This 913-page Ford 2000, 3000, 4000, 5000, 7000, 3400, 3500, 3550, 4400, 4500, 5500, 5550 Service Manual is the Ford 2000 service manual pdf every shop with a row-crop fleet from 1965-1975 keeps within reach. Open it and you get wiring diagrams for the full electrical system, hydraulic schematics covering the lift cylinder, flow control valve, and system regulating valve, plus a full troubleshooting section and page after page of torque tables. You also get complete transmission overhaul procedures for Four Speed, Six Speed, Seven and Eight Speed, and Select-O-Speed setups, along with rear axle, steering, and front axle rebuild steps. Check fluid capacities before you crack the drain plug, and confirm PTO clutch pack clearances against factory numbers instead of a shop-manual guess passed down from the last mechanic. Your tractor doesn't care how old the iron is; it cares that the torque spec is right. Bookmarked and searchable, this PDF opens on your phone in the barn or your laptop on the bench.
What's Inside This Ford 2000–7000 Manual
| System | Pages | Key Topics |
|---|---|---|
| Ford Tractor Service Manual 1965-1975 | 1-107 | Foreward, Production Codes and Serial Numbers, New Model Supplement, Supplement |
| Engine Systems | 108-177 | Cylinder Head, Valves, And Related Parts, Engine Front Cover and Timing Gears, Oil Pan Sump and Oil Pan, Connecting Rods, Bearings, Pistons |
| Fuel Systems | 178-210 | Dry-Type Air Cleaner, Fuel Tank, Fuel Lines, And Fuel Filters, Fuel Pump, Carburetor, Fuel Injection Pump, Injectors |
| Electrical System | 211-283 | Wiring Harness Identification, Battery, Generator, Generator Regulator, Starting Motor, Ignition System |
| Clutches | 284-335 | Single Clutches, Double Clutches, Clutch Pilot Bearing, Clutch Release Bearing, Clutch Release Cross-Shaft Bushings, Clutch Pedal Bushings |
| Four Speed Transmission | 336-351 | Description and Operation, Overhaul Shifter Cover, Overhaul Front End, Overhaul Rear End, Complete Overhaul |
| Six Speed Transmission | 352-375 | Description and Operation, Shift Levers and Cover Overhaul, Front End Overhaul, Rear End Overhaul, Complete Overhaul |
| Seven and Eight Speed Transmission | 376-462 | Description and Operation, Shift Levers and Cover Overhaul, Front End Overhaul, Rear End Overhaul, Complete Overhaul, Dual Power Transmission |
| Select-O-Speed Transmission | 463-556 | Description and Operation, Adjustments, Rear End Overhaul, Front End Overhaul, Complete Overhaul, Repair of the Sub-Assemblies |
| Power Take-Off | 557-610 | Transmission P.T.O., Live P.T.O., Power Take-Off Shaft Assembly, P.T.O. Coupling, Control Valve, Clutch Pack |
| Rear Axle and Brakes | 611-662 | Rear Axle Shaft, Differential, Drive Pinion, Wheel Brakes, Transmission Handbrake, Brake Pedals |
| Hydraulic Systems | 663-742 | Lift Cylinder Assembly, Lift Cover Assembly, Flow Control Valve, Hydraulic Lift Pump, System Regulating Valve, Transmission Relief Valve |
| Steering Systems | 743-819 | Steering Gear, Power Steering Pump, Reservoir, Hydraulic Pipes, Steering Power Cylinders, Steering Column Shaft |
| Front Axle | 820-846 | Front Wheel Spindle, Radius Rod, Ball Cap, Front Axle Support, Front Wheel Track |
| Wheels and Tyres | 847-860 | Rear Wheel Track Adjustment, Power Adjusted Rear Wheels, Rear Wheel Disc, Tyre Replacement, Cast Iron Attaching Weights, Liquid Ballasting of Tyres |
| Separating the Tractor | 861-882 | Engine Assembly, Front Axle Assembly, Transmission Assembly, Rear Axle Assembly |
| Accessories and General | 883-908 | Belt Pulley, Belt Pulley Guard, Remote Control Valves, Control Valve, Detent Regulating Valve, Bypass Valve |
| Tractor Maintenance Schedule | 909-913 | - |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Hydraulic Systems | Part 11 | p. 1 |
| Engine Systems | Part 1 | p. 1 |
| Clutch disc (cerametallic button type) | 8 inches (20.32 cm) | p. 74 |
| Number of Bolts | 8 | p. 80 |
| Pressure plate grooving limit | 0.025 in. (0.64 mm.) | p. 295 |
| Flywheel grooving limit | 0.025 in. (0.64 mm.) | p. 295 |
| Flywheel refacing limit | 0.080 in. (2.03 mm.) | p. 295 |
Ford 2000–7000 Common Problems This Manual Covers
Ford 5000 clutch disc oil saturation with severe slippage and complete failure to engage gear.
