Every part on your 1990-1993 AG tractor lives somewhere in this 612-page Ford 8730 parts catalog PDF, from the APL 365 front axle to the 18x9 Powershift transmission. You get exploded views with factory part numbers for the engine block, crankshaft, and turbocharger, plus full breakdowns of the Dana axle, Dual Power transmission, cab glass, and electrical harnesses for standard and Powershift builds. Wheel weights, seat assemblies, decals, even the 7413 loader boom and grapple fork are all figured and numbered. A figure search index up front shows you how to jump straight to any assembly. Match your machine exactly: 72-amp or 90-amp alternator, 3-1/2 inch lift cylinder, 13-pound radiator cap. Ordering the wrong part twice hurts worse than the breakdown. Bookmarked with a full text layer; type the part name, find the figure, order once.
What's Inside This Ford New Holland 8730 Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Fuel System | Fuel Tank Assembly & Related Parts, Fuel Sedimenter & Filter Assembly, Fuel Injection Pump, Fuel Injector Assembly, Fuel Pump Assembly, Air Cleaner & Related Parts, Diesel Fuel Primer Assembly | |
| Cooling System | Transmission Oil Cooling System, W/powershift, Radiator, Oil Cooler & Related Parts, Water Pump, Pulley & Related Parts, Bracket Assembly & Thermostat Housing, Radiator Overflow Container | |
| Engine | Cylinder Block, Head & Related Parts, Engine Block, Kit - Stepped Stud Engine Block, Crankshaft, Flywheel & Related Parts, Camshaft, Rocker Arm, Valves & Related Parts, Pistons & Connecting Rods, Oil Pump, Oil Pan & Related Parts, Gasket Overhaul Kit, Oil Pump Control Valve & Tubes, Engine Coolant Immersion Heater, Hydraulic Pump Assembly, Engine Mounted, Engine Mounted Pump & Tubing, Engine Noise Insulation Side Shields, Lubrication Equipment, Engine Coolant Heater Kits | |
| Electrical System | Headlamp Assembly, Rear Lamps - Stop & Flasher W/turn Indicator W/Cab, Parking Lamps - Stop, Side & Flasher L/Cab, Side & Flasher - W/hazard Warning, Lamp Assembly, Emergency Warning - U.S., Side Flasher, Stop & Turn, License Plate, W/Cab, Emergency Warning, U.S., W/crown Fenders, Implement Lamp Assembly, Lamp, Front & Rear, Work, Alternator, 72 Amp, Battery, Tray & Step Assembly - Except, Stop & Tail Lights - D.i.a. - U.S., Tail Lights - W/flat Top Fenders, D.i.a., Nhna, Lamp Assembly - License Plate - D.i.a. - U.S. | |
| Clutch & Transmission | Transmission Handbrake Lever, Transmission Case, 8-Speed Transmission Gears & Related Parts, Transmission Control, Transmission Dual Power, PTO Clutch, Valve, Shaft & Related Parts, PTO Clutch Controls, Independent PTO Clutch Linkage, Clutch Controls, Creeper Gears, Transmission Housings & Related Parts, 18 X 9 Powershift, Clutch Assembly & Charge Pump - 18 X 9 Powershift, Speed Clutch Assemblies - 18 X 9 Powershift, Range Clutch Assemblies - Forward 1 & Reverse - 18 X 9 Powershift, Range Clutch Assembly, Forward 2, Transmission Shift Control | |
| PTO | PTO Guard Kit | |
| Rear Axle, Differential & Brakes | Rear Wheels, Power Adjust & Manual Adjust Rear Wheels, Pressed Steel Wheel Assembly, Rear Wheel, Rear Wheel Weights, Manual Adjust Rear Wheel Weights W/square Wheels 28" to 38", Brake Lines, W/l Powershift, Transfer Gear Handbrake, Brake Controls, Brake Tubes & Fittings, Hydraulic Trailer Brakes, Rear Axle, Differential & Related Parts, Center Housing, Differential Lock & Related Parts, Differential Lock Linkage & Valve, Buzzer, Handbrake, Except | |
| Front Axle & Steering | Front Wheel Assembly, Front Wheel, Piece Rim, Front Wheels - FWD, Front Wheel Weights, Steering System, Adjustable Front Axle & Related Parts, Steering Column Assembly, Steering Column Flange Assembly, Steering Motor, Power Steering Pump & Reservoir, Power Steering Cylinder Assembly & End Assemblies, Front Axle Apl, Steering Housing Apl, Steering Assembly Apl, Transfer Case, Steering Housing, Dana Axle | |
| Hydraulics & 3-Point Hitch | Hydraulic Lift Cylinder, Hydraulic Lift, Draft & Flow Controls, Handles - Hydraulic Remote Control Valve, Hydraulic Lift Linkage, Swinging Drawbars, Hydraulic Remote Valves & Related Parts, Deluxe Remote Control Valve - Single & Double Spool, Kit - Coupling - Lever Type Coupler, Remote Cylinder Circuit Check, Quick-Hitch Linkage & Related Parts, Remote Control Unload Valve Assembly, Hydraulic Lift Assist Ram, Lift & Draft Control, Cover & Valve Assembly, Tubes & Filters, Pump & Pump Cover, Handles - Remote Control Valves | |
