Every component on your K9-P Mini Digger gets a labeled exploded view and a factory part number here, from the Kohler 23HP EFI engine down to the last bushing. The 27 pages walk system by system: tandem hydraulic pump, wheel motors and pipe routing, boom arms, split chassis, the main and auxiliary valve banks, and the EFI ignition harness with its wiring diagram. Part numbers are cross-referenced, so the arm pivot bush (1-1/4" ID x 1-1/2" OD x 32mm long) and the mount plate bearing bush (38.1 x 44.5 x 32mm) read as two distinct line items, not one guess. No more ordering off a blurry forum photo and hoping it fits. Bookmarked by system and keyword-searchable, it pulls up any assembly on your phone before you call the dealer.
What's Inside This Dingo K9-P Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction | 2-3 | Model No, Serial No, Disclaimer, Contents |
| Kohler Dash Assembly K9-P | 4-5 | Part Numbers & Descriptions (Dash Assy Welded & Painted, Relay Sealed 12V 30/40Amp Changeover, Hourmeter Round Quartz 12V, Handle L/H K94 W/Assy, Handle R/H K94 W/Assy, Handgrip Ergo - Grip Soft Texture Black Handle, Cable Lever Assy Throttle/Choke, Washer Spring M12 Zp 3mm Thick 4mm Wide, Bolt Hex M12 X 25 Gr8.8 Zp 1.75P, Washer Spring Metric M6 X 1.6T X 2.5W Zp Silver, Set Screw Hex M6 X 12 Gr8.8 Zp, Nut Speed M6 Short, K9P Compliance Plate, Screw Knock in 6G X 1/4" Zp Type U Drive, Washer Flat 1/4" X 1/2" OD 18G Zp Bright, Mounting Plate Auxiliary Bank, Switch Ignition, Key-Switch Ignition) |
| Kohler Engine Assembly | 6-7 | Part Numbers & Descriptions (Engine Kohler 23Hp Efi Ech650, Plate 8Mm Engine Mount - K9P Petrol-Diesel, Kohler Muffler Centre Outlet Efi, Gasket Muffler Kohler, K9P Exhaust Extension, Clamp Exhaust 1 1/2", Kohler Efi Air Intake Adaptor Plate Aluminium 26Mm Thick, Adaptor 90° Elbow Aircleaner/Engine Kohler, Clamp Hose 46-70Mm 2.75" Tridon, Air Intake Hose K9P, Coupling Tapered Kohler Pump Drive, Retainer Washer Kohler Drive Coupling, Bolt Hex 3/8" X 1 1/4" Unc Gr8 Zp, Spider Elastic R82 Hyd Pump Drive, Coupling Pump Half, Bellhousing Kohler, Centring Ring, Pump Hyd Tandem 11.2Cc/4Cc, Seal Kit Hyd Pump, Hose Tail 1" Bspp Male X 1" "Shortened", Clamp Hose Supra 34-37Mm, Hose 1" Return Suction Mega VAC, Nipple M/M 1/2" Bspp X 7/8" Jic Enc/Seal, Nipple M/M 1/2" Bspp X 3/4" Jic Enc/Seal, Hyd Hose Assy 1/2" K9P Pressure 610Mm, Hyd Hose Assy 3/8" K9P Pressure 685Mm, Cap Screw Socket Head M8 X 25 Zp 1.25P, Air Cleaner Assy Large Nelson K9 90°, K9P Air Cleaner Bracket, Filter Element Outer Air, Filter Element Air Inner, Cover Air Cleaner End Large, Clip Air Cleaner, Valve Dust Ejector A/Cleaner, Precleaner 2" Inlet, Co2 Sensor on Muffler for Efi Engine, Mounting Plate Auxiliary Bank, Bracket Air Cleaner) |
