Looking for the original manufacturer procedures to maintain your Quicke front loader? This 84-page Quicke Q20–Q85 series technical manual pdf (OEM #12162217 B) breaks down the complete tool carrier, compact valve, and boom assembly for all Q-Series models. Inside, you get detailed hydraulic diagrams tracking every fluid circuit, plus wiring diagrams for the Electrodrive CDC. Packed with step-by-step troubleshooting, this guide shows you exactly how to rebuild cylinders, replace live third function hoses, and fix internal leakage. Secure the cylinder guide to exactly 49 kpm and verify your Lock & Go screws are tightened to 22 Nm before testing the boom. A dead loader means tractors sitting idle in the yard. Download this bookmarked file directly to your tablet, jump straight to the hydraulic charts, and get your equipment moving again.
What's Inside This Quicke Q 20–85 Series Manual
| System | Pages | Key Topics |
|---|---|---|
| Preface | 5-8 | Loader Identification, Subframe Identification |
| Safety Instructions | 9-14 | General Information, Explanation of Warning Levels, Symbol Explanation, Risk Factors During Service, Location of Warning Decals (Eu), Location of Warning Decals (Na) |
| Description | 15-18 | Definitions, Tool Carrier, Q Compact Valve |
| Installation | 19-34 | Checking the Subframe Hardware, Delta Subframe Preparation, Installing the Loader, Control Cable Replacement, Mounting Instructions, Safety Switch, Diagram, Electrical Circuit |
| Trouble Shooting | 35-44 | Trouble Shooting Compact Valve, Trouble Shooting Electrodrive Cdc, Trouble Shooting Internal Leakage |
| Service | 45-58 | Cylinder, Seal Assembly Replacement, Seal Assembly, Hydraulic Valve, Thermoshock, Replacing Hose Assembly in the Loader Beam, Replacing Live Third Function Hoses |
| Accessories | 59-78 | Hydraulic Locking, Loader Suspension - Soft Drive/Plus Drive, 3Rd Function, 3rd Function “Pilot System”, 4Th Function, Lock & Go, Live Third Valve |
| Data | 79-84 | Lifting Height to Pivot Point, Tipping Angle on Top, Breaking Up Angle at Ground Level, Max Lifting Force, Max Hydraulic Pressure, Loader Weight |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Torque for M20 Grade 8 (Class 10.9) screw | 542.3 Nm (400 lb-ft) | p. 19 |
| Torque for M16 Grade 8 (Class 10.9) screw | 271.2 Nm (200 lb-ft) | p. 19 |
| Torque for M12 Grade 5 (Class 8.8) screw | 94.9 Nm (70 lb-ft) | p. 19 |
| Torque for securing cylinder guide | 49 kpm | p. 47 |
| Torque for Lock & Go screw (Item 5) | 22 Nm | p. 76 |
| Torque for Lock & Go screw (Item 6) | 22 Nm | p. 76 |
| Tightening torque for 1/2" Grade 5 (Class 8.8) Screw | 85 lb-ft | p. 19 |
| Tightening torque for 1/2" Grade 8 (Class 10.9) Screw | 114 lb-ft | p. 19 |
| Control cable screw torque (small) | 5-6 Nm | p. 24 |
| Control cable screw torque (large) | 12.5-13.5 Nm | p. 24 |
| Q20, Q30, Q40, Q35, Q45 | ||
| Accumulator pressure (one accumulator) | 15 bar | p. 62 |
| Q50, Q60, Q65, Q75, Q85 | ||
| Accumulator pressure (two accumulators, first) | 15 bar | p. 62 |
Quicke Q 20–85 Series Common Problems This Manual Covers
Quicke Q20 front loader arms drift down after parking tractor and will not hold position under load p. 43
Inspect the lift cylinders for internal leakage. Refer to page 43 for internal leakage rates. Replace worn piston seals if leakage exceeds allowable limits. Verify the system does not exceed the maximum hydraulic pressure of 2100 Mpa to prevent premature seal failure.
Manual Section: Trouble shootingFront loader does not raise or raises very slowly when operating the main control valve p. 24
Check the control cable connections at the hydraulic valve. Tighten the small control cable screws to exactly 5-6 Nm as detailed on page 24. Verify the tractor hydraulic supply is delivering adequate flow and bleed any trapped air from the lift circuit.
Manual Section: InstallationImplement quick coupler mechanisms sticking and difficulty fully connecting or removing bucket attachments p. 76
Clean dirt and contamination from the attachment interface and coupling system. Inspect the locking mechanism parts for wear. Torque the Lock & Go screws (Item 5) to 22 Nm as shown on page 76 to ensure proper linkage alignment during implement connection.
Manual Section: AccessoriesLoader suspension feels overly stiff or fails to cushion bumps during heavy transport operations p. 62
Test the loader suspension accumulators for proper gas charge. If operating a single accumulator system, verify the accumulator pressure is at exactly 15 bar as specified on page 62. Inspect the Softdrive electrical kit and tighten mounting hardware to ensure secure connections.
Manual Section: AccessoriesFrequently Asked Questions
How do I reset a Quicke loader control system?
To reset the Quicke loader control system, specifically for the Electrodrive CDC, you should restore the factory settings. This procedure is detailed in Manual 12155016. This action can address issues like no function for the boom and bucket, uncontrolled movement, or bad response.
How do I reset a Quicke Q20/Q30/Q40/Q50/Q60 loader after an error?
To reset a Quicke Q-series loader (Q20/Q30/Q40/Q50/Q60) after an error, particularly if it's equipped with the Electrodrive CDC system, you should restore the factory settings. Refer to Manual 12155016 for the specific procedure. This is the initial step for troubleshooting issues like no function for the boom and bucket.
How do I clear Quicke loader fault codes?
To clear Quicke loader fault codes, especially for the Electrodrive CDC system, you should first check the reason for the error code in the error code list, which is found in Manual 12155016. For specific codes like 3+4, they can be deactivated by pressing P5.
What do Quicke loader error codes mean?
The Quicke loader error codes and their meanings are not provided directly in this manual. For detailed information on error codes, you should refer to the error code list found in Manual 12155016.
How quickly can I access this manual after buying?
A 84-page Technical Manual in searchable PDF format, available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Is this Quicke Q20–Q85 Series Technical Manual printable?
Yes, print as many copies as you want, and there are no restrictions. Many mechanics print the section they need and bring it to the shop floor.
Does this Quicke Q20-Q85 Series manual include hydraulic diagrams?
Yes. The manual includes hydraulic flow diagrams and pressure specifications for the Q-Series loaders.
Document Quality
This document is a scanned PDF with an effective OCR layer, so you can easily search and copy the entire text content. The text throughout the manual is consistently crisp and highly readable, ensuring clarity for all instructions. Diagrams and illustrations are clear raster images, and all labels within them are distinct and easy to understand. The pages are clean, presenting no noticeable scan artifacts, stains, or skewed elements. Be aware that pages 2, 4, 8, 44, 58, 81, 82, and 83 are intentionally blank filler pages.
