This 816-page New Holland T2210, T2220, Boomer 2030, Boomer 2035 Repair Manual (OEM #84122964) covers all fifteen sections, from clutch and gear transmission down to the hydrostatic drive and final platform teardown. Inside you get wiring diagrams for the full electrical system, hydraulic schematics covering the gear pump, control valve manifold, and remote valves, plus a heavy troubleshooting section for chasing faults across the engine, brakes, and steering. You also get torque tables for every major assembly and the fluid capacities you need before you crack a case open. Set your relief valve to 147 ± 5 bar and confirm pump capacity at 27 L/min before you button the hydraulic system back up. No more flipping between three PDFs to find one spec. This one's bookmarked by section, so you jump straight to Gear Transmission or Electrical without scrolling past 800 pages of someone else's problems.
What's Inside This New Holland T2210, T2220, BOOMER 2030, BOOMER 2035 Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| General Information | 41-68 | Precautionary Statements, Decals, International Symbols, Specifications, General Dimensions, Minimum Hardware Tightening Torques |
| Engine | 69-190 | Specifications, Bolt Torque Specifications, Troubleshooting, Overhaul, Engine Lubrication System, Cooling System, Fuel System |
| Clutch | 191-212 | Troubleshooting, Specifications, Special Tools, Clutch Operation, Clutch Adjustments, Clutch Overhaul |
| Gear Transmission | 213-260 | Specifications, General Bolt Torque Specifications, Special Tools, Description of Operation, Overhaul, Transmission/Differential |
| FWD Axle | 261-320 | Specifications, Torque Specifications |
| Differental, Rear Axle | 321-344 | - |
| Hydrostatic Transmission | 345-418 | - |
| Power Take-Off Systems | 419-436 | - |
| Brakes | 437-448 | Parking Brake, Brake Adjustment, Brake Discs, Stators, Brake Cam |
| Hydraulic System | 449-504 | Hydraulic Fluid Filter, Combination System Relief - Diverter Valve Manifold, Control Valve (Hpl), Lift Cylinder, Hydraulic Pump, Remote Valves |
| Steering Systems | 505-562 | Power-Steering Control Motor, Gerotor Pump, Power Steering Pump, FWD Steering Cylinder, SuperSteer Steering Cylinders, Steering Column |
| Wheels and Tires | 563-570 | FWD Tread Setting, Rear Axle Tread Setting, Tractor Weighting, Rear Wheel Weight Installation, Liquid Ballast, Tire Pressure |
| Electrical System | 571-790 | Battery, Fuse Block, Key Switch, Light Switch, Relays, Engine Sensors |
| Platform | 791-816 | Hood, Rear Hood Panels, Dash Console, Seat, ROPS, Fenders |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Fuel Injection Pump Installation | 58 | p. 6 |
| Hydraulic Pump Type | Gear | p. 452 |
| Pump Capacity | 27 L/min (7.2 gpm) | p. 452 |
| System Relief Valve Setting | 147 ± 5 bar (2133 ± 70 psi) | p. 452 |
| Safety Valve Setting | 250 ± 20 bar (3625 ± 290 psi) | p. 452 |
| Lift Cylinder Diameter | 70 mm (2.76") | p. 452 |
| Maximum Lift Capacity | 1290 kg (2865 lbs) | p. 452 |
| Pressure setting | 147 ± 5 bar (2133 ± 70 psi) | p. 452 |
| Remedy for implement fails to lift when lever is in raised position | Adjust external and internal linkage | p. 466 |
| Pressure change per shim | 7.0 bar (100 psi) | p. 468 |
| T2210/2220, Boomer 2030/2035 | ||
| Pump Flow | 27.0 (7.2) LPM (GPM) | p. 470 |
| T2210/Boomer 2030 | ||
| Engine Gross Horsepower | 23.1 kw (31 hp) | p. 74 |
New Holland T2210, T2220, BOOMER 2030, BOOMER 2035 Common Problems This Manual Covers
New Holland T2210 hydraulic lift fails to raise rear implement after 200 hours of use
Check the hydraulic troubleshooting chart on page 466 first: verify external and internal lift linkage adjustment before tearing into the pump. Confirm system relief valve holds 147 bar (2133 psi); if it drifts, add or remove shims at 7.0 bar (100 psi) per shim on page 468. Pump should flow 27 L/min (7.2 gpm) at 2370 rpm, so a weak flow reading points to a worn gear pump, not the valve.
