Tracking down parts for your Takeuchi TB145? This 742-page Takeuchi TB145 parts manual PDF (OEM #BK3Z011) identifies every replaceable component on the hydraulic excavator by its factory part number. exploded views covering the lower frame (crawler belt, track rollers, front idler, travel device), the slewing device, engine and accessories, grease and hydraulic piping, cab and canopy, and the full boom group including the telescopic arm and auxiliary lines. Every drawing ties numbered callouts to exact Takeuchi part numbers and quantities, so you can cross-reference before you call the dealer. Even small hardware is pinned down: the catalog specifies the 1.2mm spacer thickness so you order right the first time. One wrong pin means another week waiting on freight. Bookmarked by system and text-searchable; type the part name, land on the exploded view, and place your order.
What's Inside This Takeuchi TB145 Parts Manual
| System | Pages | Key Topics |
|---|
| Lower Frame | 18-51 | Shoe Guide, Crawler Belt, Carrier Roller, Track Roller, Front Idler, Track Adjuster, Travel Device, Slew Bearing |
| Slewing Device | 52-111 | Turntable, Boom Swing, Swing Stopper, Travel Lever, Swing Pedal, Dozer Blade Lever, Operation Lever & Stand, Piping; Operation Lever |
| Engine & Accessories | 112-197 | Air Cleaner, Pulley, Drain Plug, Control Box; R.H., Control Box; L.H., Engine Control, Decel. Unit, Electrical |
| Grease Piping | 198-253 | Valve & Accessories, Piping; Upper, Accumulator, Emergency Shut-Off Valve, Pump Drive, Hydraulic Tank, Breather, Fuel Tank & Fuel Piping |
| Boom | 406-451 | Arm, Middle Arm, Telescopic Arm, Bucket, Auxiliary Line, 2nd Auxiliary Line, 3rd Auxiliary Line, Plug Assy |
| Decal | 452-742 | |
Quick Reference Specifications
| Specification | Value | Page |
|---|
| Bulb rating | 14V, 1.4W | p. 145 |
| Hydraulic tank shim thickness (selective) | 1.2mm / 2.0mm / 3.2mm | p. 241 |
| Turntable shim thickness (selective) | 0.2mm / 0.3mm | p. 385 |
