transaxle case. p. 168
Are the wiring diagrams included?
Yes. The Electrical System section includes both old type and new type wiring diagrams along with the starting system, alternator and IC regulator descriptions. p. 280
How quickly can I access this Kubota RTV500 manual after buying?
A 336-page Workshop Manual in searchable PDF format, available the moment you finish checkout. Open it on a computer, tablet, or phone with no shipping wait.
Is this Kubota RTV500 Workshop Manual printable?
Yes. Print as many copies as you like, with no restrictions. Plenty of mechanics print just the section they need and carry it to the shop floor.
Are there wiring harness diagrams in this Kubota RTV500 manual?
Yes, this Kubota RTV500 Workshop Manual includes complete electrical wiring diagrams, wire routing, and connector pinouts.
