The M Series 3 backhoes, from the 580M up to the 590 Super M+, are Case's job site staple, and when the drive or the backhoe stabilizers act up the machine cannot earn. This is the real factory service manual, part 87728449NA, 1,467 pages covering the diesel engine, fuel, electrical, steering, power train, brakes, hydraulics and mounted equipment, plus a full schematic set. Whether you are chasing a transmission leak that killed the drive, an overheat under heavy loader work, or a stabilizer that will not lock, it is here in factory order with the per model stall speeds and torque values to work to.
What's Inside This Case 580M, 580 Super M, 580 Super M+, 590 Super M, 590 Super M+ Manual
| System | Pages | Key Topics |
|---|---|---|
| General | Machine Specifications, Standard Torque Values, Hydraulic Stall Speeds, Fluids, General Service | |
| Engine | Diesel Engine Repair, Cylinder Head, Block, Timing, Lubrication, Cooling, Turbocharger | |
| Fuel System | Injection Pump, Injectors, Fuel Supply, Filters, Governor, Speed Settings | |
| Electrical | Wiring Diagrams, Charging and Starting, Lighting, Instruments, Sensors | |
| Steering | Hydrostatic Steering, Steering Pump and Valve, Cylinders, Articulation | |
| Power Train | Transmission, Shuttle, Torque Converter, Axles, Differentials, Final Drives | |
| Brakes | Service and Park Brakes, Brake Valves, Bleeding and Adjustment | |
| Hydraulics | Loader and Backhoe Hydraulic Circuits, Variable Volume Pump, Control Valves, Cylinders, Relief | |
| Mounted Equipment | Loader and Backhoe, Boom, Dipper, Bucket, Stabilizers, Extendahoe | |
| Schematic Set | Full Electrical and Hydraulic Circuit Schematics for the Series 3 Loader Backhoes |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| 580M Series 3 | ||
| Loader Hydraulic Stall | 2230 to 2330 rpm | |
| 580 Super M Series 3 | ||
| Loader Hydraulic Stall | 2240 to 2335 rpm | |
| 580 Super M+ Series 3 | ||
| Loader Hydraulic Stall | 2350 to 2420 rpm | |
| 590 Super M Series 3 | ||
| Loader Hydraulic Stall | 2240 to 2335 rpm | |
| 590 Super M+ Series 3 | ||
| Loader Hydraulic Stall | 2350 to 2425 rpm | |
| Super M models | ||
| Backhoe Hydraulic Stall | 2160 to 2335 rpm | |
| All models | ||
| Standard Torque, Grade 8 (1/4 in) | 16 to 20 Nm (144 to 180 lb-in) | |
| Standard Torque, Grade 8 (5/16 in) | 33 to 39 Nm (288 to 348 lb-in) | |
| Production Years | 2004 to 2013 | |
Case 580M, 580 Super M, 580 Super M+, 590 Super M, 590 Super M+ Common Problems This Manual Covers
Transmission oil leak and loss of drive
A loss of drive is usually a transmission oil leak that drops the fluid level and the operating pressure. Find and repair the leak, refill to the correct level, and run the transmission pressure and hydraulic stall checks against the per model spec before returning to work. The power train section covers the pressures, the stall values and the service.
Manual Section: Power TrainEngine overheating during heavy loader operation
Overheating under load points to the cooling package, airflow or the water pump. Clean the radiator and cooler cores, check the fan and shroud and the coolant condition, and test the thermostat and water pump. The engine section covers the cooling system service and the checks to isolate a persistent overheat.
Manual Section: EngineBackhoe stabilizer will not lock
A stabilizer that will not hold is usually the stabilizer cylinder, the lock valve or a hydraulic leak. Inspect the cylinder rod and seals, check the lock valve and the circuit for internal leakage, and test the pressure against spec. The mounted equipment and hydraulics sections cover the stabilizer and lock service.
Manual Section: Mounted EquipmentFrequently Asked Questions
What does Case part number 87728449NA cover?
It is the full factory service manual for the Case Series 3 loader backhoes, the 580M, 580 Super M, 580 Super M+, 590 Super M and 590 Super M+, 1,467 pages covering the engine, fuel, electrical, steering, power train, brakes, hydraulics and mounted equipment, plus a full schematic set.
My Super M lost drive, where do I start?
A loss of drive is often a transmission oil leak that drops the fluid and the pressure. Check the transmission fluid level and for leaks, then run the pressure and stall checks against the per model spec. The power train section covers the transmission, the pressures and the service.
My backhoe stabilizer will not lock, what should I check?
A stabilizer that will not hold points to the stabilizer cylinder, the lock valve or a hydraulic leak. Inspect the cylinder and the lock, check for internal leakage, and test the circuit pressure. The mounted equipment and hydraulics sections cover the stabilizer service.
Does one manual cover all the M Series 3 backhoes?
Yes. The 580M, 580 Super M, 580 Super M+, 590 Super M and 590 Super M+ are covered together, with per model stall speeds and any model specific differences called out in each procedure.
Is this the same manual a Case dealer uses?
It is the factory service manual (part number 87728449NA), the same step by step repair, specification and torque data the Series 3 loader backhoes were built and serviced to.
