Find the exact reference number before your tractor misses another hour of work. Exploded view diagrams cover every system here, from the crankcase and cylinder head through the mission gear, rear axle, and 3-point hitch assembly. The drivetrain section lists numbered breakdowns; the engine section covers the injection pump, water pump, and fuel system, each listing part numbers, quantities, and country-code variants for A, NZ, and AU markets. Checking your battery? The M5500DT unit runs 32 kgf (70.4 lb), so confirm group size before you order. No more waiting three days for a dealer to look it up. The PDF opens on any device, and bookmarks drop you straight to the system you're working on.
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| BATTERY weight | 32 kgf | p. 110 |
| FUSE (REF.No 006) quantity | 2 | p. 108 |
| FUSE (REF.No 006) weight | 0.002 kgf | p. 108 |
| BELT V quantity | 2 | p. 40 |
| BELT V weight | 0.095 kgf | p. 40 |
| FILTER OIL quantity | 1 | p. 30 |
| FILTER OIL weight | 0.02 kgf | p. 30 |
| CASE BRAKE quantity | 2 | p. 102 |
| CASE BRAKE weight | 17.4 kgf | p. 102 |
| ASSY LAMP HEAD quantity | 2 | p. 116 |
| ASSY LAMP HEAD weight | 0.375 kgf | p. 116 |
| ASSY CRANKCASE Weight | 80 kgf | p. 6 |
Kubota M5500DT Common Problems This Manual Covers
Kubota M5500DT dead battery or charging fault, need correct replacement battery part number p. 109
Check the Battery section starting on page 109. The exploded view shows the battery support assembly and band components. The battery itself weighs 32 kgf (70.4 lb); confirm you have the right group size before ordering. Cross-reference the Electrical section on page 107 to verify the fuse case parts list matches your serial number configuration.
Manual Section: BatteryBlown fuse keeps returning, can't match replacement fuse to correct amperage rating in parts list p. 107
Open the Electrical parts list on page 107 and locate the Assy Case Fuse exploded view. The catalog lists three fuse reference numbers (006, 007, 008) with quantities of 2, 1, and 1 respectively; part number 36200-75550 (006) weighs 0.002 kgf, 36200-75560 (007) weighs 0.002 kgf, and 33251-75570 (008) weighs 0.001 kgf. Match the fuse position in the diagram to confirm which reference number corresponds to the circuit before ordering replacements.
Manual Section: ElectricalCan't identify correct V-belt part number for fan and alternator drive after belt failure p. 39
Turn to the Water Pump section on page 39 for the belt routing diagram. The parts list confirms 2 V-belts are fitted, each weighing 0.095 kgf (0.209 lb); locate Belt V in the numbered list to pull the correct order number. Check the Belt Cover diagram on page 145 to identify cover hardware part numbers you will need.
Manual Section: Water PumpTransmission hard shifts or slips out of gear, sourcing correct mission gear and shaft part numbers p. 75
Start with the Mission Gear exploded view on pages 75-77, which covers countershaft and helical gears. The Transmission case assembly weighs 104 kgf; page 69 shows the outer case diagram. Cross-reference the 1-2 Shift Lever list on page 82 and Main Change Lever on page 84 to identify shift fork and rod part numbers for your specific fault.
Manual Section: Mission Gear4WD won't engage or front axle drive fails, need correct differential and front wheel part numbers p. 162
Head to the Diff Case 1 section on page 162 and Diff Case 2 on page 164 for front differential parts. The Front Axle Support on page 166 covers bevel pinion and king pin part numbers. Verify axle shaft and bearing numbers in the Front Wheel Case list on page 169; the front tire assembly weighs 42 kgf.
Manual Section: Diff Case 1Clutch slipping or dragging, need to match correct clutch disk and pressure plate part numbers p. 73
Pull up the Clutch section on page 73 for the exploded view listing Disk Clutch, Disk PTO Clutch, Plate Pressure, and Cover Clutch with individual part numbers. The Clutch Housing assembly weighs 100 kgf; identify both the main clutch disk and the PTO clutch disk part numbers separately, as they are distinct items in the same diagram.
Manual Section: ClutchFrequently Asked Questions
What are the replacement specifications for battery?
The replacement battery for the Kubota M5500 carries part number 35709-74090, with a listed weight of 32 kgf (70.4 lb).
What are the replacement specifications for fuse?
The M5500 fuse listing spans several part numbers at different weights: 36200-75550 at 0.002 kgf, 36200-75560 at 0.002 kgf, 33251-75570 at 0.001 kgf, 36500-75370 at 0.034 kgf, and 36500-75380 at 0.002 kgf.
What is the V-belt count for the Kubota M5500DT fan and alternator drive?
The Water Pump section on page 39 lists 2 V-belts, each weighing 0.095 kgf (0.209 lb). Locate Belt V in the numbered parts list on that page to pull the correct order number for your machine.
What does the Kubota M5500DT clutch housing weigh and where are clutch disk part numbers listed?
The Clutch section on page 73 covers the exploded view with Disk Clutch, Disk PTO Clutch, Plate Pressure, and Cover Clutch as separate items. The Clutch Housing assembly weighs 100 kgf. The main clutch disk and PTO clutch disk have distinct part numbers in the same diagram.
Is this Kubota M5500DT Parts Catalog a digital download?
A 185-page Parts Catalog in searchable PDF, ready the moment your checkout completes. Open it on a computer, tablet, or phone, with no shipping wait.
Can I print this manual?
No restrictions at all. Print individual pages, full chapters, or the entire manual. The PDF is completely unlocked.
