This is the full factory repair manual for the New Holland TR96, TR97 and TR98 twin rotor combine harvesters, the same service information a dealer technician works from. It covers the whole machine: the engine, the hydrostatic ground drive and traction, the grain header and feeder, the twin rotor threshing and separation, the cleaning shoe and fan, the grain tank and unloading, the straw chopper and spreader, the working hydraulics, and a full electrical section with the wiring diagrams and monitors. Every section carries the specifications, functional adjustments, fault finding and step-by-step overhaul procedures, so you can chase a threshing, feeder or electrical problem and put it right instead of guessing.
What's Inside This New Holland TR96, TR97, TR98 Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction and Specifications | General Instructions, Safety, Machine Specifications and Capacities, Standard Torques, Special Tools, Model Coverage TR96 TR97 TR98 | |
| Engine | Diesel Engine Description and Specifications, Cylinder Head and Block, Cooling and Lubrication, Fuel Injection, PTO Shaft Drive, Troubleshooting, Overhaul | |
| Traction and Transmission | Hydrostatic Ground Drive, Traction Gearbox, Final Drives, Ground Speed Control, Description and Operation, Fault Diagnosis, Overhaul | |
| Header and Feeder | Grain Header, Cutterbar, Reel and Auger, Feeder House and Conveyor, Feeder Width by Serial Number, Drive, Adjustment, Overhaul | |
| Twin Rotor Threshing and Separation | Rotor Cage and Rasp Bars, Concaves and Grates, Rotor Speed, Functional Adjustment, Wear Parts, Overhaul | |
| Cleaning | Cleaning Shoe, Sieves and Chaffer, Cleaning Fan and Airflow, Returns and Tailings, Grain Loss Checks, Functional Adjustment, Overhaul | |
| Grain Handling and Storage | Grain Tank, Filling and Unloading Augers, Unloading Tube Drive, Grain Tank Capacity, Clean Grain and Returns Elevators, Overhaul | |
| Straw Chopper and Spreader | Straw Chopper and Knives, Chaff and Straw Spreader, Drive and Clutch, Spread Pattern Adjustment, Overhaul | |
| Hydraulic System | Working Hydraulics, Header Lift and Reel, Unloading and Steering Circuits, Pump and Valves, Pressure Testing, Fault Diagnosis, Overhaul | |
| Electrical System | General Electrical, Wiring Diagrams, Starting and Charging Systems, Battery, Monitors and Sensors, Lighting, Warning Systems, Fault Diagnosis | |
| Air Conditioning and Cab | Operator Cab, Air Conditioning and Heating, Compressor and Pressure Switches, Controls and Instruments, Fault Diagnosis, Service |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All models | ||
| Threshing System | Twin Rotor threshing and separation | |
| A/C Low Pressure Safety Switch | 4 psi (0.27 bar) | |
| A/C High Pressure Safety Switch | 365 psi (24.8 bar) | |
| TR96 | ||
| Feeder Width | 48 in (122 cm) below serial break, 40 in (102 cm) above | |
New Holland TR96, TR97, TR98 Common Problems This Manual Covers
Poor threshing, high grain loss or grain damage.
The Twin Rotor Threshing and Separation section covers the rotor speed, concave clearance and rasp-bar condition with the functional adjustments and grain-loss checks to balance a clean sample against grain damage.
Manual Section: Twin Rotor Threshing and SeparationFeeder or header slugs, slips or feeds unevenly.
The Header and Feeder section covers the feeder conveyor and drive, the reel and auger timing and the slip clutch, with the adjustments and overhaul to stop the slugging and uneven feeding.
Manual Section: Header and FeederDirty grain sample or grain loss over the shoe.
The Cleaning section covers the sieve and chaffer settings and the fan airflow with the functional adjustments and grain-loss checks to get a clean sample and keep the losses down.
Manual Section: CleaningAir conditioning cuts out or will not cool.
The A/C pressure switches (low 4 psi, high 365 psi) protect the compressor. The Air Conditioning and Cab section covers the switch checks, the refrigerant charge and the compressor diagnosis to get the cab cooling again.
Manual Section: Air Conditioning and CabFrequently Asked Questions
Does the manual cover the twin rotor threshing and separation adjustments?
Yes. The Twin Rotor Threshing and Separation section covers the rotor cage and rasp bars, the concaves and grates and the rotor speed, with the functional adjustments and wear-parts replacement to keep threshing clean and cut grain loss.
The feeder or header is giving trouble - what does the manual cover?
The Header and Feeder section covers the cutterbar, reel and auger, the feeder house and conveyor and the drive, with the adjustments and overhaul. It also notes the feeder width change by serial number on the TR96.
Does this manual include the wiring diagrams and electrical diagnostics?
Yes. The Electrical System section carries the general electrical, the wiring diagrams, the starting and charging systems, the monitors, sensors and warning systems so you can trace an electrical fault on the TR96, TR97 or TR98.
The air conditioning is cutting out - what are the switch settings?
The A/C low pressure safety switch is set at 4 psi and the high pressure switch at 365 psi. The Air Conditioning and Cab section covers the compressor, the pressure switches and the diagnosis for an A/C that cuts out.
Which models and threshing type does this manual cover?
It covers the New Holland TR96, TR97 and TR98 twin rotor combines, including the engine, hydrostatic drive, header and feeder, twin rotor threshing and separation, cleaning, grain handling, hydraulics and electrical systems.
How will I receive this New Holland TR96, TR97, TR98 Repair Manual?
A 1865-page Repair Manual in searchable PDF format (281 MB), available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Can I print this New Holland TR96, TR97, TR98 manual?
Yes, print as many copies as you want, and there are no restrictions. Many mechanics print the section they need and bring it to the shop floor.
