Need the right part number for your 1996-1998 New Holland 1925 compact tractor? This New Holland 1925 parts catalog PDF packs 220 pages of exploded views covering both the 1925 and the 3 CYL variant, gear and HST alike. You get factory part numbers for every assembly on the machine: front axle, power steering pump, clutch, HST transmission, injection pump, three-point hitch, fenders, and roll bar. A figure search index jumps you straight to the right diagram, and a metric-to-inch hardware table backs up every fastener callout. Clutch shims run 0.2, 0.3, 0.4, and 0.5 mm; order the exact size instead of guessing from a worn part. Stop squinting at corroded castings trying to read a casting number. Bookmarked and keyword-searchable; find the part, copy the number, place the order.
What's Inside This Ford New Holland 1925, 1925 3 CYL Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Fuel System | Fuel Tank & Related Parts, Air Cleaner, Injection Pump & Lines, Injection Pump, Fuel Injector | |
| Cooling System | Oil Pump, Water Pump, Alternator, Radiator | |
| Engine | Cylinder Block, Camshaft, Cylinder Head, Crankshaft & Pistons, Timing Gear Case, Muffler, Engine Gasket Kit | |
| Electrical System | Relay, Diode & Fuse Locations, Lights, Economy, Nh-Na, Switches, Dashboard, Battery, Alternator Assy., Worklights | |
| Clutch & Transmission | Clutch & Clutch Case, W/9 X 3, W/hst, Front Transmission Case & Shifter, Gears, Front Transmission, Rear Transmission Case & Shifter, Rear Transmission Gears, Control Levers, Transmission Range, Rear PTO, Mid PTO & FWD | |
| PTO | Three-Point Hitch Assy., Std. & PTO Shield, PTO Gears, Mid PTO Kit 9 X 3 | |
| Rear Axle, Differential & Brakes | Front & Rear Wheels, Rear Wheel Weights, 75 Lbs., R4, Parking Brake, Nh-Na, Brake & Wheel Shaft Case, Differential & Differential Lock Linkage, Pedals & Brake Lock | |
| Front Axle & Steering | Front Axle, W/FWD, Front Differential Gears, Final Reduction Gears, Steering Column, Fixed, Piping, Steering, Power Steering Case, Power Steering Pump, Power Steering Cylinder | |
| Hydraulics & 3-Point Hitch | Lift Cover & Arms, Lift Cover Head Assy., Control Valve, Quadrant & Linkage L/draft Control, Single Spool Rear, Remote Control Valve Kit, #1, #2, Hydraulic Pump & Piping, Hydraulic Piping, W/hst, Hpl Control Valve Assy., Two-Spool Remote Control Valve & Piping Kit, Prince Valve #Hc-V-AB10 & #Hc-V-AE35, Two-Spool Remote Control Valve Assembly, Deluxe Drawbar Assembly, Drawbar Kits, Hydraulic Pump | |
| Body & Operator Station | Step Plate, Kit, Step, Right Side, Left Side, Floor Mats, Dashboard and Rear Hood, Seat & Seat Belt Set, Economy, Fenders, L.H. & Related Parts, R.H. & Related Parts, Hood and Related Parts | |
| Decals & Accessories | Tool Box, Tool Box Kit & Smv, Decals, Operating, Identification, Warning | |
| Other Components | Front End Weights, Hpl Controls, Deluxe Three-Point Hitch & Kit, Fixed Clevis Hitch, Manifold Diverter Block, Aeration Parts, HST, HST Controls & Cruise Control, Kit, Cruise Control, Throttle Controls, Hand, Throttle Controls - Foot, Electrical - Right Hand Side, Electrical - Left Hand Side, Starting Motor, Instrument Panel, Rigid Roll Bar & Related Parts |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Shim, 0.2mm | 0.2mm | p. 93 |
| Shim, 0.3mm | 0.3mm | p. 93 |
| Shim, 0.2T | 0.2T | p. 105 |
| Shim, 0.5T | 0.5T | p. 105 |
| Fuse, 5 Amp | 5 Amp | p. 158 |
| Fuse, 30 Amp | 30 Amp | p. 160 |
Ford New Holland 1925, 1925 3 CYL Common Problems This Manual Covers
New Holland 1925 clutch slipping, can't identify correct adjustment shim thickness in the parts listing
Measure your old shim with calipers first. The clutch parts list on page 93 catalogs shims in 0.2mm, 0.3mm, 0.4mm, and 0.5mm thicknesses, each under its own part number. Order the size that restores original stack height, then verify the figure reference against the parts number list for your serial range.
Manual Section: Drivetrain Parts Diagram p. 93Transmission parts lookup confusing, step kit and shims buried under unexpected assembly headings
Start with the drivetrain exploded view to locate the correct assembly figure. Transmission shims are cataloged by thickness: 0.2T and 0.5T sizes appear on page 105, the 0.1T size on page 108. Note the figure and reference number, then match it in the parts number list before ordering.
Manual Section: Drivetrain Parts DiagramTractor won't crank, blown fuse suspected, unsure which amp rating fits each holder
Check the electrical parts pages before ordering anything. The 5 Amp fuse is listed on page 158, the 30 Amp and 40 Amp fuses on page 160, and the 7.5, 15, and 20 Amp fuses on page 162. Match each rating to its holder in the exploded view, then pull starting motor part numbers from the same section.
Manual Section: Starting Motor p. 158Hydraulic lift weak, need pump seal and O-ring part numbers before tearing into it
Check the hydraulic parts diagram and locate the pump in the exploded view. Seals and O-rings carry individual reference numbers there; match each one to the parts number list. Measure the old O-ring inside diameter in millimeters with calipers before ordering, since several sizes look nearly identical in the figure.
Manual Section: Hydraulic Pump & PipingFrequently Asked Questions
What are the replacement specifications for the right side step kit?
The right side step kit for the 1530, 1630, 1725, and 1925 models is part number 718709013. It includes four M10 x 1.5 prevailing torque lock nuts (part number 100037), one 9/16" lock washer (part number 280248), one M14 x 1.5 x 30 cap screw (part number 9516470), three M10 x 1.5 x 40 flange head cap screws (part number 9804263), and one M10 x 1.5 x 50 flange head cap screw (part number 9804264). p. 133
What are the replacement specifications for clutch components on the 1925 tractor?
For the 1925 model with a single clutch, the pressure plate is part number SBA320450011 and the clutch disc is part number SBA320400212. The release bearing is part number SBA398560840 and the release hub is part number SBA320310570. p. 98
What is the part number for the engine oil filter?
The engine oil filter for the 1925 tractor is part number SBA140517020. p. 75
What is the part number for the fuel filter element?
The fuel filter element for the 1925 tractor is part number SBA360720020. p. 141
What is the part number for the alternator assembly?
The alternator assembly for the 1925 tractor is part number SBA185046320. p. 170
What format is this New Holland 1925, 1925 3 CYL manual in?
Immediate download of the complete 220-page searchable Parts Catalog. Access it on any device, from a laptop at your desk to a phone in the field.
Is this New Holland 1925, 1925 3 CYL Parts Catalog printable?
Zero restrictions. The PDF is DRM-free. Print whatever sections you need to take out to the shop. Standard letter or A4 paper works.
