Everything a TZ owner handles between dealer visits fits inside these 144 pages: the New Holland TZ25DA operator manual PDF, OEM 87544689, which also covers the TZ18DA and TZ22DA compact tractors along with the 54CMS and 60CMS mower decks. Lubrication and maintenance takes up roughly a quarter of the book, from fuel and lubricant service procedures to the same predelivery checks the dealer ran: tire pressures, fan belt tension, coolant level, battery. Wiring diagrams and a troubleshooting chart handle the electrical side, and both mower decks get their own full section for mounting, operation, and maintenance. Swap the hydraulic and HST oil filters at 300 hours, refill the crankcase with 3.3 liters after an oil filter change, and set rear wheel disc-to-axle bolts at 122 N·m. Every hour spent hunting numbers is mowing weather you don't get back. One purchase, one bookmarked, keyword-searchable PDF, yours for as long as you own the tractor.
What's Inside This New Holland TZ18DA, TZ22DA, TZ25DA Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| Safety | 8-21 | Safety Frame (ROPS), Operating the Tractor, Operating the PTO, Servicing the Tractor, Diesel Fuel |
| General Information | 22-25 | Minimum Hardware Tightening Torques |
| Operation | 26-55 | Controls and Instruments, Starting the Engine |
| Lubrication and Maintenance | 56-91 | General Maintenance, Fuel and Lubricant Service Procedures |
| CMS and 60CMS TZ Mower Deck | 92-129 | Operating Instructions, Maintenance |
| Specifications | 130-137 | Engine Specifications, Transmission Speeds |
| Predelivery Service | 140-144 | Tire Pressure, Air Cleaner Element, Radiator Coolant Level, Fan Belt Tension, Battery, Engine Oil Level, Transmission and Rear Axle Oil Level |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Injector line fitting torque | 24-29 N·m (18-22 ft. lbs.) | p. 65 |
| Hydraulic system oil filter replacement interval | 300 hours | p. 71 |
| H.S.T. system oil filter replacement interval | 300 hours | p. 71 |
| Front Wheel Disc-to-Hub | 88 N·m (65 ft-lb) | p. 134 |
| Engine Oil Capacity (with filter) | 3.3L | p. 130 |
| Fuel Tank Capacity | 29.5 liters | p. 130 |
| Cooling System Capacity | 3.5 liters | p. 130 |
| Rear Axle & Transmission Oil Capacity | 13 liters | p. 130 |
| Front Axle Differential/Final Reduction Gear Case Oil Capacity | 2.0 liters | p. 130 |
| Front Wheel Bolt Torque | 88 N⋅m | p. 84 |
| Rear Wheel Bolt Torque | 122 N⋅m | p. 84 |
| ROPS Attaching Bolt Torque | 50 N⋅m | p. 134 |
New Holland TZ18DA, TZ22DA, TZ25DA Common Problems This Manual Covers
New Holland TZ25DA won't crank, no glow plug light, intermittent no-start after sitting overnight
Check the battery first: it should be a 450 cold cranking amp unit, so load test it and clean both cable ends. Verify you are fully on the seat, the HST pedals are neutral, and the PTO is off before cranking. Trace no-crank faults with the wiring diagram on page 89 and check every fuse.
Manual Section: Electrical System Troubleshooting p. 78Hydrostatic drive quits after 30 to 45 minutes of mowing, works again once the tractor cools
Check the transmission oil level on the dipstick before every use; the rear axle and transmission hold 13 liters total. Replace both the hydraulic and HST filters every 300 hours as shown on page 71, sooner if drive fades when hot. Old fluid and a plugged filter starve the hydrostat once the oil thins out.
Manual Section: Lubrication and Maintenance p. 71Engine runs rough, loses power, or stalls after fuel filter replacement or running the tank dry
Bleed the fuel system using the procedure on page 65 any time the 29.5 liter tank runs dry or a filter is changed. Open the bleed points, crank until fuel runs clear of bubbles, then snug the injector line fittings to 24-29 N·m (18-22 ft. lbs.). Check the filter bowl for water while you are there.
Manual Section: Fuel System Bleeding p. 65Mower deck leaves streaks and uncut strips, cut looks ragged even at slow ground speed
Sharpen or replace the blades and check deck leveling side to side before blaming the tractor. Work through the streaking conditions in the troubleshooting procedures on page 123. Whenever a blade comes off, torque the retainer nuts to 150-177 N·m (110-130 ft. lbs.) and inspect them daily during mowing season.
Manual Section: Mower Deck Troubleshooting p. 123Temperature gauge climbs into the red during loader work or heavy mowing on hot days
Check the coolant level in the recovery tank when the engine is cold and top up with the correct mix; the system holds 3.5 liters per the specifications on page 130. Clean chaff and grass out of the radiator screen and fins with low pressure air, then verify fan belt tension before the next hay day.
Manual Section: Cooling System Maintenance p. 130Frequently Asked Questions
What are the torque specifications for the wheel bolts on the New Holland TZ22DA?
The front wheel bolts should be torqued to 88 N·m (65 ft-lb). The rear wheel bolts should be torqued to 122 N·m (90 ft-lb). p. 84
What are the replacement specifications for the hydraulic system oil filter on the New Holland TZ18DA, TZ22DA and TZ25DA?
The hydraulic system oil filter should be replaced after the first 50 hours of operation, and then every 300 hours thereafter. p. 71
What is the replacement interval for the primary fuel filter on the New Holland TZ18DA, TZ22DA and TZ25DA?
The primary fuel filter should be replaced every 300 hours of operation. p. 63
What is the valve clearance specification for the TZ18DA, TZ22DA, and TZ25DA engines?
The cold valve clearance for both intake and exhaust valves is 0.20 mm (0.008 in) for all three models. p. 130
What is the engine oil crankcase capacity for the New Holland TZ18DA, TZ22DA and TZ25DA?
The crankcase capacity, including the filter, is 3.3 liters (3.5 U.S. quarts). p. 130
Is this manual a download or a disc?
Delivery is instant: a 144-page searchable PDF is yours the second checkout clears. Laptop, tablet, or phone, all fine.
Are there any print restrictions on this manual?
Printing is allowed without restriction. Pull the pages you need for the job and bin them when they get greasy.
