OEM #DS35-W00 documents the CK22 and CK22H down to factory spec across 332 pages. Hydraulic schematics trace the full steering circuit, HST transmission, and 3-point hitch lift; wiring diagrams map every circuit and component location for both models. The reference depth is where it earns its keep: step-by-step procedures, torque tables, and troubleshooting charts running from clutch and transmission through HST, rear axle, brakes, and front axle. Head bolts torque to 58.8 to 63.7 Nm, connecting rod bolts to 29.4 to 34.3 Nm, and those figures sit in the tables rather than buried in a forum thread. When the machine is down, you want the right answer on the first try. Chapter bookmarks and keyword search let you pull it up on your phone right at the tractor.
What's Inside This Kioti CK22, CK22H Manual
| System | Pages | Key Topics |
|---|---|---|
| General | 15-50 | Tractor Identification, Dimensions, Specifications, Lubricants, Fuel and Coolant |
| Engine-1 | 51-128 | Engine Identification (Engine Epa Decal, Bar Code for Engine Number, Engine Number Assignment Standard), Specifications (Performance Curve, Dimensions, Service Specifications) |
| Engine-2 | 129 | Cylinder Block, Cylinder Head |
| Clutch | 130-141 | Specifications, Operation Principle, Troubleshooting, Checking and Adjustment (Clutch Pedal Play Adjustment, Clutch Pedal Stopper Bolt, Safety Switch) |
| Transmission | 142-183 | Operating Principle, Power Train Diagram, Power Train, Transmission Shift Linkage Structure, Differential Gear, Power Steering Unit, Propeller Shaft, Step |
| Transmission-2 | 184-185 | Operating Principle, Power Train Diagram, Ck22, Ck22H |
| HST-1 | 186-204 | Specifications, Operating Principle (Power Train Diagram, Structure, Functions of Each Component, Operation Control), Troubleshooting (Hydrostatic Transmission) |
| HST-2 | 205 | Operating Principle, Power Train Diagram, Hydraulic Transmission Section |
| HST-3 | 206 | Servicing, Body |
| Rear Axle | 207-218 | Specifications, Operating Principle (Power Train, Principle of Differential System, Differential Lock System), Troubleshooting |
| Brake | 219-228 | Specifications, Operating Principle (Structure, Features of Wet Disc Brakes), Troubleshooting, Servicing (Disassembling and Assembling, Inspection for Overhaul) |
| Front Axle | 229-250 | Specifications (Service Specifications), Operating Principle (Front Axle Structure, Wheel Alignment, Differential System), Troubleshooting |
| Steering | 251-278 | Specifications, Operating Principle (Hydraulic Schematic, Hydraulic Circuit Diagram, Operation, Operating of Steering Unit, Steering Cylinder, Gear Pump), Troubleshooting |
| Hydraulic-1 | 279-329 | Control (Mls) Valve, Operating Principle, Hydraulic Scheme, Hydraulic Circuit Diagram (Ck22/Ck22H), Oil Filter, Hydraulic Block, Joystick Valve, Auxiliary Control Valve (If Equipped) |
| Hydraulic-2 | 330 | Hydraulic Circuit Diagram, Manual, HST Specification, Steering Cylinder, Power Steering Unit |
| Electric | 331-332 | Circuit and Component Location, Circuit Diagram, Electric Component Location (Engine, Interior Electric Components, Instrument Panel) |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Head bolt, nut torque | 58.8 ~ 63.7 Nm (6.0 ~ 6.5 kgf-m, 43.4 ~ 47.0 lb-ft) | p. 62 |
| Bearing case bolt 1 torque | 29.4 ~ 34.3 Nm (3.0 ~ 3.5 kgf-m, 21.7 ~ 25.3 lb-ft) | p. 62 |
| Wheel bolt torque | 83 Nm (8.5 kgf-m, 62 lb-ft) | p. 30 |
| Wheel nut torque | 68 Nm (7 kgf-m, 50 lb-ft) | p. 30 |
| HST hydraulic filter Min. Pore Dia | 62 ± 6 | p. 281 |
| Oil filter replacement interval | after 200 hours of use | p. 284 |
| Engine oil filter replacement interval | 50 hours (first), then 100, 200, 400, 600, 800, 1500, 3000 hours | p. 24 |
| Fuel filter element replacement interval | 50 hours (first), then 100, 200, 400, 600, 800, 1500, 3000 hours | p. 24 |
| Air cleaner element cleaning interval | 50 hours (first), then 100, 200, 400, 600, 800, 1500, 3000 hours | p. 24 |
| Air cleaner element replacement interval | 200 hours (first), then 800, 3000 hours | p. 24 |
| Battery type | 70D23L, DF65D | p. 34 |
| Battery voltage | 12 V | p. 34 |
Kioti CK22, CK22H Common Problems This Manual Covers
Kioti CK22 cranks but won't start, or fires hard after sitting with full tank
Start in the engine troubleshooting section. Confirm the 20 L tank isn't dry, then bleed air from the fuel lines and swap the fuel filter element if it's due at the 50-hour interval. Test each glow plug for resistance: a cold-weather no-fire traces almost always to the glow system or fuel delivery.
