Hunting for exact factory part numbers for your 1996-1998 New Holland 1725 compact tractor family (including the 3 CYL variant)? This 218-page New Holland 1725 parts catalog pdf maps out the complete exploded views for every chassis, drivetrain, and hydraulic component on your machine. You get page after page of highly detailed assembly diagrams, complete with hardware breakdowns and index numbers. Open to the hydraulic section to find exact part numbers for the two-spool remote control valve, or check the drivetrain group for complete mid-PTO and 9x3 transmission layouts. Verify the exact sizing for your front axle hardware, like the M14 x 1.5 x 35mm bolts, and look up the specific Ag-only 105-pound rear wheel weights before ordering replacements. Ordering the wrong hardware sets your shop back days. Grab this digital manual instantly, pull it up on your tablet, and get your parts order right the first time.
What's Inside This New Holland 1725, 1725 3 CYL Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Fuel System | Fuel Tank, Air Cleaner, Injection Pump & Lines, Injection Pump, Fuel Injector | |
| Cooling System | Oil Pump, Radiator | |
| Engine | Cylinder Block, Camshaft, Cylinder Head, Crankshaft & Pistons, Timing Gear Case, Muffler, Engine Gasket Kit | |
| Electrical System | Relay, Lights, Switches, Battery, Alternator, Worklights | |
| Clutch & Transmission | Clutch & Clutch Case, Front Transmission Case & Shifter, Gears, Rear Transmission Case & Shifter, Rear Transmission Gears, Control Levers | |
| PTO | Three-Point Hitch Assy., PTO Gears, Mid PTO Kit 9 X 3 | |
| Rear Axle, Differential & Brakes | Front & Rear Wheels, Rear Wheel Weights, Parking Brake, Brake & Wheel Shaft Case, Differential & Differential Lock Linkage, Pedals & Brake Lock | |
| Front Axle & Steering | Front Axle, Front Differential Gears, Steering Linkage, Steering Column, Piping, Power Steering Case, Power Steering Pump, Power Steering Cylinder | |
| Hydraulics & 3-Point Hitch | Lift Cover & Arms, Lift Cover Head, Control Valve, Hydraulic Pump & Piping, Hpl Control Valve, Deluxe Drawbar, Drawbar Kits, Hydraulic Pump | |
| Body & Operator Station | Step Plate, Kit, Floor Mats, Dashboard and Rear Hood, Seat & Seat Belt Set, Fenders, Hood and Related Parts | |
| Decals & Accessories | Tool Box, Decals | |
| Other Components | Front End Weights, Final Reduction Gears, Hpl Controls, Deluxe Three-Point Hitch & Kit, Fixed Clevis Hitch, Manifold Diverter Block, Aeration Parts, Column Shift |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Bolt, M14 x 1.5 x 35mm | M14 x 1.5 x 35mm | p. 17 |
New Holland 1725, 1725 3 CYL Common Problems This Manual Covers
Need to find the correct tie rod end part number for a New Holland 1725 with sloppy steering
Check the exploded view on page 17 to locate the exact FWD tie rod ends. Verify the casing mounting hardware matches the required M14 x 1.5 x 35mm bolt specification. Cross-reference the diagram numbers with your parts list to ensure correct fitment before ordering replacement components.
Manual Section: Front Axle (W/FWD) p. 17Can't identify the right hydraulic pump piping lines and filter numbers after spotting a massive fluid leak
Inspect the hydraulic parts diagram to identify the correct pump assembly and piping lines. Replace any missing bracket hardware with a standard M14 x 1.5 x 35mm bolt. Match the exploded view item numbers to the index to get the exact filter replacement code.
Manual Section: Hydraulic Pump & PipingConfused by the metric hardware descriptions in the parts index and need the exact inch equivalents
Review the metric conversion charts on page 217 to translate screw diameter and length into standard inches. Compare your required casing hardware against the listed M14 x 1.5 x 35mm bolt dimensions. Verify the translated thread pitch and length match your shop stock before starting reassembly.
Manual Section: General Infomation - Metric to Inches p. 217Frequently Asked Questions
What is the part number for the engine oil filter?
The engine oil filter part number is SBA140517020, as listed in the recommended dealer stocking list. p. 201
What is the part number for the air filter element?
The outer air filter element is part number 86549700, and the inner air filter element is part number 86549701. p. 142
What is the part number for the fuel filter element?
The fuel filter element part number is SBA360720020. p. 139
What is the part number for the fan belt?
The fan belt part number is 86517954. p. 92
How quickly can I access this New Holland 1725, 1725 3 CYL manual after buying?
A 218-page Parts Catalog in searchable PDF format, available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Can I print this New Holland 1725, 1725 3 CYL manual?
Zero restrictions. The PDF is DRM-free. Print whatever sections you need to take out to the shop. Standard letter or A4 paper works.
