Within the hour you will have a cracked hydraulic hose fitting on the bench and this 366-page Manitou MLT 635 130 PS parts catalog PDF (OEM ID 647663) open beside it, matching the fitting to its exploded view across four MLT telescopic handler models, including the 733 105, 733 115 and 737 130 PS. Hydraulics fill a big slice of the book, breaking the valve bank, joystick, rams and telescope cylinder down to individual seals and pins, while the engine, transmission and cab sections give every component its number and position. Plan on 5 liters of 10W40 API CJ4 for the engine and 2 liters of SAE80W90 for a manual gearbox. A hose fitted on a guessed pressure rating is a boom waiting to drop. Search the text, jump by bookmark, and order the right part number for your machine the first time.
What's Inside This Manitou MLT 635 130 PS, 733 105/115, 737 130 PS Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| General Instructions and Safety Notice | 1-8 | Adhesive Signs |
| Lubricants | 9-30 | Air Conditioning Oil, Engine Oil, Brake Fluid, Manual Gearbox Oil, Cooling Liquid, Grease |
| Filters-Belt | 31-33 | Air Filter, Fuel Filter, Oil Filter, Hydraulic Return Oil Filter, Alternator Belt |
| Frame - Body | 34-56 | Frame Structure, Body Panels |
| Electricity | 57-96 | Electric Circuits, Electrical Components |
| Axle Assembly - Axle | 97-120 | Front Axle, Rear Axle |
| Wheels | 121-122 | Tyre, Valve, Wheel Nut |
| Hydraulic | 123-173 | Valve Bank, Joystick, Ram |
| Telescopic Boom | 174-182 | Boom Foot, Boom Ring, Hinge Pin, Telescope Cylinder, Carriage, Sliding Block |
| Engine | 183-253 | Intake System - Exhaust, Fuel Supply System, Cooling System |
| Pedals | 254-265 | Brake Pedal, Master Cylinder, Handbrake Cable, Linkage, Transmission Cut-Off Switch |
| Driver Cab | 266-303 | Cab Structure |
| Transmission | 304-366 | Gear Box |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Engine Oil (10W40 API CJ4) Capacity | 5 Liters | p. 18 |
| Brake Fluid (LHM) Capacity | 1 Liter | p. 20 |
| Oil Special Immersed Brakes Capacity | 1 Liter | p. 22 |
| Manual Gearbox Oil (SAE80W90) Capacity | 2 Liters | p. 24 |
| Automatic Gear Box Oil (DEXTROM3) Capacity | 1 Liter | p. 26 |
| Windscreen Washer Liquid Capacity | 1 Liter | p. 28 |
| Cooling Liquid (-35°C) Capacity | 5 Liters | p. 30 |
| Diesel Exhaust Fluid (AdBlue) Capacity | 10 Liters | p. 32 |
Manitou MLT 635 130 PS, 733 105/115, 737 130 PS Common Problems This Manual Covers
Manitou MLT 733 hydraulic return oil filter and fuel filter part numbers hard to find in parts listings
Check the Filters-Belt section starting on page 31 before ordering a service kit. Match the air filter, fuel filter, oil filter and hydraulic return oil filter against the parts list for your exact variant, since this book covers ST4 S2 and S3 builds. Confirm the alternator belt reference on the same pages while you are there.
Manual Section: Filters-Belt p. 31Engine oil and gearbox oil part numbers unclear when ordering fluids for scheduled service
Check the Lubricants section on page 18 for engine oil part 895837, Manitou evology API CJ4 10W40, listed at 5 Liters. Verify gearbox oil against page 24 (manual gearbox oil 499237, 2 Liters) or page 26 (DEXROM III automatic gear box oil 958186, 1 Liter) based on your transmission type.
Manual Section: Lubricants p. 18LHM brake fluid and immersed brake oil part numbers confused when ordering brake circuit fluids
Verify which fluid your brake circuit takes before ordering. Page 20 lists LHM brake fluid S8214 B as part 490408 at 1 Liter, while page 22 lists Manitou oil special immersed brakes as part 546034, also 1 Liter. Cross-check the master cylinder in the Pedals section on page 254 against the parts list for your variant.
Manual Section: Lubricants p. 20Valve bank, joystick or ram replacement part numbers hard to identify in hydraulic parts listings
Check the hydraulic parts diagram on page 129 and trace the line from the valve bank back to the joystick and each ram. Match the callout numbers on the exploded view to the matching parts list. Confirm the model designation, since 635, 733 and 737 variants share this Hydraulic section.
Manual Section: Hydraulic p. 129Telescope cylinder, sliding block or hinge pin part numbers difficult to locate for boom rebuild
Check the Telescopic Boom section starting on page 174 for the boom foot, boom ring, hinge pin, telescope cylinder, carriage and sliding block. Identify the worn part on the exploded view first, then read its reference from the parts list. Match each sliding block to its callout position before you order.
Manual Section: Telescopic Boom p. 174Propshaft, cardan coupling or bevel drive part numbers hard to match on transmission diagrams
Check the drivetrain parts diagram and locate the propshaft, cardan coupling, bevel drive and gear box callouts. Match each callout to the parts list for your exact model, since the book covers Tract and LSU variants. Confirm gearbox oil type on page 24 or page 26 before ordering.
Manual Section: TransmissionFrequently Asked Questions
What are the engine oil filter replacement specs for the Manitou MLT 635 130 PS, 733 105/115, 737 130 PS?
The engine oil filter for the specified engine is part number 943326. This filter is used across multiple models including the MLT 733 105 D ST4 S1 and MLT 733 115 D ST4 S3. p. 39
What are the fuel filter replacement specifications for the Manitou MLT 635 130 PS, 733 105/115, 737 130 PS?
The fuel filter for the machine is part number 318538. It is compatible with several models including the MLT 733 105 D ST4 S2 and MLT 733 115 D ST4 S3. p. 241
What is the engine oil capacity of the TCD 3.6 L4 T4F engine in the Manitou MLT 635 130 PS, 733 105/115, 737 130 PS?
The engine oil is available in various container sizes, including 5 Liters (part number 895837), 20 Liters (895838), 55 Liters (895839), and 209 Liters (895840). p. 18
What is the part number for the alternator belt on the Manitou MLT 635 130 PS, 733 105/115, 737 130 PS?
The alternator belt is part number 942574 and is characterized as having 8 ribs (8 STRIES). p. 39
What is the hydraulic return oil filter cartridge part number for the Manitou MLT 635 130 PS, 733 105/115, 737 130 PS?
The hydraulic return oil filter cartridge is part number 236094. p. 39
Do I get instant access to this Manitou MLT 635 130 PS Parts Catalog?
One searchable PDF covering 366 pages, delivered instantly. No disc, no shipping, no waiting on the post.
Is this Manitou MLT 635 130 PS manual print-friendly?
Yes. Many buyers print one chapter at a time for their own shop and keep the rest on a tablet.
