Part of the New Holland Operator Manuals.
A warning light comes on in the cab with a loaded baler behind you and nobody to ask until the dealer opens Monday; the 506 pages in this book exist so that moment ends at a page number instead of a guess. It covers the New Holland T6.140, T6.150 and T6.160, publication 47897262, in English.
Controls and Instruments runs through the operator platform, cab air filters, electronic parking brake and the switchgear you use every day. Working Operations covers the automated headland sequences and the display screens behind them. Maintenance holds the service chart, fluid capacities, front axle and hydraulic specifications, and what to do when a warning light comes on.
Thirty-nine bookmarks and a clean section split mean the download opens to the page you need in a minute or two, which is the difference between finishing before the rain and parking the tractor.
What's Inside This New Holland T6.140, T6.150, T6.160 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| General Information | 11-34 | Introduction, Fuel Requirement, Biodiesel Fuel, Change the Engine Oil, Protective Devices, Lubricants and Coolants, Tractor Jacking Points, Capacities |
| Safety Information | 35-70 | Safety Precautions, Safety Decals, Safety Rules, Burn Prevention, Prevention of Fire or Explosions, Fire Extinguisher, Protection Offered by the Tractor, Hazardous Substances |
| Controls and Instruments | 71-154 | Access to Operator's Platform (Introduction, Cab Air Filters, In Cab Storage, Cable and Wiring Routing, Mobile Telephone Usage, Implement Monitor Installation, Cab Air Pressurisation Control) |
| Operating Instructions | 155-168 | Commissioning the Unit (Refueling the Tractor) |
| Transport Operations | 169-172 | Preparing for Road Transport (Carrying the Tractor on a Transporter, Secure the High Visibility Roof Panel), Recovery Transport (Freeing a Stuck Tractor, Towing the Tractor) |
| Working Operations | 173-374 | Automated Headland Functions (Quick Guide, Explanation of Symbols, Recording and Replaying, Recording a Sequence, Replaying a Sequence, Headland Function and Color Display Screen, Deleting a Sequence with Color Display) |
| Maintenance | 375-506 | Maintenance Chart, When the Warning Light Is on (Change the Engine Air Cleaner Outer Element, Drain the Fuel System Water Separator, Check the Brake Fluid Level) |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Front disc to hub nuts | 279 Nm (206 lb ft) | p. 406 |
| Front disc to rim nuts | 250 Nm (184 lb ft) | p. 406 |
| Maximum system pressure at rated engine speed | 210 bar +/- 5 (3045 psi +/- 73) | p. 480 |
| Remote control valves maximum pressure at rated engine speed | 210 bar +/- 5 (3045 psi +/- 72) | p. 481 |
| Transmission/rear axle/hydraulics oil capacity | 62 l (16.4 US gal) | p. 475 |
| Fuel tank capacity | 175 l | p. 387 |
| DEF/AdBlue tank capacity | 37 l | p. 387 |
| Engine oil capacity (including filter) | 10 l | p. 387 |
| 4WD front axle differential oil capacity | 9 l | p. 387 |
| Front PTO gearbox oil capacity | 0.5 l | p. 387 |
| Disc to hub nuts torque | 279 Nm | p. 406 |
| Disc to rim nuts torque | 250 Nm | p. 406 |
New Holland T6.140, T6.150, T6.160 Common Problems This Manual Covers
Dust in the cab and weak airflow
Chaff and field dust pack the cab air filters until the fan moves almost nothing and cab pressure drops, letting dirt in around the door seals. The Controls and Instruments section shows where the filters sit and how the cab air pressurisation control works.
Manual Section: Controls and Instruments p. 71Headland sequence replays out of order
A recorded headland sequence that lifts the hitch or drops the PTO at the wrong point usually means the record run was made at a different speed or the steps were saved in the wrong order. Working Operations walks recording, replaying and deleting a sequence on the color display.
Manual Section: Working Operations p. 173Warning light for water in fuel
Condensation and dirty bulk fuel fill the water separator, and the tractor flags it before the injection system suffers. The Maintenance section covers what to do when the warning light is on, including draining the fuel system water separator and changing the engine air cleaner outer element.
Manual Section: Maintenance p. 375Wheel nuts slacken after changing track width
Wheel hardware left short of spec works loose within a few hours of row work and elongates the mounting holes. Maintenance gives 279 Nm (206 lb ft) for the front disc to hub nuts and 250 Nm (184 lb ft) for the front disc to rim nuts on four wheel drive adjustable front wheels, so you can set them properly instead of guessing.
Manual Section: Maintenance p. 406Remote hydraulics slow under load
Remote cylinders that creep or stall on a heavy implement usually point at pump output or a relief setting rather than the implement itself. Specifications gives a remote control valve maximum pressure of 210 bar (3045 psi) at rated engine speed, which gives you a figure to test against.
Manual Section: Specifications p. 481Front axle overloaded during loader work
A loader and front ballast stack weight onto the front axle faster than owners expect, and steering wear and axle damage follow. Working Operations lists a maximum front axle loading of 4100 kg for continuous operation on the Class 3 4WD axle, and Specifications gives a maximum total operating weight of 9500 kg.
Manual Section: Working Operations p. 361Stuck tractor damaged during recovery
Pulling from the wrong point or towing with the driveline in the wrong state turns a bogged tractor into a transmission repair. Transport Operations covers freeing a stuck tractor, towing it correctly and securing it on a transporter.
Manual Section: Transport Operations p. 169Frequently Asked Questions
Which tractors does this operator manual cover?
It covers the New Holland T6.140, T6.150 and T6.160 tractors, published under New Holland number 47897262. The cover (page 1) lists all three models, and the product, engine, drive line and cab identification pages (pages 15 to 17) show where the serial numbers are stamped so you can confirm your own tractor. p. 1
Does it list fluid capacities for servicing?
Yes. Maintenance gives 10 l of engine oil including filter, 62 l for the transmission, rear axle and hydraulics, 9 l for the 4WD front axle differential, 0.5 l for the front PTO gearbox, a 175 l fuel tank and a 37 l DEF tank. p. 387
Are torque figures included?
Some are. Specifications gives hub stud torques such as 210 Nm (154.9 lb ft) for the eight M16 studs on the 4WD front axle, and Maintenance gives the wheel nut torques on page 406. This is an operator manual, so it carries service torques rather than full engine or transmission overhaul specifications. p. 472
What does it say when a maintenance warning light comes on?
The Maintenance section opens with the maintenance chart and a dedicated part for when the warning light is on, covering the engine air cleaner outer element, draining the fuel system water separator and checking the brake fluid level. p. 375
What do I get after purchasing this New Holland T6.140 manual?
You download the Operator Manual yourself: 506 pages, searchable PDF, available immediately. Keep a copy on every device you use.
Is this New Holland T6.140 Operator Manual printable?
Printing is allowed without restriction. Pull the pages you need for the job and bin them when they get greasy.