| K9-P Wheel Motors & Pipes | 8-9 | K9-P Wheel Motors and Pipes Part Numbers & Descriptions (Dingo Spec Wheelmotor 1 3/8" Shaft, Key Woodruff Mb/Me Taper Shaft, Seal Output Shaft Wheelmotor, Seal Kit Wheelmotor, O Ring Wheel Motor Mount – Welded Chassis, Wheel Nut, Hub Twin Flange Sprocket Type 1 3/8"-Inc Studs, Nipple M/M 7/8" Uno X 7/8" Jic, Pipe Hyd 5/8" C4 Front Whl Mtr LH No Valve Type, Pipe Hyd 5/8" Rear of Tank to Front Wheel Motors, Pipe Hyd 5/8" Oc Valve to Bottom Rear of Tank, Nipple M/M 7/8" X 7/8"Jic Bulkhead, Pipe Hyd 5/8" C2 Front R/H Wheel Mtr, Pipe Hyd 5/8" External Rear Wheel Motor, Washer Flat 1 1/8" X 2"Od 2Mm - Wheel Motor, Valve O/Centre DOC Twin Circuit with Relief, Nipple M/M 7/8" Uno X 7/8" Jic Ext Bulkhead, Wheel Motor Nut, Cartridge Over Centre Valve, Stud Wheel 7/16" X 1 7/8" 48Mm) |
| K9-P Tank Top Assembly | 10-11 | Part Numbers & Descriptions (O Ring Hyd Filter Top of 100 Series 4" ID 1/8 Thick, O Ring Filter Housing to Tank, Filter Element Hyd, Dipstick Assy Hyd Tank, Tank Top Front Assy in Tank Filter, Bolt Hex M8 X 16 Gr8.8 Zp 1.25P, Filter Assy Hyd Oil, Seal Kit Filter Housing, Hose Tail Straight M8 X 1.25 Thread X 1/4" Hose, Nipple M/M 1" Bspp X 1 1/16" Jic) |
| K9-P Bushes Mount Plate | 12-13 | Part Numbers & Descriptions (Mount Plate Male Assy Bush Type Inc Q/R Pins, Bush Arm Pivot 1 1/4" ID X 1 1/2" OD X 32Mm Long, Bush Bearing Mount Plate 38.1 X 44.5 X 32Mm L, Bush Bevel Q/R Lock Mount Plate, Spring Compression Male Mount Plate, Pin Roll 5/32" X 1 Q/Release Pin Retainer, Locking Pin Mount Plate Q/Release 5/8") |
| K9-P Arms Exploded | 14-15 | Part Numbers & Descriptions (Arm W/Assy Lift Inc Bushes, Pin & Bush Kit, Pin Ram Base Short Pin Short Tag 1" Chrome, Cyl Hyd K9 Phasing, Pin 1 1/4" Chrome Mount Plate 63 Mm, Elbow M/M 9/16" Uno X 9/16" Jic 90°, Bush Arm Pivot 1 1/4"Id X 1 1/2"Od X 32Mm Long, Pin - 1 1/4" Chrome - Arm Rear Pivot Pin, Hyd Hose Assy 1/2" Rmte to Mle Cplng 1180Mm, Nipple 1/2" Bspp X 7/8" Bulkhead, Coupling Q/R Hyd Male 1/2", Dust Cover 1/2" Male, Dust Cover 1/2" Female, Coupling Q/R Hyd Female 1/2", Coupling and Dust Cap Kit ½" Q/R, Hyd Hose Assy 1/2" Rmte to Fm Cplng 1150Mm, Clamp Block Half Only Hyd Hose 22Mm, Pin - 1" Chrome - Top Crowd - 134Mm Long, Mount Plate Male Assy Bush Type Inc Q/R Pins, Nipple M/M 3/8" Bspp X 9/16" Jic Bulkhead, Hyd Hose Assy 1/4" 1105Mm Remote Hose F-F, Hyd Hose Assy 1/4" 1130Mm Remote F-F, Arm Tie Down Bracket 8Mm, Hyd Hose Assy 1/4" 520Mm - Lift, Hyd Hose Assy R/H Ram Top Hose 430Mm, Hyd Hose Assy L/H Ram Top Hose 355M, Hyd Hose Assy L/H Ram Lower 395Mm, Hyd Hose Assy Crowd Ram Front 1590Mm, Hyd Hose Assy Crowd Ram Rear 1500Mm, Hose Spacer, Screw Flat Head Socket Countersunk M8X50ZP, Hose Bkt Cap 32x3Mm, Plate L/H Remote Hose Holder 65Mm Long, Clamp Block Half Only Hyd Hose 15Mm) |
| K9-P Chassis Exploded | 16-17 | Part Numbers & Descriptions (Split Chassis Welded Assembly, Bracket W/Assy Fuel Tank F/Male Pivot, Battery Dingo, Plug-Immobilisier - Dash – 1.5" Hole, Grille Aluminium Upper Bonnet Scoop Mesh, Hosetail 1" Bspp Male X 1" with Dropper Tube, Battery Bracket Raised, Battery Bracket, Alum Side Panel L/H, Dash Assy, Aluminium Dash Front Panel, K94 New Chassis Bonnet Bracket, Alum Dash Rear Half Panel, Alum Bonnet – Mesh Grille Not Inc, Arm W/Assy Lift Inc Bushes, Split Chassis Grill Welded Assembly, Alum Side Panel R/H, Fuel Tank Rear 1 Piece Bracket W/Assy, Fuel Tank Front Mount W/Assy, Tank Top Front Assy in Tank Filter, Rear Tank Single Oil Pick Up Lid RH W/Assy, Rear Battery Spacer, Rear Tank Lid LH, K9P Dash Bracket R/H for Ignition, K9P LH Dash Bracket, Fuel Tank K94/5/P/D/C W/-Nut Inserts, Elbow 5/16" Barb Tail Push in Fuel Line, Cap Fuel Unleaded Black Clicker, Grommet Fuel Tank Outlet, Catch - Flat - Bonnet Lockable, K9P Muffler Heat Shield, Air Cleaner Bracket, Engine Mount to Chassis Bracket Petrol) |
