Working on a 5625, 5625SX, or 5625DX and need factory numbers instead of guesswork? This 296-page Gehl 5625 shop manual PDF (OEM #907245) carries the full rebuild data for all three variants: chassis, T-bar controls, hydrostatic and hydraulic systems, electrical, and engine. The hydraulic schematics are variant-matched to the SX and DX, the wiring harness diagrams come with a circuit/function chart, and troubleshooting guides run across four major systems. Roughly 50 pages cover exploded views; another 200 walk through step-by-step procedures for tandem pump removal, planetary gearcase disassembly, lift/tilt cylinder rebuild, and QGS control module diagnostics. Torque the axle nuts to 120 lb-ft (163 Nm); hold hydrostatic charge pressure between 120-150 PSI on the DX. With the machine down, download it, open it on a tablet, and jump straight to the bookmarked section you need.
What's Inside This Gehl 5625, 5625SX, 5625DX Manual
| System | Pages | Key Topics |
|---|---|---|
| Specifications | 11-13 | Standard Features, Tire Options, Buckets & Capacities, Dimensions |
| Safety | 14-24 | Signal Words, Additional Safety Reminders, Mandatory Safety Shutdown Procedure, Lift Cylinder Mechanical Lock, Cylinder Lock Engagement, Cylinder Lock Disengagement |
| Decals | 25-28 | New Decal Application, Paint Finish, Decal List |
| Lubrication | 29-32 | Hydraulic Oil Reservoir, Crankcase Oil, Chaincases, Planetary Gearcase Oil, Grease Fitting Locations |
| Chassis | 33-60 | Introduction, Engine Access Cover Removal, Engine Access Cover Installation, Overhead Guard Removal, Overhead Guard Installation, Seat Removal, Seat Installation |
| Drive | 61-89 | Introduction, Drive Chain Adjustment, Drive Chain Removal, Drive Chain Installation, Axle & Sprocket Removal, Axle & Sprocket Installation, Axle & Wheel Bearing Disassembly |
| Controls | 90-179 | Introduction, T-Bar Removal, T-Bar Installation, T-Bar Position Adjustment, T-Bar Tracking Adjustment, Traction Controls, Left T-Bar Assembly, T-Bar Controls |
| Hydrostatic System | 180-190 | Introduction, Troubleshooting Guide, Case Drain Test, Charge Pressure Test & Adjustment, Tandem Pump Relief Valves, Tandem Pump Removal, Tandem Pump Installation |
| Hydraulic System | 191-239 | Introduction, Troubleshooting Guide, Relief Pressure Test, Control Valve, Tilt Cylinder Test, Self-Leveling Valve Test, Lift Cylinder Test, Solenoid Valve Test |
| Electrical System | 240-253 | Operation, Troubleshooting, Qgs Control Module Operation, Qgs Control Module Test, Glow Plug Test, Glow Plug Relay Test, Relay Test, Water Temperature Switch Test |
| Engine | 254-286 | Introduction, Troubleshooting Guide, Oil Filter Element Removal, Oil Filter Element Installation, Air Filter Assembly, Removal / Installation, Air Filter Element |
| Torque Specifications | 294-296 | Unified National Thread (8-32, 8-36, 10-24, 10-32, 1/4-20, 1/4-28, 5/16-18, 5/16-24, 3/8-16, 3/8-24, 7/16-14, 7/16-20, 1/2-13, 1/2-20, 9/16-12, 9/16-18, 5/8-11, 5/8-18, 3/4-10, 3/4-16, 7/8-9, 7/8-14, 1-8, 1-14) |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Axle Nuts torque | 120 lb-ft (163Nm) | p. 67 |
| Solenoid and Relief Valve Cartridges torque | 70 lb-ft (88 Nm) | p. 237 |
| Caliper Cap Screws torque | 24 ft./lbs (32.5Nm) | p. 146 |
| Tilt Cylinder Circuit maximum allowable setting | .38" (10 mm.) in 15 minutes | p. 198 |
| Lift Cylinder maximum allowable setting | .75 in. (19mm) in 15 minutes | p. 201 |
| Air Filter Element cleaning pressure | less than 30 PSIG (210 kPa) | p. 260 |
| Glow Plug resistance | approximately 13 ohms | p. 245 |
| Fan Belt deflection | .50 in. (13 mm) under a load of 20 lbs (9kg) | p. 265 |
| Drive Chain deflection | .25" @ 20 lbs. (6.35cm @ 9kg) | p. 63 |
| Chaincase oil level | approximately 1.5" (38mm) deep | p. 63 |
| SX Models | ||
| Charge Pressure Relief Valve operating pressure | 120 to 140 PSI | p. 188 |
| DX Models | ||
| Charge Pressure Relief Valve operating pressure | 120 to 150 PSI | p. 188 |
