Part of the New Holland Repair Manuals.
An hour from now you could be tracing fault 301.07 to a binding duckbill instead of guessing why the net wrap quit mid-windrow. This manual covers the Roll-Belt 450, 460, 550, and 560 round balers, from pickup teeth and rotor cutter to the Bale Command II Plus and ISOBUS electronics.
Every hydraulic circuit gets full diagnosis and repair steps: bale density, tailgate, pickup lift, cutter control, drop floor, and bale eject, with component locations and test procedures for each. The fault code tables, harness pinouts, and eight sheets of electrical schematics are covered just as deep.
When hay is down and rain is two days out, the fix has to happen in the field. Keep this on the tablet in the tractor cab and the diagnostic steps ride with the baler.
What's Inside This New Holland 450-560 Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction | 7-76 | Safety Information, General Specifications, Fire Extinguisher, Chain Oiler and Gearbox Oil Capacities, Towing Weights, Wheel Torque |
| Rear Axle System | 77-106 | Non-Powered Rear Axle, Tire Configurations, Wheel Torque, Wheel Installation |
| Power Take-Off (PTO) | 107-172 | Drive Shaft, Gearbox, Clutches, Slip Torque, Safety Booklet |
| Hydraulic Systems | 173-312 | Bale Density Circuit, Tailgate Circuit, Pickup Lift Circuit, Cutter Control Circuit, Drop Floor Circuit, Bale Eject Circuit |
| Hitches, Drawbars, and Implement Couplings | 313-332 | Drawbars, Towing Hitches, Front Hitch |
| Electrical Systems | 333-926 | Harnesses and Connectors, Ejection/Unloading Control, Twine and Net Cutting, Bale Formation Control, Electronic Modules, Fault Codes |
| Product Feeding | 927-1264 | Pickup, Wide Pickup with Over Shot Feeder, Rotor Cutter, Stuffer, Rotor |
| Pressing - Bale Formation | 1265-1484 | Bale Formation, Belt De-Clutch, Starter Roll, Stationary Roll, Stripper Roll, Floor Roll, Sledge |
| Tying/Wrapping/Twisting | 1485-1572 | Net Wrapper, Twine Wrapper |
| Ejection | 1573-1586 | Bale Ejector Components |
| Lubrication System | 1587-1622 | Grease Lubrication System, Oiler System, Roller Chain Maintenance |
| Platform, Cab, Bodywork, and Decals | 1623-1641 | Machine Shields, Guards, Decals, Plates |
| Special Tool Index | 1642-1643 | Index of Special Tools Referenced Throughout the Manual |
| Electrical Schematic | 1644-1646 | CAN Bus, Sensors and Options, Power/Ground Distribution, Net Wrap Options, Density Pressure Options, Lighting, Power (Battery) Harness - Bale Command II Plus / ISOBUS |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Wheel hardware torque | 156 - 183 N-m (115 - 135 lb ft) (31x13.5-15 8 ply) / 156 - 183 N-m (115 - 135 lb ft) (31x13.5-15 10 ply) / 380 - 407 N·m (280 - 300 lb ft) (18L-16.1SL 10 ply) / 203 - 230 N·m (150 - 170 lb ft) (21.5L-16.1 10 ply) | p. 67 |
| Gearbox oil capacity | 1.9 L (2.0 US qt) or 2.0 L (2.1 US qt) | p. 46 |
| Drive chain oiler reservoir capacity | 1.9 L (2.0 US qt) | p. 46 |
| Fire extinguisher capacity | 9.46 L (2.5 US gal) | p. 16 |
| Single density cylinder system pressure range (Adjustable) | 83-179 bar (1200 - 2600 psi) | p. 56 |
| Dual density cylinder system pressure range | 69 - 138 bar (1000 - 2000 psi) (Roll-Belt 460, Roll-Belt 560 Hay) | p. 56 |
| Clearance to spare net roll storage box | 4.8 m (16 ft) | p. 10 |
| Maximum allowable wear elongation for roller chains | 3% | p. 38 |
| Recommended air pressure | 241 kPa (35 psi) or 2.4 bar (31x13.5-15 8 ply) / 414 kPa (60 psi) or 4.1 bar (31x13.5-15 10 ply) / 186 kPa (27 psi) to 255 kPa (37 psi) or 1.9 - 2.6 bar (18L-16.1SL 10 ply) / 138 kPa (20 psi) or 1.4 bar (21.5L-16.1 10 ply) / 104 - 138 kPa (15 - 20 psi) or 1.03 bar - 1.4 bar (4.80/4.00-8) / 207 kPa (30 psi) or 2.1 bar (15X6.00-6) | p. 67 |
| Bale width | 1181 mm (46.5 in) (Roll-Belt 450, 460) / 1562 mm (61.5 in) (Roll-Belt 550, 560) | p. 56 |
| Minimum/Maximum bale diameter | 914 - 1524 mm (36 - 60 in) (Roll-Belt 450) / 914 - 1829 mm (36 - 72 in) (Roll-Belt 460) | p. 56 |
| Minimum bale weight | 181 kg (400 lb) | p. 56 |
| Maximum bale weight | 544 kg (Roll-Belt 450 Hay) / 816 kg (Roll-Belt 450 Silage) / 748 kg (Roll-Belt 460 Hay) / 998 kg (Roll-Belt 460 Silage) / 1200 lb (Roll-Belt 450 Hay) / 1800 lb (Roll-Belt 450 Silage) / 1650 lb (Roll-Belt 460 Hay) / 2200 lb (Roll-Belt 460 Silage) | p. 56 |
