Tracking down the right component is easy with this 124-page 3TNE82A-TB, TB125 parts catalog PDF covering the complete engine assembly. You get crystal-clear exploded views for the entire build, from the cylinder head to the flywheel housing. Open the file to find detailed part numbers and hardware breakdowns for the cooling water system, governor, and suction manifold. Locate exact OEM replacement numbers for the fuel injection valve assembly or verify the proper gasket set before calling the dealer. Stop wasting money ordering the wrong components. Download the manual, use the bookmarks to jump straight to your specific engine variant, and build your parts list right the first time.
What's Inside This Yanmar 3TNE82A-TB Parts Manual
| System | Pages |
|---|---|
| Cylinder Block | - |
| Gear Housing | - |
| Flywheel Housing & Oil Sump | - |
| Cylinder Head & Bonnet | - |
| Suction Manifold & Air Cleaner | - |
| Exhaust Manifold & Silencer | - |
| Camshaft & Driving Gear | - |
| Crankshaft & Piston | - |
| Lub.Oil System | - |
| Cooling Water System | - |
| Fuel Injection Pump | - |
| Governor | - |
| Fuel Injection Valve | - |
| Fuel Line | - |
| Starting Motor | - |
| Generator | - |
| Gasket Set | - |
Yanmar 3TNE82A-TB Common Problems This Manual Covers
Need to find correct 3TNE82A-TB fuel injection components after engine bogs down at higher throttle p. 4
Inspect the engine parts diagram on page 4 to locate the fuel injection pump assembly. Cross-reference the diagram callouts with the parts number list on page 5. Order the exact injector nozzles (3 pieces required) matching your specific serial number block.
Manual Section: Engine for 3TNE82A-TbCan't identify the right cylinder head gasket part number for rebuild after white smoke issue p. 41
Check the parts index for the ETB series starting on page 41. Locate the cylinder head exploded view. Verify the required gasket thickness in millimeters before selecting the part number. Gasket selection depends strictly on your measured piston protrusion dimensions.
Manual Section: Engine for 3TNE82A-EtbNeed the exploded view to order correct main bearing sizes for tight crankshaft rotation p. 81
Open the parts index for the QTB system on page 81. Review the crankshaft and bearing diagram to find standard and oversized bearing shells. Order the required upper and lower halves (4 pairs total) based on your machined journal dimensions.
Manual Section: Engine for 3TNV82A-QTB,QTB1Looking up replacement starter and wiring harness part numbers after key switch indicator fails p. 4
Locate the electrical system breakdown in the engine parts diagram on page 4. Find the 12V starter motor and associated wiring harness indicator components. Match the exact callout numbers with the parts number list on page 5 to ensure proper factory fitment.
Manual Section: Engine for 3TNE82A-TbFrequently Asked Questions
What are the replacement specifications for gasket cylinder head?
The replacement specification for the cylinder head gasket is identified by part number 119812-01330, named GASKET, HEAD, with a quantity of 1. This information is consistent across different engine models listed in the manual.
What are the replacement specifications for starter?
The replacement starter for the 3TNE82A-TB and 3TNE82A-ETB models is specified by part number 129400-77012, described as STARTING MOTOR (S13-294), with a quantity of 1. For the 3TNV82A-QTB,QTB1 (E/2004.09-), the part number is 129136-77011, described as STARTER, with a quantity of 1.
How do you fix need to find correct 3TNE82A-TB fuel injection components after engine bogs down at higher throttle?
Inspect the engine parts diagram on page 4 to locate the fuel injection pump assembly. Cross-reference the diagram callouts with the parts number list on page 5. Order the exact injector nozzles (3 pieces required) matching your specific serial number block.
How do you fix can't identify the right cylinder head gasket part number for rebuild after white smoke issue?
Check the parts index for the ETB series starting on page 41. Locate the cylinder head exploded view. Verify the required gasket thickness in millimeters before selecting the part number. Gasket selection depends strictly on your measured piston protrusion dimensions.
Is this 3TNE82A-TB & variants Parts Catalog a digital download?
You get a 124-page searchable PDF that downloads instantly after checkout. Open it on your laptop, tablet, or phone, and bring it right to the shop floor.
Can I print this 3TNE82A-TB & variants manual?
Absolutely. No DRM or copy protection. Print the whole manual or just the pages you need. Any home or office printer works.
