Safe, productive daily running of three skid-steer loaders comes down to 43 pages in this Gehl SL7610, SL7710, SL7810 operator manual PDF (Form No. 917032), with the European-spec SL7710 covered as well. Controls and safety equipment fill a good share of the book, from the operator restraint bar to the lift arm support device, and the operation chapter takes you through engine starting and changing attachments. Troubleshooting charts for the electrical system and engine come next, while the maintenance chapter sets intervals for the air cleaner, cooling system, drive chains and lift arm pivots. Expect 3300 psi from the main hydraulic system and 29 gpm at standard flow; torque wheel nuts to 180 ft-lbs. Climbing under raised lift arms leaves no room for doubt. Bookmarked, text-searchable pages jump straight to loader identification, so your dealer gets the right model and serial number and the part arrives correct the first time.
What's Inside This Gehl SL7610, SL7710, SL7810, SL7710 (EU) Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction | 3-4 | Loader Identification, Manual Storage, Attachments, Service Parts, Owner Information |
| Safety | 5-9 | Mandatory Safety Shutdown Procedure, Potential Hazards |
| Controls and Safety Equipment | 10-17 | Operator Restraint Bar, Lift Arm Support Device |
| Operation | 18-22 | Starting the Engine, Changing Attachments |
| Service | 23-30 | Loader Raising Procedure, Engine Service |
| Troubleshooting | 31-34 | Electrical System, Engine |
| Maintenance | 35-36 | Foreign Material Removal, Engine Air Cleaner, Hydraulic System, Cooling System, Drive Chains, Lift Arm Pivots |
| Specifications | 37-40 | Operating Weight, Engine, Hydraulic System, Electrical System, Capacities, Sound Levels |
| Torque Specifications | 42-43 | Unified National Thread, Grade 2 Hardware, Grade 5 Hardware, Grade 8 Hardware, Metric Coarse Thread, Metric Grade Hardware |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Main Hydraulic System Pressure | 3300 psi | p. 37 |
| Standard-Flow Rating | 29 gpm | p. 37 |
| Wheel Nut Torque | 180 ft-lbs | p. 29 |
| Lift Arm Pivot Torque | 240 ft-lbs | p. 29 |
| SL7610 | ||
| Rated Operating Load (SL7610) | 3400 lbs | p. 37 |
| SL7810 | ||
| Rated Operating Load (SL7810) | 3675 lbs | p. 37 |
| SL7710 (EU) | ||
| Rated Operating Load (SL7710 EU) | 3875 lbs | p. 37 |
Gehl SL7610, SL7710, SL7810, SL7710 (EU) Common Problems This Manual Covers
Gehl SL7610, SL7710 and SL7810 starter will not engage when the key is turned to START
Clean the battery terminals and cables and retighten them, then recharge or replace a discharged battery. Before servicing the battery or wiring, set the battery disconnect switch to OFF (page 30). Check ignition, seat switch and restraint bar switch wiring for loose or broken leads per page 31. Never bypass the keyswitch (page 6); if the seat switch, restraint bar switch, starter relay or starter solenoid is at fault, contact your dealer.
Manual Section: Electrical System Troubleshooting p. 31Loader engine turns over on the starter but will not fire or start
Return the control valves to neutral and confirm the fuel tank is not empty. Replace a plugged fuel filter with no smoking or spark-producing equipment nearby (page 6). Check connections and voltage at the fuel shut-off solenoid following page 32. If cranking speed is slow, recharge or replace the battery; in cold weather, pre-warm the engine or install a block heater. A failed fuel pump goes to your dealer.
Manual Section: Engine Troubleshooting p. 32Engine runs hot and overheats repeatedly during sustained digging and loading work
Shut the engine off and clear any blockage restricting fan air circulation, then check crankcase oil level and add or remove oil as required. Add coolant if low, but never remove the cap while coolant is hot (page 29). Tighten a loose fan belt, replace a restricted air filter, and let the exhaust cool before clearing a restriction, per page 32. A misplaced fan shroud is a dealer job.
Manual Section: Engine Troubleshooting p. 32Lift arm and bucket tilt controls fail to respond when the operator works the controls
Lower the restraint bar first, then check oil level in the reservoir. If low, look for external leaks with a piece of cardboard, never your hands (page 9), with the lift arm lowered (page 28); repair and add oil. Allow longer warm-up if oil is too heavy. Check electrical connections to the lift solenoid per page 33. Never bypass the seat or restraint bar switch (page 10); a faulty switch goes to your dealer.
Manual Section: Hydraulic System Troubleshooting p. 33Lift arm drifts down and will not hold raised position with lift control in neutral
Lower the lift arm before servicing the hydraulics (page 28), then check oil level in the reservoir and inspect the hoses, tubes and fittings between the control valve and cylinders following page 34. Hunt leaks with a piece of cardboard, never your hands (page 9). Tighten fittings and replace leaking hoses or tubes as needed. Leakage past the lift cylinder seals or lift spool, or a faulty self-leveling valve, is a dealer repair.
Manual Section: Hydraulic System Troubleshooting p. 34Auxiliary hydraulics function slowly or do not function at all with an attachment hooked up
Lower the restraint bar and turn the flow control knob up from minimum, then run the engine at higher speed. With the lift arm lowered (page 28), add hydraulic oil if low and check the load sensing signal line, tightening or replacing it if loose or broken. Readjust control linkage for full spool travel per page 34. A failed load sensing compensator or high pressure compensator goes to your dealer.
Manual Section: Hydraulic System Troubleshooting p. 34Frequently Asked Questions
How do I troubleshoot a no-start condition on a Gehl SL7610, SL7710, or SL7810?
If the starter will not engage when the key is turned to START, check if the seat or restraint bar switch is malfunctioning or not actuated. Also, verify battery connections, check for a discharged battery, or inspect the starter relay in the instrument panel. Contact your dealer if the starter solenoid is not functioning. See page 31 for a complete troubleshooting table. p. 31
What are the hydraulic relief-pressure specifications for a Gehl SL7610, SL7710, or SL7810?
The main hydraulic system pressure for the SL7610, SL7710 (EU), and SL7810 models is 3300 psi (228 bar). p. 37
What are the replacement specifications for the hydraulic oil filter on the Gehl SL7610, SL7710, SL7810, SL7710 (EU)?
The Gehl part number for the hydraulic oil filter element is 184157. The hydraulic oil should be changed after 1000 hours or one year of use, or if it becomes contaminated. p. 23
What is the required torque for the lift arm pivot points on a Gehl SL7610, SL7710, SL7810, SL7710 (EU)?
The lift arm pivot points should be torqued to 240 ft-lbs (325 N·m). p. 29
What is the engine oil capacity for the Gehl SL7610, SL7710, SL7810, SL7710 (EU) skid-steer loaders?
The engine oil capacity for the SL7610, SL7710, and SL7810 is 8.9 U.S. quarts (8,5 liters). p. 25
What do I get after purchasing this Gehl SL7610 manual?
You get a 43-page searchable PDF that downloads instantly after checkout. Open it on your laptop, tablet, or phone, and bring it right to the shop floor.
Am I able to print pages from this Gehl SL7610 manual?
Yes. Many mechanics print the section they need for their own shop and bring it to the bench.
