When a DPU 130 comes back from a teardown in labeled boxes, the argument over what bolts on first ends here: this Wacker Neuson DPU 130 repair manual PDF is the 106-page factory reassembly book for the reversible vibratory plate. Roughly half the book is straight assembly procedure, rebuilding your machine system by system from hood hinges and battery through crossbeam, hydraulic tank, fuel valve, radiator, and starter motor down to the exciter itself. Upper mass hydraulic hoses go on in a numbered sequence, one through seven, and wiring harness drawings trace each cable from the electric connection box out to the engine and ground points. Torque the battery ground cable to 50 Nm, the hood's rubber bumpers to 30 Nm, and the Verbus ribbed screws to 25 Nm. Every hour spent guessing a hose route is an hour the plate isn't compacting. Bookmarked and text-searchable, the PDF puts the section you need one keyword away.
What's Inside This Wacker Neuson DPU 130 Repair Manual
| System | Pages | Key Topics |
|---|---|---|
| Repair Instructions and Safety | 1 | DPU 130 Repair Instructions, Safety Guidelines |
| Hood, Hinges and Battery Assembly | 2-11 | Rear and Front Hood, Assembling Hinges, Aligning the Hood, Threaded Rods, Ground Cable, Wiring Harness Connection, Stiffener and Battery |
| Crossbeam and Its Component Parts | 12-18 | Lifting Eye, Hose Clamps, Stop Mounts, Limit Stop, Lock, Lifting the Crossbeam, Mounting the Crossbeam |
| Electrical Control Panel Assembly | 19-20 | Emergency Stop, Display, On/Off Switch, Electric Connection Box Components |
| Hydraulic Tank and Tank Components | 21-24 | Mounting the Hydraulic Tank, Extension Screws, Air Cleaner Support, Oil Sight Glass, Return Filter, Screw-Down Fittings |
| Fuel System, Engine Supports and Radiator | 25-36 | Fuel Valve, Fuel Filter, Connecting Fuel Lines, Engine Support Preparation and Mounting, Shock Mounts, Radiator Mounting |
| Throttle, Starter Motor, Cooling Fan and V-Belt | 37-44 | Throttle Valve Preparation, Fitting the Cable, Electrical Connection, Pinion Gear Engagement, Fastening Starter, V-Belt Pulley, V-Belt Tension, Cooling Fan |
| Upper Mass Hydraulic Hoses, Oil Draining and Refilling | 45-55 | Hose 1 Through 7 Assembly Sequence, Draining Hydraulic Oil, Draining Engine Oil, Replenishing Hydraulic and Engine Oil |
| Shock Mounts and Mounting the Exciter | 56-63 | Main and Small Shock Mounts, Shock Mount Rail, Exciter Cover, Adjustment Cylinder Protection, Sealing Compound, Positioning the Exciter |
| Adjustment Cylinder, Tumbler Lever and Lower Mass Hoses | 64-82 | Piston and Cover Preassembly, Adjusting Unit, Fastening Shock Mounts, Swivel Head, Spring Joint, Hose Disposition and Sequence, Connecting Lower Mass Hoses |
| Exciter Assembly | 83-95 | Cylindrical Roller Bearings, Exciter Shafts, Toothed Gears, Exciter Housing Closure |
| Wiring Harnesses and Hydraulic Block | 96-106 | Electric Connection Box, Connecting Cables, Engine Connection, Ground Points, Hydraulic Block Mounting, Screwed Socket, Venting the System |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Receiver eye socket head cap screws | 10 Nm (7.4 ft-lb.) | p. 2 |
| Verbus ribbed screws (hood) | 10 Nm (7.4 ft-lb.) | p. 2 |
| Rear hood receiver eye screw torque | 10 Nm | p. 2 |
| Rear hood rubber bumper screw torque | 30 Nm | p. 2 |
| Battery ground cable torque | 50 Nm | p. 8 |
| Hydraulic tank mounting screw torque | 80 Nm | p. 21 |
| Fuel valve hollow screw torque | 35 Nm | p. 25 |
| Engine support to diesel engine torque | 120 Nm | p. 30 |
| Hydraulic oil capacity | 45 liters | p. 52 |
| Engine oil drain volume | 3 liters | p. 53 |
| Hydraulic oil refill volume | 44 liters | p. 54 |
| Engine oil refill volume | 3.2 liters | p. 55 |
Wacker Neuson DPU 130 Common Problems This Manual Covers
Wacker Neuson DPU 130 engine stalls or bogs down when vibration is switched on
Check the fuel supply before blaming the exciter. Verify the fuel valve and filter line connections shown on page 25 are tight; the fuel valve hollow screws take 35 Nm (25.8 ft-lb.). Then run the throttle valve switching operation test starting on page 37 to confirm the cable pulls full RPM before vibration engages.
