When your material transfer vehicle throws a code and the paving train grinds to a halt, this 456-page Bomag BMF 2500 M service manual PDF (OEM 008 401 56 EN) gives you the factory data to clear the mat. The document maps out the electrical architecture with complete wiring diagrams and CAN bus overviews, while detailed hydraulic schematics route the closed and open loops for the travel and conveyor belt circuits. You can trace faults directly from the display to the component using extensive error code lists and dedicated troubleshooting charts for the MCR conveyor motors. Factory specifications are laid out exactly how you need them, verifying everything from the injector electrical resistance at 3 Ohms to the starter screw tightening torque set at 43 Nm. Waiting on a service truck while the asphalt cools costs money, so load this bookmarked, text-searchable file onto your toughbook and fix the problem right on the grade.
What's Inside This Bomag BMF 2500 M Manual
| System | Pages | Key Topics |
|---|---|---|
| General | 7-62 | Introduction |
| Overview of Machine | 63-78 | Component Overview - Electrics, Component Overview - Hydraulics, Lubrication Points |
| Electric Systems | 79-222 | Wiring Looms, CAN - Overview, Overview, Display (Changing the Diesel Engine Speed, Typical Engine Data), Component Description (Steering Angle Sensor), Bomag Telematic |
| Diesel Engine | 223-318 | Description (Cooling System, Engine Oil System, Air Intake System, Fuel System, Exhaust System, Engine Electrics) |
| Hydraulic System | 319-368 | Open and Closed Hydraulic Circuit, Hydraulic Units (Control Valve Block, Hydraulic Oil Tank, Conveyor Belt Pump H1, Mcr Conveyor Belt Motor), Fan Circuit, Working Circuit |
| Assembly Groups | 369-386 | Hopper (Description), Conveyor Belt (Description, Repair), Cooling System (Description) |
| Troubleshooting | 387-392 | Preliminary Remarks, Emergency Procedures (Actuating the Emergency Stop Switch, Disconnecting the Battery, Towing the Machine) |
| Special Tools | 393-400 | Electrics, List of Special Tools |
| Appendix | 409-456 | Circuit Diagrams |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Starter screw tightening torque | 43 Nm | p. 270 |
| Starter fastening nut M5 tightening torque | 4 Nm | p. 270 |
| Injector sealing ring nominal thickness | 1.5 mm | p. 272 |
| Injector electric resistance | 3 Ohm | p. 275 |
| Valve cover gasket electrical resistance (closed circuit) | < 10 Ohm | p. 287 |
| Cold weather radiator cover opening | 387 cm² [60 in²] | p. 298 |
| Chain lubrication system operating intervals | 3 minute operation, 11 minutes break | p. 375 |
| Hammer weight for conveyor belt repair | 500 g | p. 381 |
| High pressure cartridge tightening torque | 22 Nm | p. 22 |
| Thermostat housing screw tightening torque | 10 Nm | p. 264 |
| Starter M5 nut tightening torque | 4 Nm | p. 270 |
| Starter M10 nut tightening torque | 21 Nm | p. 270 |
Bomag BMF 2500 M Common Problems This Manual Covers
Bomag BMF 2500 M conveyor belt edge damage and material flow interruption under high output
Inspect the belt guides and scrapers for severe wear. Remove damaged sections and install the replacement belt splice using a 500 g hammer as specified on page 381. Verify roller alignment to ensure the belt tracks straight before restarting the paving train.
Manual Section: Assembly Groups p. 381Engine runs rough, lacks power during heavy material transfer, and exhibits unburned fuel smoke
Test the injector electric resistance. Replace the injector if the reading falls outside the 3 Ohm specification found on page 275. Clean the seating surface, install a new 1.5 mm sealing ring from page 272, and torque the feed pipe union nut to 55 Nm.
Manual Section: Diesel Engine p. 275Abnormal grinding noise from the conveyor undercarriage area and dry drive chains during operation
Check the chain lubrication system controller. Verify the timer is set to the correct operating intervals of 3 minute operation, 11 minutes break as detailed on page 375. Fill the reservoir, prime the lines, and confirm oil reaches the roller pins to prevent mid-mat failures.
Manual Section: Assembly Groups p. 375Engine won't crank or turns over slowly when trying to start the machine in cold weather
Confirm the battery voltage and cable connections are solid, then remove the starter and inspect the ring gear. Install the new starter motor and tighten the main mounting screws to 43 Nm as shown on page 270, and secure the M10 fastening nut to 21 Nm to ensure proper ground.
Manual Section: Diesel Engine Troubleshooting p. 270Frequently Asked Questions
What is the tightening torque for the high pressure cartridges when towing the Bomag BMF 2500 M?
When preparing the machine for towing, the counter nut on the high pressure cartridges must be tightened to a torque of 22 Nm. p. 22
What is the tightening torque for M10 screws with strength class 8.8 on the Bomag BMF 2500 M?
For screws with a metric unified thread and a strength class of 8.8, the tightening torque for an M10 dimension is 50 Nm. p. 49
What is the hydraulic oil filter replacement interval on the Bomag BMF 2500 M with bio-degradable hydraulic oil?
The hydraulic oil filter needs replacement at the latest after 500 operating hours whenever the system runs on bio-degradable hydraulic oil. p. 36
What is the tightening torque for the injector feed pipe union nut on the Bomag BMF 2500 M?
Tightening the injector feed pipe union nut requires a torque of 55 Nm during installation. p. 274
What is the tightening torque for the valve cover screws on the Bomag BMF 2500 M?
Mounting the valve cover means tightening the screws from the middle towards the outside to a torque of 24 Nm. p. 290
What format is this Bomag BMF 2500 M manual in?
A 456-page Service Manual in searchable PDF format, available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Can I print this Bomag BMF 2500 M manual?
Yes. No DRM, nothing blocks printing, so run off the pages you need on whatever printer you have.