Manual Section: Engine TroubleshootingHydraulic loader arms move slowly, chatter between cycles, or stop responding under load p. 303
Confirm hydraulic fluid sits at the full mark. Replace the oil filter at 200 hours per the interval on page 284. Inspect every suction line and fitting for air ingestion: chattering cylinders trace to aerated fluid upstream of the pump. Work the hydraulic troubleshooting section from page 303 to separate valve faults from pump wear.
Manual Section: Hydraulic System TroubleshootingHST transmission loses drive in one direction or neutral position creeps forward p. 197
Open the HST troubleshooting in Chapter 5 at page 197 for one-direction and neutral-drift faults. On the CK22H, check that transmission fluid reaches the 18.5 L mark (page 40); low fluid brings on neutral drift before full drive loss. A clogged filter starves the pump and shows first as sluggish response, so replace it at 200 hours per page 284.
Manual Section: HST TroubleshootingEngine temperature climbs under load or tractor overheats in warm working conditions p. 24
Compare coolant level against the 5.7 L capacity (page 20) and inspect hoses for leaks. Clear debris from the radiator fins with compressed air. Verify fan belt deflection is 8 mm at 78.5 N (page 85). Check radiator hoses on the 2-year schedule from page 38, and replace them at the 800 or 3000-hour intervals listed on page 24: slow loss from a cracked hose only surfaces under sustained load.
Manual Section: Chapter 1 GeneralClutch pedal slips under load, chatters on engagement, or drags and won't release p. 130
Adjust clutch pedal free play to 20-30 mm with the pedal stopper bolt procedure on page 32. Inspect the disc for oil contamination, since any upstream seal leak has to be fixed before the adjustment will hold. The clutch system is detailed from page 130. Disc wear shows up as slip that worsens as the engine reaches operating temperature.
Manual Section: Clutch TroubleshootingFrequently Asked Questions
What are the replacement specifications for hydraulic filter?
The hydraulic filter is a canister type, due for replacement every 200 hours of use. Staying on that interval keeps performance steady and stops contamination from building up in the hydraulic system.
What are the replacement specifications for engine oil filter?
Per the maintenance schedule, the engine oil filter gets replaced every 200 hours. With the new filter installed, oil capacity comes to 2.6 liters (0.69 U.S. gal.).
How quickly can I access this Kioti CK22, CK22H manual after buying?
Download starts the moment checkout completes: a 332-page searchable PDF. Open it on a laptop, tablet, or phone and carry it straight to the shop floor.
Can I print this Kioti CK22, CK22H manual?
Yes. Print as many copies as you like, with no restrictions. Plenty of mechanics print just the section they need and keep it at the bench.
Document Quality
This document is a scanned PDF with an OCR layer, allowing you to search and copy text. While the OCR is mostly accurate, some original text can appear slightly faded or less crisp due to the scanning process. Diagrams and illustrations are raster images, which may pixelate when zoomed, but their labels are generally readable. The pages are clean with minimal scan artifacts, though some blank pages are included as separators.
