Part of the Hitachi Parts Manuals.
Tracking down the correct replacement components is straightforward when you use this complete 371-page Hitachi ex35-2 parts catalog pdf (OEM #P1B5-1-2) to maintain your compact excavator. You get highly detailed exploded views of every single machine system, complete with exact factory part numbers, hardware descriptions, and assembly diagrams. Jump into the hydraulic section to find complete hardware breakdowns for the main piston pump, pilot valves, multi-lever controls, and travel motors. Verify the exact tooth point bolts for your 350mm wide JIS94 bucket, and confirm you have the correct O-rings, dust seals, and bushings sitting on your workbench before tearing down the boom cylinder. Parts counter guesswork wastes your whole afternoon. Download this bookmarked file directly to your phone, search for your specific component by keyword, and order the right hardware the first time.
What's Inside This Hitachi EX35-2 Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Fuel System | Air Cleaner, Fuel Pipings | |
| Cooling System | Radiator, Radiator Support, Reserve Tank | |
| Engine | Muffler, Oil Cooler Pipings, Swing Bearing, Pump;Piston | |
| Electrical System | Gauge Panel, Wire Harness, Valve;Solenoid | |
| PTO | Extra Pipings _PTO_ | |
| Hydraulics & 3-Point Hitch | Pump Device, Pump Device Support, Boom Swing Cylinder, Blade Cylinder, Boom Cylinder, Arm Cylinder, Bucket Cylinder, Valve;Control, Valve;Pilot, Valve;Lock | |
| Body & Operator Station | Frame, Tank, Engine Control Cable, Console _Canopy_, Console _Cab_, Canopy, Floor, Seat, Seat Base, Cover, Track Frame, Ptma Blade Frame, Cab, Cab Parts, Cab Ass'Y, Seat Belt | |
| Decals & Accessories | Tools | |
| Other Components | Counterweight, Protector, Engine, Swing Device, Swing Post, Main Pipings, Engine Control, Console, Control Lever, Control Pedal, Lever Link Support, Lever Link, Pilot Pipings, Pilot Pipings _Jis-Type_, Pilot Pipings _H-Type_, Electric Parts |
Hitachi EX35-2 Common Problems This Manual Covers
Need the correct tooth point and side cutter part numbers for a Hitachi EX35-2 excavator bucket.
Inspect the bucket assembly diagram on page 223. Identify the side cutter and tooth point components. Match the diagram callouts to the parts list to ensure you order the correct mounting bolts for the 300 mm (11.8 in) wide bucket.
Manual Section: Bucket 0.045 _Jis94_ (300Mm Wide_ p. 223Missing the lock pin and tooth point part numbers for the extra wide trenching bucket.
Check the bucket exploded view on page 233. Find the lock pin, nut, and tooth point part numbers in the diagram. Cross-reference the item numbers to verify you are ordering components for the 0.13 cubic meter (650 mm) wide bucket.
Manual Section: Bucket 0.13 _Jis94_ (650Mm Wide) p. 233Cannot identify the correct hydraulic hose and elbow union part numbers for the multi lever valve.
Look at the 014 Way Multi Lever Pipings diagram on page 259. Identify the specific hose, elbow, and clip part numbers required. Ensure you are checking the 14-way (14-port) valve configuration rather than the 12-way version to avoid ordering incompatible fittings.
Manual Section: 014 Way Multi Lever Pipings (4) p. 259Broken crawler tracks require replacement master pins and track shoes for the undercarriage system.
Open the Track-Link 300G diagram on page 173. Locate the specific master pin, bushing, and shoe part numbers in the exploded view. Verify you are ordering replacement components specifically for the 300G (300 mm) track assembly to guarantee proper fitment.
Manual Section: Track-Link 300G p. 173Frequently Asked Questions
What is the part number for the main frame of the excavator?
The main frame for the EX35-2 excavator is identified by part number 5003568. p. 2
What is the part number for the engine oil filter?
The oil filter for the engine is part number 4294838. p. 8
What is the part number for the radiator cap?
The radiator cap is part number 4407714. p. 10
What is the part number for the air cleaner element?
The air cleaner element is part number 4357443. p. 16
What is the part number for the main hydraulic pump?
The standard piston pump is part number 4331671. p. 24
Is this Hitachi EX35-2 Parts Catalog a digital download?
You get a 371-page searchable PDF that downloads instantly after checkout. Open it on your laptop, tablet, or phone, and bring it right to the shop floor.
Are there any print restrictions on this Hitachi EX35-2 manual?
Yes, print as many copies as you want, and there are no restrictions. Many mechanics print the section they need and bring it to the shop floor.