| Body & Operator Station | Tractor Seat Assembly, Seat Assembly, Bostrom, Suspension, Bostrom 10 Digit Serial No., Seat Assembly Suspension, Grammer Ds85, Air Suspension, Seat Suspension Assembly, Air, Rear Flat Top Fenders, Rear Mud Fenders W/Cab, Hood, Cowl & Instrument Panels, Hood Side Panels & Grille W/related Parts, Front Center Grille Assembly & Frame, Front Fenders, Safety Frame - Upper & Lower, Seat Belt & Rollbar | |
| Decals & Accessories | Model Identification Decals, Instruction Decals, Shift Pattern & Control Console Decals, Kit, Tools | |
| Other Components | Front End Wafer Weights, Front End Weights, Planetary Drive Apl, Carrier Assembly Apl, Shield Assembly, Axle Assembly, Dana Axle, Carrier Assembly - 3/4 Pin, Planetary Drive - 3 Pin, Planetary Drive - 4 Pin, Oil Tubes & Fittings, Differential Center Housing, Lower Lift Torsion Bar System, Manifold & Exhaust System W/turbocharger, Turbocharger Assembly, Torque Limiter & Related Parts - 18 X 9 Powershift, Water Filter, Diesel Cold Start |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Cap Assy. pressure rating | 13 lbs. | p. 261 |
| Hose length | 3840.0mm | p. 479 |
| Engine Coolant Heater Voltage | 230V | p. 294 |
| Alternator Output | 72 AMP | p. 360 |
| Lift Cylinder Diameter | 3-1/2 inch | p. 568 |
Ford New Holland 8730 Common Problems This Manual Covers
Ford 8730 powershift transmission running hot with E03 code, unsure which oil cooler parts fit my serial range
Check the transmission oil cooling system parts group and match cooler lines and fittings to your serial number break. Trace line routing on the drivetrain parts diagram to identify unmarked fittings, then verify each number against the parts number list before ordering. Convert metric line sizes using the tables on page 611.
Manual Section: Transmission Oil Cooling SystemEngine hard to start in cold weather, block heater dead, need heater and radiator cap part numbers
Check the immersion heater listing on page 294; the replacement element is rated 230V, so match your shop supply before ordering. Replace the radiator cap at the same time if it will not hold pressure; the cap assembly on page 261 is rated 13 lbs. Verify both numbers against the parts number list.
Manual Section: Engine Coolant Immersion Heater p. 294Loader lift cylinder leaking, parts listing shows two cylinder diameters and unsure which seal kit fits
Measure your cylinder bore before ordering seals; page 568 lists a 3-1/2 inch diameter lift cylinder for the 7412HD and a 3-1/4 inch diameter cylinder for the 7413. Check the loader hydraulic system exploded views starting on page 531 to confirm which assembly your machine carries, then order the matching kit.
Manual Section: 8730 Loader 7413 Qa p. 568Alternator not charging, ID tag unreadable, parts listing shows several output ratings for this tractor
Check the electrical system parts listings; page 360 covers the 72 AMP alternator and page 361 covers the 95 AMP unit. Compare mounting brackets and pulley style in the exploded views against your old unit before picking one, then verify the number against the parts number list.
Manual Section: Electrical System p. 360Frequently Asked Questions
What are the replacement specifications for the hydraulic filter on the 8730 tractor?
The hydraulic filter for the 8730 tractor is part number 86546610, which is a mounted horizontal filter. p. 152
What is the specification for the engine oil filter for the 8730 tractor?
The engine oil filter for the 8730 tractor is part number 86546615. p. 169
What is the torque specification for the cylinder head bolts on the 8730 engine?
The manual does not provide a torque specification. However, it lists the cylinder head bolts for the 8730 engine as part number 87802206, which are 9/16"-12 UNC 2A x 5-1/32" bolts. p. 167
What is the part number for the starting motor assembly for the 8730 tractor?
The starting motor assembly for the 8730 tractor is part number D8NN11000CE. p. 367
What is the specification for the alternator on the 8730 tractor?
The 8730 tractor uses a 90 Amp alternator, part number E9NN10300AA. p. 361
What format is this Ford 8730 manual in?
This is a 612-page searchable PDF ready for immediate download. Works on any device, so pull it up on your phone while you're under the hood. No shipping, no waiting.
Is this Ford 8730 Parts Catalog printable?
Zero restrictions. The PDF is DRM-free. Print whatever sections you need to take out to the shop. Standard letter or A4 paper works.