| K9-P Dash Assembly | 18-20 | Valve Bank Main Control with Drain (Spool Control Cap, Boot Rubber Control Cap, Brass Insert Suits Sd5, Oring Brass Insert Inner, Oring Brass Insert Outer, Oring Suit Sd4/5/6, Spool Drive Suit Sd5, Spool Lift/Crowd Suit Sd5, Spring Return Kit, Block Sd5 Drain, Oring Sd5 Drain Block - Early, Oring Sd5 Drain Block - Late, Relief Valve, Seal Kit Suit Sd5 Control Bank) |
| K9-P Aux Dash Assembly | 21-22 | Valve Bank Auxilary Control (Spool Control Cap, Boot Rubber Control Cap, Brass Insert, Oring Brass Insert Inner, Oring Brass Insert Outer, Oring Suit Sd4/5/6, Spool, Position Detent, Spring Return, Relief Valve) |
| K9-P Pipe Configuration | 23 | Main Control Bank, K94494, K94495, K94493, K94492 |
| Kohler Efi Eng. Ignition Harness | 24 | Grom Blue Eye, Change Over, Hour Meter, Ignition, Large Pin Plug |
| Notes | 25-27 | Proudly Manufactured by, Dingo Mini Diggers Pty Ltd 9 Owen Street East Dalby Qld 4405 Australia, Dingo, Dingo.Com.Au |
Every system also includes a diagram.
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| HYD HOSE ASSY 1/2" K9P PRESSURE length | 610mm | p. 7 |
| HYD HOSE ASSY 3/8" K9P PRESSURE length | 685mm | p. 7 |
| BUSH ARM PIVOT dimensions | 1 1/4" ID x 1 1/2" OD x 32mm. | p. 13 |
| BUSH BEARING MOUNT PLATE dimensions | 38.1 x 44.5 x 32mm. | p. 13 |
| Relay Voltage | 12V | p. 5 |
| Engine Horsepower | 23HP | p. 7 |
| Engine Mount Plate Thickness | 8mm | p. 7 |
| Hydraulic Pump Displacement | 11.2CC/4CC | p. 7 |
| Wheel Motor Shaft Diameter | 1 3/8" | p. 9 |
| Arm Pivot Bushing Dimensions | 1 1/4" ID x 1 1/2" OD x 32mm | p. 13 |
| Mount Plate Pin Diameter | 1 1/4" | p. 15 |
| Hydraulic Hose Length (Lift) | 520MM | p. 15 |
Dingo K9-P Common Problems This Manual Covers
Dingo K9-P hydraulic filter housing leaking, need correct O-ring part numbers for filter top p. 10
Check page 10 for the Tank Top Assembly parts list. Two O-rings are catalogued separately: the top filter O-ring (4" ID, 1/8" thick) and the housing-to-tank O-ring. If both look suspect, the Seal Kit Filter Housing covers the complete set. While you are there, note the Filter Element Hyd and Dipstick Assy numbers on the same page.
Manual Section: K9-P Tank Top AssemblyRoutine service due, can't find part numbers for inner and outer air filter elements p. 6
Find the Kohler Engine Assembly list on page 6. The air filter elements are split into two line items, Filter Element Outer Air and Filter Element Air Inner, and the Precleaner with a 2" inlet sits just below them. Page 7 carries the exploded diagram, so confirm the Dust Ejector Valve and Air Cleaner bracket positions there before ordering.
