Written for the 50Z V wheel loader and no other machine, this Kawasaki 50Z V parts catalog PDF (publication 93305-00153) runs 554 pages and matches parts to your build, standard or optioned. Exploded views break down the lift arms, lift and tilt cylinders, loader valve, Orbitrol steering unit, transmission clutch packs and both differentials, each callout tied to a part number you can cross-check in the index at the back. Optional equipment fills a large share of the book: the high lift arm variants, kickout, dynamic damper, cab, air conditioning and heater, plus wiring layouts that trace harness clamps and connectors through the chassis and cab. Order the front and rear lamp bulbs as 24V 62W/62W and the instrument panel bulbs as 24V 1.4W. Made-up torque figures strip threads; guessed part numbers park loaders. The pages are bookmarked and text-searchable, and they print cleanly enough to take to the bench, where they can soak up hydraulic oil.
What's Inside This Kawasaki 50ZV Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Clutch & Transmission | Transmission Hydraulic Line, Torque Converter & Transmission, Transmission, Reverse & First Clutch, Forward & Second Clutch, Third Clutch, Transmission Control Valve, Shift Lever | |
| Fuel System | Fuel Tank, Air Cleaner, Fuel Line, Fuel Control | |
| Cooling System | Radiator Mount, Radiator, Fan Mount, Radiator Mount - 4mm Pitch Fin, Hydraulic Line - Oil Cooler | |
| Engine | Engine Room Mount, Air Breather Mount, Oil Pump | |
| Electrical System | Gauge, Electrical Parts Mount, Front Lamp, Rear Lamp, Battery Mount, Instrument Panel & Switch Mount, Electrical Wiring - Front Chassis, Electrical Wiring - Rear Chassis, Electrical Wiring - Floor Board, Electrical Wiring - Cab, Electrical Parts, Electrical Wiring - Heater, Dynamic Damper - Electrical Wiring, A Alternator, High Power Horn Mount, Front Lamp Mount | |
| Rear Axle, Differential & Brakes | Rear Axle, Rear Differential, Brake Line, Parking Brake | |
| Front Axle & Steering | Second Propeller Shaft, Third Propeller Shaft, Front Axle, Front Differential, Steering Wheel Mount, Steering Shaft, Steering Cylinder, Loading Hydraulic Line - Steering Cylinder | |
| Hydraulics & 3-Point Hitch | Lift Arm, Grease Piping, Master Cylinder, Valve Control, Loading Hydraulic Line - Front Chassis, Loading Hydraulic Line - Rear Chassis, Control Valve, Lift Cylinder, Tilt Cylinder, Hydraulic Line - Bucket, Oil Cylinder, Bucket Cylinder Cover, Hydraulic Line, Lift Arm - Reinforced, Lift Arm - Semi-Long, Hydraulic Line - Semi-Long | |
| Loader, Backhoe & Attachments | Bucket Positioner, Bucket, Bucket Option Parts | |
| Body & Operator Station | Front Chassis, Rear Chassis, Oil Tank, Floor Board, Seat Stand & Control Box Mount, Deck & Fender, Step & Handrail, Seat, Awning & Cover, Cab Mount, Cab, Front Wiper & Wind Washer, Mirror, Cab Option Parts, Air Duct, Air Duct Group - Floorboard | |
| Other Components | Pin Mount, Center Pin, Operation Stand, Rear Grill, Sponge Mount, Wind Shield, Suspension, Power, Drain Line, Water Line, Exhaust, Torque Converter, Repair Kit, Axle Support, Tire & Disc Wheel, Orbitrol |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| 70A Alternator | 70A | p. 473 |
| Bulb (Front Lamp) | 24V62W/62W | p. 99 |
| Bulb (Rear Lamp) | 24V62W/62W | p. 101 |
| Bulb (Instrument Panel) | 24V1.4W | p. 105 |
| Bulb (Front Wiper) | 24V10W | p. 295 |
Kawasaki 50ZV Common Problems This Manual Covers
Kawasaki 50ZV shift lever assembly and control cable part numbers hard to find in the parts book
Check the Shift Lever Group exploded view starting on page 202 for the shift lever assembly, control cable assembly, plate and pin. Match each reference number to its line in the parts list before ordering. Also confirm your serial number against the serial number plate callout in the Marking Group on page 262.
Manual Section: Shift Lever Group p. 202Friction disc and separation disc part numbers unclear for a reverse and first clutch pack rebuild
Check the Reverse & First Clutch exploded view on page 156 for the friction disc, separation disc, piston assembly and piston rings. Look through the Repair Kit listing on page 164 before ordering individual parts. Then confirm that the transmission assembly callout on page 142 matches the unit in your machine.
Manual Section: Reverse & First Clutch p. 156Correct 70A alternator part number unclear when ordering a replacement charging unit for the loader
Check the A Alternator group on page 473, which lists the 70A alternator as part 50401-02200. Check the fuse and cable callouts in the same group before you place the order. Then match your machine's serial number to the serial number plate shown in the Marking Group on page 262.
Manual Section: A Alternator p. 473Front and rear lamp replacement bulbs needed, but the correct 24V bulb part number is unclear
Check the Front Lamp Group parts list on page 99: the 24V62W/62W bulb is part 38480-70020 and the 24V25W bulb is 38480-70930. For the rear lamps, page 101 lists 38480-70020 again, plus 73200-24014 (24V25W), 73200-24015 (24V25/10W) and 73200-24009 (24V12W).
Manual Section: Front Lamp Group p. 99Lift cylinder or tilt cylinder seal kit part number unclear on machines fitted with a high lift arm
Check the Lift Cylinder exploded view on page 248 and the Tilt Cylinder view on page 250 for the seal kit, piston, rod, cover and bushing callouts. If the loader has the high lift arm, use the tilt cylinder seal kit on page 382. For the long arm version, use page 406.
Manual Section: Lift Cylinder p. 248Orbitrol seal kit and steering cylinder part numbers hard to locate before a steering system rebuild
Check the Orbitrol exploded view on page 218 for the seal kit, bearing kit, rotor assembly, shaft and springs. For the steering cylinder, identify the head, bushing, piston, ring and rod on page 222. The mounting pins, liners and grease nipples are listed in the Steering Cylinder Group on page 216.
Manual Section: Orbitrol p. 218Frequently Asked Questions
What is the replacement part number for the air cleaner element?
The replacement part number for the air cleaner element is 30981-70460, as specified in the Air Cleaner Group section. p. 431
What is the part number for the 70A alternator?
The part number for the 70A alternator is 50401-02200. p. 473
What is the part number for the engine oil filter?
The engine oil filter element part number is 30981-70350, as specified in the Oil Tank Group section on page 61. p. 61
What is the part number for the brake fluid?
The part number for the brake fluid is 41262-70020, which is supplied in a 1L container. p. 274
What is the part number for the 24V 10W bulb used in the front wiper and window washer group?
The part number for the 24V 10W bulb is 38480-70630. p. 295
Do I get instant access to this Kawasaki 50Z V Parts Catalog?
You download the Parts Catalog yourself: 554 pages, searchable PDF, available immediately. Keep a copy on every device you use.
Can I print specific sections of this Kawasaki 50Z V Parts Catalog?
Zero restrictions. The PDF is DRM-free. Print whatever sections you need to take out to the shop. Standard letter or A4 paper works.