| Overall pickup width excluding pickup gauge wheels | 1943 mm (76 in) (Roll-Belt 450 and Roll-Belt 460 (1.5 m Wide pickup)) / 2132 mm (84 in) (Roll-Belt 450 and Roll-Belt 460 (1.8 m Wide pickup, Rotor feeder with and without assist roll)) / 2132 mm (84 in) (Roll-Belt 450 (1.8 m Wide pickup with OSF)) / 2132 mm (84 in) (Roll-Belt 460 (1.8 m Wide pickup with OSF)) / 2399 mm (94 in) (Roll-Belt 450 and Roll-Belt 460 (2.0 m Wide pickup, Rotor cutter with and without assist roll)) / 2187 mm (86 in) (Roll-Belt™ 550 Hay, 1.5 m Standard pickup) | p. 57 |
| Power Take-Off (PTO) speed | 540 RPM or 1000 RPM | p. 68 |
| Tractor power minimum requirement | 52 kW (70 Hp) (Roll-Belt™ 550 Hay, 1.5 m Standard pickup) / 60 kW (80 Hp) (Roll-Belt™ 550 Hay, 2.0 m Wide pickup with OSF) / 60 kW (80 Hp) (Roll-Belt™ 560 Hay, 1.5 m Standard pickup) / 67 kW (90 Hp) (Roll-Belt™ 560 Bale-Slice™, 2.0 m Wide pickup with OSF) / 60 kW (80 Hp) (Roll-Belt™ 560 Specialty Crop, 2.0 m Wide pickup with OSF) | p. 69 |
| Maximum road speed (bale chamber empty) | 32 km/h (20 mph) | p. 69 |
| Maximum static weight on the towing vehicle | 776 kg (1710 lb) (Roll-Belt 450, Roll-Belt 550) / 889 kg (1960 lb) (Roll-Belt 460, Roll-Belt 560) | p. 66 |
| Base unit weight (Shipping) | 2707 kg (5967 lb) (Roll-Belt 550 Hay, 1.5 m Standard pickup) / 2995 kg (6603 lb) (Roll-Belt 560 Hay, 1.5 m Standard pickup) / 3440 kg (7585 lb) (Roll-Belt 560 Hay, 2.0 m Wide pickup with OSF) | p. 66 |
New Holland 450-560 Common Problems This Manual Covers
Net wrap only partially covers the bale or throws a wrapping error
Start with the Tying/Wrapping section on the net wrapper: check duckbill travel, knife action, and the spiral rollers, since chaff and rough roller surfaces stop the net spreading to the bale edges. Then confirm feed voltage per the electrical section.
Manual Section: Tying/Wrapping/Twisting p. 1494Wrap fault codes like 301.07 during auto cycle
The electrical section decodes the fault: 301.07 flags duckbill motor current above 22 amps for over a second. Follow the diagnostic tree for binding duckbill, binding net knife, or weak supply before swapping the motor or the control module on a guess.
Manual Section: Electrical systems p. 882Chains, sprockets, and roller bearings wearing out early
The lubrication chapter covers the grease system, the chain oiler, and roller chain maintenance, plus oiler and gearbox capacities such as the 1.9 to 2.0 liter gearbox fill. Keeping the oiler fed and adjusted is the cheapest bearing insurance these balers get.
Manual Section: Lubrication system p. 46Frequently Asked Questions
Why does auto net wrap fail on my Roll-Belt when manual wrap works fine?
That is the classic complaint on these balers. The manual lists the intermittent auto-wrap causes on page 1494: duckbill binding, net knife binding, or a weak power source. If you get fault 301.07, the duckbill motor pulled over 22 amps for more than a second, which usually means mechanical drag, not a bad motor. Work the checks in order before buying parts. p. 882
What do New Holland Roll-Belt error codes mean?
The electrical section carries the full fault code tables for the Bale Command II Plus and ISOBUS controls. Codes read as component and failure type. For example, 100.04 means battery supply voltage is too low, and the manual sends you to the tractor diagnostic screen to check for charging faults first. That one page can save you from replacing a module that was only starved for volts. p. 791
How do I reset the Roll-Belt monitor software?
The display section covers clearing the monitor with the DELETE ALL APPLICATIONS / FILES button, then reloading the baler software. The manual walks through the screens so you do not wipe settings you wanted to keep. It also covers module programming and harness checks if the monitor still acts up after a clean load. p. 469
Does it give wheel lug torque and tire specs?
Yes, by tire size. The 31x13.5-15 8 ply takes 156 to 183 N-m (115 to 135 lb ft), the 18L-16.1SL 10 ply takes 380 to 407 N-m (280 to 300 lb ft), and the 21.5L-16.1 10 ply takes 203 to 230 N-m (150 to 170 lb ft). Tongue weight limits are listed too: 776 kg for the 450 and 889 kg for the 460. p. 52
Does it cover belt and pickup repair, or just electronics?
The bale formation section covers belts, belt de-clutch, starter roll, stripper roll, floor roll, and the sledge. Product feeding covers the pickup, wide pickup with overshot feeder, rotor cutter, and stuffer. Those are exactly the wear areas: pickup teeth, belt splices, and roller bearings are what these machines eat first. Service specs for the gearbox and chain oiler are in the introduction chapter.
