Every one of the 504 pages in this Takeuchi TB53FR parts manual PDF (OEM #BJ1Z006-1) does one job: put the correct part number for your crawler excavator in your hand before you call the dealer. Exploded views carry full parts lists for the undercarriage, turntable and controls, engine and electrical system, hydraulic piping and tank, cover and cab, hoe attachment, decals and tools, plus the swivel joint and control valves, covering both the 4TNE88-ETBZ and 4TNV88-QTBZ engines. Serial number breaks are called out on every assembly, so you order the right revision for your machine, not the one that almost fits. Shim the front sash at 1.6 mm and the turntable at 1.0 mm; both are identified right in the diagrams. Ordering a slew ring on a guess is an expensive mistake. Bookmarked by system and text-searchable; type the part name, find the number, place the order.
What's Inside This Takeuchi TB53FR Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Undercarriage | 26-51 | Lower Frame, Crawler Belt, Crawler Belt (with Rubber Pads), Carrier Roller (15810005-15810683), Carrier Roller (15810684-), Track Roller, Front Idler, Track Adjuster |
| Turntable & Control Lever | 52-119 | Slewing Device (15810005-15810674), Slewing Device (15810675-), Turntable (15810005-15810674), Turntable (15810675-), Boom Offset (15810005-15810674) |
| Engine & Electrical System | 120-183 | Engine & Accessories, Air Cleaner Element, Drain Plug, Control Box, Engine Control |
| Hydraulic Piping & Tank | 184-213 | Valve & Accessories (15810005-15810674), Valve & Accessories (15810675-), Piping; Upper (15810005-15810674) |
| Cover & Cab | 214-267 | Cover, Engine Hood, Side Cover, Catch, Canopy, Floor Frame, Insulator, Seat Assy |
| Hoe Attachment | 268-323 | Boom (15810005-15810674), Boom (15810675-15810794), Boom (15810795-) |
| Decal & Tool | 324-371 | Decal (for Japan; 15810005-15810674), Decal (for Japan; 15810675-), Decal (Cab) (15810005-15810674), Decal (Cab) (15810675-), Decal (Canopy) (15810005-15810674) |
| Hydraulic Device | 372-475 | Swivel Joint, Control Valve (15810005-15810674), Control Valve (15810675-), Control Valve (with the 2nd Auxiliary Line; 15810005-15810674) |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Bulb (Canopy Light) | 12V, 20W | p. 181 |
| Bulb (Room Lamp) | 12V, 55W | p. 243 |
| Shim (Front Sash) | t=1.6mm | p. 215 |
| Shim (Turntable) | t=1.0mm | p. 57 |
| Shim (Boom) | t=1.0mm | p. 270 |
Takeuchi TB53FR Common Problems This Manual Covers
Takeuchi TB53FR boom pin and bushing part numbers, boom foot has excessive side play
Check the boom exploded views starting on page 268. Boom listings split by serial range (15810005-15810674, 15810675-15810794, and 15810795 onward), so read your serial plate before ordering pins or bushings. Order the boom adjustment shims from the same parts list on page 270; they come in 0.2mm, 0.5mm, and 1.0mm thicknesses to take up side play.
Manual Section: Hoe Attachment p. 268Slewing device and turntable parts lists differ by serial number, unsure which listing applies
Verify your serial number first: the turntable and slewing device carry separate parts listings for 15810005-15810674 and 15810675 onward. Check the exploded views in the Turntable & Control Lever section beginning on page 52, then pull shim quantities from page 57, where turntable shims are cataloged in t=1.0mm, t=1.6mm, and t=2.3mm thicknesses.
Manual Section: Turntable & Control Lever p. 52Cracked front window, can't identify the correct glass and front sash part numbers
Check the Cover & Cab exploded views starting on page 214; the front sash assembly and its hardware are cataloged there by serial range, 15810005-15810674 or 15810675 onward. Order the front sash shims listed at t=1.6mm on page 215 along with the glass so the sash seats and seals correctly after assembly.
Manual Section: Cover & Cab p. 214Canopy work light burned out, need the replacement bulb spec and parts listing
Replace the bulb with the 12V, 20W unit cataloged on page 181 in the Engine & Electrical System parts listings; do not substitute a higher wattage. Note the cab room lamp is a different part, a 12V, 55W bulb listed on page 243, so confirm which lamp you are servicing before ordering either one.
Manual Section: Engine & Electrical System p. 181Frequently Asked Questions
What is the replacement specification for the air cleaner element?
The replacement air cleaner element for the TB53FR (for double element) is part number 19111-02772, which is a Donaldson P82-2858 filter. p. 145
What is the part number for the standard 630mm bucket assembly?
The standard 630mm bucket assembly for the TB53FR is part number 03962-16000. p. 297
What is the part number for the engine oil filter or engine assembly?
The engine assembly for the TB53FR (4TNE88-ETBZ) is part number 19101-64001. p. 121
What is the part number for the travel motor assembly for serial numbers 15810005-15810392?
The travel motor assembly for the specified serial number range is part number 19031-19500. p. 43
What is the part number for the slew motor assembly?
The slew motor assembly is part number 19031-20200. p. 53