Manual Section: Assembly Diesel Valve and Diesel Filter p. 25Vibration output drops or quits under load while engine RPM stays steady
Check the hydraulic oil level at the sight glass first; the system holds 45 liters, and a low tank starves the exciter gear motor. Inspect the pressure hose connections at the exciter, covered on page 58. If flow checks out, pull the exciter and inspect the cylindrical roller bearings and toothed gears per page 83.
Manual Section: Exciter Assembly p. 83Oil weeping from the breather hose or pooling under the upper mass after a shift
Inspect the breather hose fitting; the hollow screw torques to 30 Nm (22.1 ft-lb.) on page 51, and a loose one weeps oil constantly. Replace the sealing washers while you are in there. If leakage continues, drain the hydraulic system per page 52 and inspect every hose end for cracking before refilling with 44 liters.
Manual Section: Upper Mass Hydraulic Hoses Assembly p. 51Starter motor clicks but the engine will not crank even with a fully charged battery
Check the battery ground cable connection first; it torques to 50 Nm (36.9 ft-lb.) per page 8, and a loose ground drops cranking amps fast. Then inspect the starter cable nut, torqued to 10 Nm (7.4 ft-lb.) on page 41. If connections are clean, remove the starter and check pinion gear engagement per page 40.
Manual Section: Starter Motor Assembly p. 40Engine overheats after an hour of compaction, coolant temperature warning on the display
Clean the radiator screen and check the combination radiator core for packed dust; the screen screws torque to 15 Nm (11.1 ft-lb.) on page 35. Inspect V-belt tension and the cooling fan per page 42; the fan screws take 10 Nm (7.4 ft-lb.). Verify coolant hose clamps are tight before refilling.
Manual Section: Assembly Engine Radiator p. 34Frequently Asked Questions
What are the replacement specifications for the handle assembly on a Wacker Neuson DPU 130?
To mount the handle to the hood lock, use an 8 mm Allen key. You must safeguard both socket head cap screws with Omnifit 100 M and torque them to 25 Nm (18.5 ft-lb.). p. 3
What is the required torque for the hydraulic oil drain plug on the Wacker Neuson DPU 130?
The larger hydraulic oil drain plug must be torqued to 55 Nm (40.6 ft-lb.) after draining the oil. p. 54
What is the engine oil capacity for the DPU 130?
The engine requires 3.2 liters (3.4 quarts) of engine oil, specifically Fuchs Titan Unic 10 W 40 MC (SAE10W40). p. 55
What is the hydraulic oil capacity for the DPU 130?
The hydraulic oil tank has a capacity of 45 liters (11.9 gallons) when factory filled, and you should replenish with 44 liters (11.9 gallons) of hydraulic oil. p. 52
What is the torque spec for the exciter cover screws on a Wacker Neuson DPU 130?
The cover is fastened to the exciter using 6 ribbed hexagon socket screws per exciter, which must be torqued to 85 Nm (62.7 ft-lb.) using an 8 mm Allen key. p. 58
What do I get after purchasing this Wacker Neuson DPU 130 manual?
Instant PDF download. You get the full 106-page searchable Repair Manual immediately after payment. Open it on your laptop, tablet, or phone right in the shop.
Are there any print restrictions on this Wacker Neuson DPU 130 manual?
Yes, printing is unrestricted: a single page, a chapter, or the lot, on letter or A4.
