All 152 pages of this Case 1370 Operator Manual (OEM #9-4721) are built around one goal: keeping your 1370 Tractor running right, shift after shift. Inside you get the complete operating controls walkthrough, cold-weather starting procedures, Power Shift Transmission sequencing, Draft-O-Matic hydraulic controls, and a full preventive maintenance schedule covering everything from engine oil filters to cooling system thermostat replacement. Fluid specs are spelled out in plain numbers: the Power Shift transmission hydraulic system takes Case TFD Fluid, the oil filters run 10 to 12 micron filtration, and the engine oil drain plug torques to 29-31 ft. lbs. (39-42 Nm). Change your engine oil filter after the first 20 hours, then every 200 hours after that. No more hunting forums for intervals that might not even match your serial number. Pull up the PDF on your tablet, search by keyword, and have the factory answer before you touch a wrench.
What's Inside This Case 1370, 1370 Tractor Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| To the Purchaser of a Case Tractor | 9-10 | - |
| Serial Number | 11 | Engine Serial Number Plate, Cab Serial Number Plate, Transmission Serial Number Plate, Model Designation, Tractor Serial Number, Engine Serial Number |
| Diesel Engine | 12-13 | Firing Order, Piston Displacement, Compression Ratio, Piston and Connecting Rod, Main Bearings, Valve Tappet Clearance |
| General Specifications | 14-23 | Cooling System, Electrical System, Parking Brake, Hydraulic Power Assist Brakes, Power Shift Transmission, Differential Lock, Hydrostatic Power Steering, Draft-O-Matic System |
| Fuel Specifications | 24-25 | Fuel Conditioner |
| Lubrication | 26-35 | Engine Hour Meter, Engine Lubrication, Recommendations and Capacities, Lubrication Chart, Engine Crankcase Oil Change, Engine Oil Filters |
| Implement Warning Lamp | 52-54 | Forward and Rearward Adjustment, Seat Tension Adjustment, Seat Belts |
| Tilt and Telescoping Steering Column | 55-56 | Tilting, Tilt Pedal, Telescoping, Lock Knob |
| Stopping the Engine | 57-61 | Operation of Quick Start Aid, Cold Weather Starting Fluid, Coolant Heater |
| Power Shift Transmission | 62-63 | 3 Speed Power Shift Section, 4 Speed Mechanical Range Section, Inching Pedal, Range Selector Lever, Power Shift Selector Lever |
| Differential Lock | 64-66 | Engaging, Front Wheels, Brake Pedals, Differential Lock Pedal, Disengaging |
| PTO Operating Precautions | 67-70 | Tractor Drawbar, Power Take-Off Driven Machine, Power Take-Off Adapter Guard, Power Take-Off Shaft Assembly |
| Draft Arm Mechanical Flotation | 71 | Draft Arm, Float Lock Pins, Sway Blocks, Anti-Sway Chain |
| Anti-Sway Chain | 71-75 | Draft Arms, Sway Blocks, Spring, Wheels, Rims |
| Remote Hydraulic Control | 76 | Dual Valve, Right Hand Control Lever Operation, Inner Lever, Outer Lever, Couplings |
| Variable Flow Remote Hydraulic Control | 77 | Dual and Variable Flow Valves, Left Hand Control Lever Operation, Inner Lever, Outer Lever, Flow Control Knob, Cylinder Action |
| Remote Hydraulic Cylinder Coupling | 78-83 | Coupling Socket, Dust Plug, Portable Cylinder Hose, Cylinder Hose Lines, Tractor Hose Lines, Pressure |
| Front Axle Adjustments | 84 | Tractor Front End, Drag Link, Axle Tube Extension, Locating Bolts, Tread Spacings, Turning Angle |
| Front End Weights | 85-95 | Rear Wheel Weights, Rear Tire Liquid Weight, Facts About Pressurized Cooling System, Anti-Freeze Solutions |
| Fan Belt Adjustment | 96 | Belt Tension Gauge, Alternator Pulley, Fish Scale, Crankshaft Pulley, Belt Tension, Deflection |
| Replacing Fan Belt | 96-98 | Idler Pulley, Adjusting Plate, Mounting Bolts, Compressor Pulley, Crankshaft Pulley, Adjusting Bolt |
| Preventive Maintenance | 99-138 | Cooling System (Facts About Pressurized Cooling System, Anti-Freeze Solutions, Checking Thermostats, Cleaning the Cooling System, Thermostat Replacement), Fan Belt Adjustment |
| After Delivery Checkup | 143-152 | Brakes, Tire Pressure, Fuel Injection Pump Timing, Cooling System, Belt Adjustment, Crankcase Oil |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Hydraulic fluid type | CASE TFD FLUID | p. 20 |
