This Kubota Workshop Manual covers the F2890 and F3690 front mowers together with the RCK60P-F39, RCK60R-F36, RCK72P-F39 and RCK72R-F36 mower decks. It is a 333 page factory service document (publication 9Y111-09174) for machines built around the D1105 and V1505 diesel engines.Inside you get the full repair picture: engine overhaul, the hydrostatic transmission, front and rear axles, brakes, steering, the hydraulic implement circuit, and the electrical system with wiring diagrams, plus dedicated mower deck servicing. Torque values, servicing specifications, troubleshooting charts and step by step adjustment procedures run throughout.With this PDF an owner or independent mechanic can trace a fault, set a blade to the correct torque, chase down an electrical problem, or rebuild a subsystem without guessing. Download it once and keep it on your phone, tablet or shop computer for reference during any job.
What's Inside This Kubota F2890–F3690 Package Manual
| System | Pages | Key Topics |
|---|---|---|
| Information | - | Machine (Safety First, Safety Decals, Specifications, Dimensions), Safety First (Before You Start Service, Start Safely), Operate Safely, Keep a Good Airflow in the Work Area |
| General | - | Identification (Engine and Model Serial Numbers), Handling Precautions for Electrical Parts and Wiring (Battery, Fuse, Connector, Handling of Circuit Tester, Color of Wiring) |
| Engine | - | Engine Body (Closed Breather, Half-Floating Head Cover), Lubricating System, Cooling System, Fuel System (Governor) |
| Transmission | - | Structure, Power Train (Hydrostatic Transmission), Range Gear Shift Section, Rear Wheel Drive Section (Dual-Acting Overrunning Four Wheel Drive), PTO Section |
| Front Axle | - | Structure (Four Wheel Drive Model), Troubleshooting, Servicing Specifications, Tightening Torques, Checking, Disassembling and Servicing (Preparation, Disassembling and Assembling) |
| Brakes | - | Structure, Operation, Troubleshooting, Servicing Specifications, Tightening Torques, Checking, Disassembling and Servicing (Checking and Adjusting, Disassembling and Assembling) |
| Rear Axle | - | Structure (Four Wheel Drive Model), Troubleshooting, Servicing Specifications, Tightening Torques, Checking |
| Steering | - | Structure, Steering Controller, Troubleshooting, Servicing Specifications, Tightening Torques, Checking |
| Hydraulic System | - | Hydraulic Circuit, Hydraulic Pump, Flow Priority Valve, Relief Valve, Implement Control Valve, Feedback Linkage, Hydraulic Cylinder |
| Electrical System | - | Wiring Diagram, Starting System (Operator Presence Control System), Meter Panel (Easy Checker™, Service Code Display, Error Code Display) |
| Mower | - | Mower Identification, Lubricant, Tightening Torques (Metric Screws, Bolts and Nuts, American Standard Screws, Bolts and Nuts with Unc or Unf Threads), Plugs, Maintenance Check List |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Mower blade mounting screw torque | 98.1 to 117.7 N·m (10.0 to 12.0 kgf·m, 72.3 to 86.8 lbf·ft) | p. 309 |
| Mower blade replacement condition | Replace if worn or cracked | p. 309 |
| Spindle shafts lubrication | Multi-purpose EP2 grease (NLGI Grade No. 2) | p. 305 |
| Fuse capacity (ACC) | 5 A | p. 278 |
| Fuse capacity (Head lights, Fuel pump) | 10 A | p. 278 |
| Battery type | 80D26R | p. 28 |
| Battery CCA (SAE) | 582 CCA | p. 28 |
| Electrical connector condition check (female connector) | Make sure that there is no female connector being too open. | p. 29 |
| Electrical connector condition check (plastic cover) | Make sure that plastic cover is large enough to cover whole connector. | p. 29 |
Kubota F2890–F3690 Package Common Problems This Manual Covers
Mower deck will not engage
The deck fails to engage or cuts in and out under load. This usually points to PTO control, wiring, connector or fuse faults, which the Electrical System section walks through with the operator presence circuit and wiring diagrams.
Manual Section: Electrical System p. 261Uneven cut or scalping
Poor cut quality, uneven deck height or scalping often traces to worn blades, spindle wear or setup that has drifted out of spec. The Mower section covers blade servicing, mounting torque and deck maintenance.
Manual Section: Mower p. 301Weak or lost hydrostatic drive
The mower travels weakly or will not move normally, commonly from fluid condition, air in the system or wear in the hydrostatic drive. The Transmission section details the power train and hydrostatic transmission for diagnosis.
Manual Section: Transmission p. 132Hard starting or stalling
The engine starts poorly, stalls or runs unevenly. The Engine section covers the fuel system, governor and related checks needed to isolate a running fault.
Manual Section: Engine p. 71Slow or weak implement lift
The implement lifts slowly or not at all, often from a control valve, relief valve or pump issue. The Hydraulic System section covers the circuit, pump, flow priority valve and implement control valve.
Manual Section: Hydraulic System p. 239Deck vibration and noise
Excessive vibration or unusual noise from the deck usually comes from loose fasteners, worn spindle bearings or damaged blades. The Mower section provides tightening torques and blade inspection to correct it.
Manual Section: Mower p. 301Frequently Asked Questions
Which machines does this manual cover?
It covers the Kubota F2890 and F3690 front mowers plus the RCK60P-F39, RCK60R-F36, RCK72P-F39 and RCK72R-F36 mower decks, under publication number 9Y111-09174.
Which engines are covered?
These machines are powered by the Kubota D1105 and V1505 diesel engines. Engine and model serial number identification is documented in the General section. p. 21
Does it give the mower blade mounting torque?
Yes. The Mower section lists the mower blade mounting screw torque as 98.1 to 117.7 N-m, along with lubricant and maintenance details for the deck.
Are wiring diagrams included?
Yes. The Electrical System section includes the wiring diagram, starting system, operator presence control and the meter panel with service and error code displays. p. 261
How will I receive this Kubota F2890 & variants Workshop Manual?
Instant PDF download. You get the full 333-page searchable Workshop Manual immediately after payment. Open it on your laptop, tablet, or phone right in the shop.
Am I able to print pages from this Kubota F2890 & variants manual?
Yes. The PDF has no DRM restrictions, print any page or section you need for your shop. Works with any standard printer.
Are there hydraulic schematics in this Kubota F2890 & variants manual?
Included. Hydraulic system schematics cover all circuits, control valves, and component specifications for the Kubota F2890 & variants.