Manual Section: Hydraulic System Troubleshooting p. 466Grinding or whining noise from gear pump with weak or no flow to lift cylinder
Verify pump speed reaches 2370 rpm and output holds 27 L/min (7.2 gpm) on page 452; anything noticeably lower means internal gear wear. Pull the pump and inspect the gear set and housing bore for scoring. Check the lift cylinder bore for scuffing too, since it's 70 mm (2.76 in) diameter and a damaged bore will mask itself as a pump fault. Replace the pump if flow can't be restored.
Manual Section: Hydraulic Pump p. 452Engine shuts down unexpectedly under load with no error code displayed
Work through the engine troubleshooting index for stalling under load. Check the fuel injection pump seal and mounting torque, spec'd at 39-44 N·m (29-33 ft-lbs) on page 171, for a leak that starves fuel at high demand. Test the engine speed sensor wiring and connector for intermittent contact, since a failing CR sensor can drop signal only under vibration and load without tripping a stored code.
Manual Section: Engine General TroubleshootingTransmission slips or won't engage properly when switching into 4WD mode
Check FWD axle troubleshooting for shimmy or engagement complaints tied to the front differential. Inspect the 4WD engagement solenoid wiring and connector for corrosion or a weak ground. Drain and inspect transmission/hydraulic fluid condition, since the rear axle and HST system holds 33.3 liters and low or contaminated fluid causes clutch pack slip before you ever suspect the solenoid itself.
Manual Section: FWD Axle TroubleshootingStarter cranks slowly or engine won't turn over in cold weather
Check battery state of charge and terminal connections before condemning the starter. On T2210/Boomer 2030 units the starter is rated 1.7 kW (2.3 hp), while T2220/Boomer 2035 units carry a 2.0 kW (2.7 hp) starter on page 765, so confirm you're testing against the correct spec for your model. Verify alternator output holds 12 volt/40 amp on page 743, since a weak charging circuit will mimic a bad starter in cold starts.
Manual Section: Starter Motor TroubleshootingHydraulic fluid overheats during extended loader or implement use
Check fluid level and condition in the combined rear axle/HST reservoir, which holds 33.3 liters, on page 54. Inspect the hydraulic filter for restriction and confirm system relief is holding at 147 bar (2133 psi), not bypassing continuously and generating heat. If pressure creeps toward the safety valve setting of 250 bar (3625 psi), the relief valve is stuck and needs to be pulled and cleaned.
Manual Section: Hydraulic System Troubleshooting p. 466Frequently Asked Questions
What are the torque specifications for the New Holland T2210 engine bolts?
The engine bolt torque specifications for the T2210/T2220/Boomer 2030/Boomer 2035 models include: Connecting Rod Cap Nuts at 49-54 N·m (36-40 ft-lbs), Main Bearing Retaining Bolts at 49-54 N·m (36-40 ft-lbs), and Cylinder Head Bolts at 98-103 N·m (72-76 ft-lbs). p. 82
What are the replacement specifications for the hydraulic pump for models T2210/2220, Boomer 2030/2035?
The hydraulic pump for these models has a flow of 27.0 Lpm (7.2 gpm). The manual states that only the shaft seal and internal O-rings are serviceable; if troubleshooting indicates a faulty pump, the entire pump should be replaced with a new assembly. p. 485
What are the replacement specifications for the fuel injection pump seal kit?
The manual states that if a fuel injection pump is suspected of being faulty, it should be tested and repaired by an authorized Diesel Service Station only. During the tractor warranty period, if the injection pump is diagnosed as faulty, it should be replaced entirely and not repaired. p. 169
What is the engine oil capacity for the New Holland T2210/Boomer 2030 with a filter?
The engine oil capacity for the New Holland T2210/Boomer 2030 with a filter is 4.0 liters (4.2 U.S. qts). p. 54
What do I get after purchasing this New Holland T2210, T2220, Boomer 2030?
You get a 816-page searchable PDF that downloads instantly after checkout. Open it on your laptop, tablet, or phone, and bring it right to the shop floor.
Can I print specific sections of this New Holland T2210, T2220, Boomer 2030?
Yes. The PDF has no DRM restrictions, so print any page or section you need for your shop. Works with any standard printer.
Can I find wiring schematics in this New Holland T2210, T2220, Boomer 2030?
Yes, full electrical schematics are included with wire colors, connector locations, and circuit descriptions.