| Hydraulic oil filter type | 10 to 12 Micron Filtration | p. 24 |
| Engine oil filter replacement interval | After the first 20 hours of operation and each 200 hours of operation thereafter. | p. 28 |
| Engine oil drain plug torque | 29 to 31 ft. lbs. (39 to 42 Nm) | p. 22 |
| Grease type for all pressure fittings | Good No. 1 or a Good No. 2 Lithium Gun Grease | p. 20 |
| Grease quantity for all pressure fittings | As Many Strokes As Required | p. 20 |
| Engine Bore | 4-5/8 inches (117mm) | p. 12 |
| Piston Displacement | 504 cubic inches (8.26L) | p. 12 |
| Power Take-Off Shaft Speed at 2000 Engine RPM | 1000 RPM | p. 16 |
| Engine Crankcase Oil Change Interval | 100 hours | p. 31 |
Case 1370, 1370 Tractor Common Problems This Manual Covers
Case 1370 tractor transmission shifts poorly and hydraulic fluid level fluctuates rapidly on the dipstick. p. 24
Inspect the fluid level and top up with CASE TFD FLUID as specified on page 20. Replace the elements with 10 to 12 Micron Filtration units and torque the filter manifold bolts to 35 to 42 ft. lbs. (48 to 57 Nm) on page 25.
Manual Section: Hydraulic Oil FiltersEngine oil pressure warning light flickers continuously during operation at normal operating temperature. p. 22
Drain the crankcase and verify the 100 hours change interval has not been exceeded. Install a new filter and torque the engine oil drain plug to 29 to 31 ft. lbs. (39 to 42 Nm) as directed on page 22. Refill the system and check for leaks.
Manual Section: Engine Oil Change & FiltersPower take-off driven implement operates sluggishly and fails to reach standard operating speed under load. p. 16
Verify the engine speed is set to 2000 RPM to achieve the required 1000 RPM shaft speed listed on page 16. Inspect the power take-off adapter guard and shaft assembly for binding. Lubricate all pressure fittings with No. 2 Lithium Gun Grease.
Manual Section: General SpecificationsParking brake fails to disengage completely and dashboard warning indicator remains illuminated during travel.
Check the linkage for binding and lubricate all pressure fittings on the assembly with No. 1 or No. 2 Lithium Gun Grease using as many strokes as required. Review the adjustment procedures to ensure the brake mechanism fully releases before operating the machine.
Manual Section: Parking Brake AdjustmentFrequently Asked Questions
How to reset engine error codes on Case 1370
The manual describes a reset button specifically for the air filter restriction indicator. After servicing the safety element, start the engine and press the reset button. If the clear signal appears, the indicator is functioning properly; if the red signal remains, press the button several times, or shut off the engine and consult your Authorized Case Dealer.
How do you fix case 1370 tractor transmission shifts poorly and hydraulic fluid level fluctuates rapidly on the dipstick?
Inspect the fluid level and top up with CASE TFD FLUID as specified on page 20. Replace the elements with 10 to 12 Micron Filtration units and torque the filter manifold bolts to 35 to 42 ft. lbs. (48 to 57 Nm) on page 25.
How do you fix engine oil pressure warning light flickers continuously during operation at normal operating temperature?
Drain the crankcase and verify the 100 hours change interval has not been exceeded. Install a new filter and torque the engine oil drain plug to 29 to 31 ft. lbs. (39 to 42 Nm) as directed on page 22. Refill the system and check for leaks.
How do you fix power take-off driven implement operates sluggishly and fails to reach standard operating speed under load?
Verify the engine speed is set to 2000 RPM to achieve the required 1000 RPM shaft speed listed on page 16. Inspect the power take-off adapter guard and shaft assembly for binding. Lubricate all pressure fittings with No. 2 Lithium Gun Grease.
What format is this manual in?
This is a 152-page searchable PDF ready for immediate download. Works on any device, so pull it up on your phone while you're under the hood. No shipping, no waiting.
Can I print specific sections of this Case 1370, 1370 Tractor Operator Manual?
Yes. The PDF has no DRM restrictions, so print any page or section you need for your shop. Works with any standard printer.
