A fault code on the LC display, a full hopper, and trucks queued up the ramp: that is the moment this book exists for. The Bomag BF 700 C-2 operator manual PDF, factory document 008 200 30 EN, packs 220 pages of operating, safety and maintenance instruction for this asphalt paver. Maintenance takes the biggest share of the book, running from the 50-hour greasing round to the 2000-hour coolant change, with running-in checks staged over the first thousand hours. Troubleshooting wraps up with screed heating fault codes, jump-lead starting, and the full fuse assignment for the central electrics. When you renew the fuel filter, pull the screw-on cover to 25 Nm; the oil filter cover takes 50 Nm. A cold screed with a hot mat behind it is a miserable place to guess. Bookmarked and printable, this PDF survives the bench; download your copy and keep the mat moving.
What's Inside This Bomag BF 700 C-2 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction | 9-12 | Foreword, Machine Type Plate and Engine Type Plate |
| Technical Data | 13-18 | Noise and Vibration Data |
| Concerning Your Safety | 19-50 | Definition of Responsible Persons (Operating Company, Expert / Qualified Person, Driver / Operator) |
| Display and Control Elements | 51-84 | Operator’s Stand (Main Control Panel, Start Switch, V Universal Socket, LC-Display Unit, Function Button to Reset the Meter Counter, Function Keys F1 and F2, Toggle Button for Operator's Platform, Rotary Switch/Button Windscreen Wiper/Washer, Rotary Switch Working Lights Front and Rear, Rotary Switch for Lateral Working Light, Rotary Switch for Flashing Beacon, Emergency Stop Switch, Push Button to Release Hydraulics and Travel Functions, Push Button for Partial Unloading of Screed, Parking Brake Switch, Travel Lever, Travel Speed Potentiometer, Rotary Switch for Operating Mode, Toggle Switch Press Rollers, Push Button for Warning Horn, Hopper Control Panel, Scraper Belt Control Panel, Auger Control Panel, Toggle Button for Auger Height Adjustment, Tumbler Switch for Asphalt Fume Extraction System, Rotary Switch for Engine Speed, Push Button Reduced Engine Power, Toggle Switch, Travel Ranges, Toggle Button for Track Control, Steering Wheel, Push Button for Cleaning Function, Screed Width Control Panel, Control Panel Screed Up/Down, Levelling Control Panel, Control Panel for Screed Vibration, Control Panel for Tamper, Screed, Toggle Switch for Seat Heating, Hydraulic Hand Pump for Protective Roof) |
| Tests Before Taking Into Operation | 85-96 | Notes on Safety, Visual Inspections and Function Tests, Checking the Engine Oil Level, Checking the Fuel Level, Topping Up Fuel (Refuelling), Checking the AdBlue/DEF Level |
| Operation | 97-138 | Setting Up the Work Place, Operating the Screed, Operating the Screed Heating, Operating the Protection Roof, Emergency Procedures |
| Loading / Transporting the Machine | 139-144 | Prepare for Transport, Loading the Machine, Lashing the Machine to the Transport Vehicle, Loading by Crane |
| Maintenance | 145-202 | Preliminary Remarks and Safety Notes, Overview of Maintenance Flaps and Doors |
| Troubleshooting | 203-214 | Preliminary Remarks, Starting the Engine with Jump Leads, Screed Heating Fault Code Display, Fuse Assignment (Notes on Safety, Central Electrics, Main Fuses) |
| Waste Disposal | 215-216 | Final Shut-Down of Machine |
| List of Special Tools | 217-220 | - |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Tightening torque for screw-on cover main fuel filter | 25 Nm | p. 172 |
| Tightening torque for screw-on cover fuel pre-filter | 15 Nm | p. 172 |
| Operating weight (Cece) with screed | 20200 kg | p. 14 |
| Travel speed | 0-4 km/h | p. 14 |
| Rated power ISO 3046 | 128 kW | p. 15 |
| Fuel tank capacity | 285 l | p. 16 |
| Engine oil filling quantity | 17.5 l | p. 155 |
| Hydraulic system oil filling quantity | 160 l | p. 155 |
| Coolant filling quantity | 36 l | p. 155 |
| Main fuel filter cover tightening torque | 25 Nm | p. 172 |
| Fuel pre-filter cover tightening torque | 15 Nm | p. 172 |
| AdBlue/DEF filter housing tightening torque | 80 Nm | p. 175 |
Bomag BF 700 C-2 Common Problems This Manual Covers
Bomag BF 700 C-2 engine cranks slowly and won't start on cold mornings
Check battery terminal clamps for corrosion and tightness before calling for a jump. Follow the jump-lead procedure with the troubleshooting steps on page 204, connecting positive first. Verify fuel level too; the tank holds 285 l, and a low tank parked on a grade lets the pickup draw air.
Manual Section: Troubleshooting p. 204Engine oil pressure warning lamp lights up during pre-start checks before the first pass
Check the oil level on the dipstick as part of the pre-operation tests on page 85. Top up if low; the engine holds 17.5 l, per the filling quantities on page 155. If the lamp stays on with a correct level, shut down and get service out before the next pass.
Manual Section: Tests Before Taking Into Operation p. 85Coolant temperature climbs and warning buzzer sounds halfway through a long paving pass
Check the coolant level after the engine cools; never open the cap hot. Top up as needed; the system holds 36 l, listed on page 155. Clean radiator and cooler fins of asphalt fume residue at the intervals in the maintenance schedule to keep the machine in the pass.
Manual Section: Maintenance p. 155Engine loses power and runs rough pulling a full hopper up grade
Drain the water separator and check for a plugged fuel pre-filter first; dirty diesel from site tanks does this. Replace both elements per the maintenance schedule, then torque the pre-filter cover to 15 Nm and the main fuel filter cover to 25 Nm as given on page 172.
Manual Section: Maintenance p. 172AdBlue warning lamp comes on and engine drops into reduced power mid-shift
Check the AdBlue level during the pre-operation checks on page 85 and refill before it runs dry; the engine derates to protect the SCR system. If the DEF filter is due, tighten the filter housing to 80 Nm as listed on page 175, then let the system prime before restarting the pull.
Manual Section: Maintenance p. 175Frequently Asked Questions
What are the fault codes for the screed heating system?
The screed heating system displays fault codes in the [Temperature actual value] field. 'OC' indicates an interruption (open circuit), 'SC' indicates a short circuit, 'OUR' means the temperature exceeds the pre-selected value by more than 30 °C (86 °F), and 'AND' means the target temperature was not reached within 54 minutes. p. 206
What is the engine oil capacity for the BF 700 C-2?
The engine oil filling quantity for the BF 700 C-2 is 17.5 liters (4.6 gallons). p. 155
What is the tightening torque for the main fuel filter screw-on cover?
The tightening torque for the main fuel filter screw-on cover is 25 Nm (18 ft-lbf). p. 172
How often should the coolant be changed?
The coolant should be changed every 2000 operating hours, or at the latest after three years. p. 189
What is the nominal value for the tamper bar protrusion?
The nominal value for the tamper bar protrusion is 0.35 ± 0.05 mm (0.014 ± 0.002 in). p. 180
How quickly can I access this Bomag BF 700 C-2 manual after buying?
A single searchable PDF file of 220 pages, downloadable right after payment. Nothing ships, nothing waits in the mail.
Is printing allowed for this Bomag BF 700 C-2 Operator Manual?
Yes. The PDF has no DRM restrictions, so print any page or section you need for your shop. Works with any standard printer.