Manual Section: Kohler Engine AssemblyHydraulic hose failed on lift arm, need exact replacement length and part number p. 14
Turn to page 14 for the K9-P Arms Exploded diagram. The lift arm runs a dedicated 520mm hose assembly, while the crowd ram uses a 1590mm front hose and a 1500mm rear hose, all itemised on page 15. Match the failed hose to its diagram position first: six distinct assemblies route through the arm, and lengths vary by as much as 1070mm.
Manual Section: K9-P Arms ExplodedArm pivot worn and sloppy, need bushing dimensions and part number to order correct replacement p. 12
Open page 12 for the K9-P Bushes Mount Plate exploded view. The arm pivot bushing reads 1 1/4" ID x 1 1/2" OD x 32mm long; the mount plate bearing bush is a different size, 38.1 x 44.5 x 32mm, catalogued on page 13. Confirm which position is worn, then grab the Q/R lock pin and compression spring numbers from the same section.
Manual Section: K9-P Bushes Mount PlateWheel motor output shaft seal leaking, need part numbers for seal and full seal kit p. 8
Pull up the K9-P Wheel Motors and Pipes list on page 8. The Seal Output Shaft Wheelmotor and the full Seal Kit Wheelmotor are listed as separate line items. The shaft measures 1 3/8" diameter; grab the Key Woodruff Mb/Me Taper Shaft number too, since it usually wants inspection once the output seal is disturbed.
Manual Section: K9-P Wheel Motors & PipesControl valve spool seals worn, need correct O-ring kit part number for main SD5 valve bank p. 18
Head to page 18 for the K9-P Dash Assembly valve bank list. The Seal Kit Suit Sd5 Control Bank covers every internal O-ring on the main bank, though individual rings such as Oring Suit Sd4/5/6 and the inner and outer brass insert O-rings are catalogued on their own. For the auxiliary bank, page 21 lists its spool and spring return parts separately.
Manual Section: K9-P Dash AssemblyFrequently Asked Questions
What is the arm pivot bushing size on a Dingo K9-P?
The arm pivot bushing measures 1 1/4" ID x 1 1/2" OD x 32mm long. The mount plate bearing bush is a different size: 38.1 x 44.5 x 32mm. Both are listed in the K9-P Bushes Mount Plate section on page 13.
What hydraulic hose lengths do I need for the K9-P lift arm?
The lift arm runs a 520mm hose assembly. For the crowd ram, you need a 1590mm front hose and a 1500mm rear hose. All six hose assemblies routing through the arm are itemised on page 15 of the K9-P Arms Exploded section.
What wiring and electrical components are covered in the K9-P parts catalog?
Page 24 covers the EFI ignition harness and associated wiring diagram components. Electrical items are cross-referenced by part number alongside hydraulic and mechanical assemblies throughout the catalog.
Where do I find the O-ring kit part number for the K9-P main control valve bank?
Page 18 lists the K9-P Dash Assembly valve bank. The Seal Kit Suit Sd5 Control Bank covers every internal O-ring on the main bank. Individual O-rings such as Oring Suit Sd4/5/6 and inner and outer brass insert O-rings are catalogued separately. The auxiliary bank seal and spring-return parts are listed on page 21.
How do I check hydraulic pressure on a Dingo K9-P?
The K9-P Dash Assembly carries a "TEST PORT ADAPTOR 3/8" BSPP MALE" (Part Number 9314090001) for checking hydraulic pressure. It is listed as Item 6 in the K9-P Dash Assembly Part Numbers & Descriptions.
What are the replacement specifications for air filters?
Two elements cover the air filter: the "FILTER ELEMENT OUTER AIR" (Part Number 9515000033) and the "FILTER ELEMENT AIR INNER" (Part Number 9515000034). Both belong to the "AIR CLEANER ASSY LARGE NELSON K9 90°" (Part Number 9515000036).
How will I receive this Dingo K9-P Parts Catalog?
A searchable, 27-page PDF Parts Catalog, yours the moment checkout completes. Open it on a computer, tablet, or phone, with no shipping wait.
Can I print specific sections of this Dingo K9-P Parts Catalog?
Yes. The PDF carries no DRM restrictions, so print any page or section you need for the shop. It works with any standard printer.
Document Quality
This document is a scanned PDF with an optical character recognition (OCR) layer, allowing you to search and copy the full text. The text quality is crisp and legible throughout. Diagrams and illustrations are raster images, which are clear at normal viewing but may show pixelation if zoomed in significantly, though labels remain readable. The pages are clean with no noticeable scan artifacts or skewed content. There are a few "NOTES" pages at the end that are mostly blank.