Inspect the clutch assembly for transmission oil leaks. Measure the cerametallic button type clutch disc wear limit; replace if it exceeds 0.010 in. (0.25 mm.) as detailed on page 294. Torque the flywheel to crankshaft bolts to 100 to 110 lb. ft. (13.8 to 15.2 m.kg.) during reassembly on page 80.
Manual Section: Clutches p. 284Progressive bolt slackening failure with severe pressure plate cover distortion during routine maintenance.
Check the pressure plate for uneven stress damage. Measure the pressure plate grooving limit, replacing the unit if wear exceeds 0.025 in. (0.64 mm.) per page 295. Slacken the 8 bolts progressively in a cross pattern to prevent cover assembly bending during removal.
Manual Section: Clutches p. 284Hydraulic system failure to lift under load or occasional failure to lift during field operation.
Test the hydraulic pressure relief valve initial opening pressure. Adjust the valve if the pressure falls outside the 2150-2450 psi range shown on page 20. Inspect the lift cylinder assembly for internal leaks and verify the transmission relief valve is seating properly.
Manual Section: Hydraulic Systems p. 663Warning lights and gauges inoperative with intermittent or low generator output and slow engine crank.
Inspect the charging system components. Check the alternator belt deflection and adjust the tension to achieve 3/4 to 1 inch of play as specified on page 53. Test the battery and wiring harness connections if the generator warning light remains inoperative after belt adjustment.
Manual Section: Electrical System p. 211Frequently Asked Questions
What are the torque specifications for Ford 3000 cylinder head bolts?
For Ford 3000 engines, the cylinder head bolts (with engine cold) should be tightened to a torque of 95-105 lb. ft. (13.13-14.51 kg. m.). This ensures proper sealing and prevents distortion. p. 176
What are the torque specifications for Ford 3400 wheel lug nuts?
The wheel nuts for Ford 2000, 3000, 4000, and 5000 series tractors, which includes the Ford 3400, should be tightened to a torque of 304-336 lb. ft. (42.03-46.44 kg. m.). p. 859
What are the replacement specifications for a cerametallic button type clutch disc?
For current cerametallic button type clutch discs, replacement is necessary only when the buttons are worn to within 0.010 in. (0.25 mm.) of the rivet heads. For Ford 2000, 3000, and 4000 models, these discs have 3 pairs of cerametallic buttons and a total friction area of 22.8 in.² (147 cm.²). p. 294
What are the replacement specifications for the clutch pressure plate and cover assembly?
All current design pressure plate assemblies have a diameter of 11 in. (27.9 cm.) and are secured to the flywheel by six dowel bolts. It is important that all new pressure plate and clutch assemblies are checked and adjusted prior to installation in the tractor. p. 290
How quickly can I access this Ford 2000 & variants manual after buying?
A 913-page Service Manual in searchable PDF format, available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Can I print specific sections of this Ford 2000 & variants Service Manual?
Zero restrictions. The PDF is DRM-free. Print whatever sections you need to take out to the shop. Standard letter or A4 paper works.
Can I find hydraulic circuit diagrams in this Ford 2000 & variants manual?
Yes, complete hydraulic schematics with flow diagrams, valve configurations, and pressure specifications are included.
