Splitting a Kawasaki 95ZV wheel loader at the articulation joint and putting it back to factory standard is the job these 345 pages exist for, and this Kawasaki 95ZV shop manual PDF (OEM 93215-00242) runs from deck and cab removal through axles, transmission, hydraulics and brakes. The hydraulic group runs longest, taking the pump, boom and bucket cylinders, multiple control valve and Orbitrol apart, with the pilot valve covered in three serial-number versions. Exploded views back up the procedures, and service standard tables give you linkage pin clearances, clutch oil pressure and center pin shim adjustment. Rig for 360 kg (790 lbs) before a boom cylinder comes off, and torque the hydraulic tank's bolt (8) to 765 N-m (562 lb-ft) on reinstall. Alone with a dead loader, the book is the only one to ask. Bookmarks and a live text layer find your page in seconds, and you can print sections for the bench and let them collect grease.
What's Inside This Kawasaki 95ZV Manual
| System | Pages | Key Topics |
|---|---|---|
| General Information | 11-26 | Symbols, Weight of Main Components, Bolt Tightening Torque, Hose Band Tightening Torque |
| Disassembly & Reassembly Chassis Group | 27-48 | Deck (Removing and Installing), Fuel Tank (Removing and Installing), Hydraulic Tank (Removing and Installing), Engine Room (Removing and Installing), Cab (Removing and Installing) |
| Service Standard Chassis Group | 49-58 | Linkage (Pin Standard Clearance Values, Liner Clearance Adjustment), Center Pin (Shim Adjustment, Bearing Cover Installing, Lower Center Pin Bearing Outer Ring Installing) |
| Disassembly & Reassembly Power Group | 59-128 | Power Line (Tightening Torque), Radiator (Tightening Torque, Removing and Installing), Engine (Removing and Installing), Propeller Shaft (Removing and Installing) |
| Service Standard Power Group | 129-132 | Propeller Shaft Service Standard, Axle and Differential Service Standard (Axle Group) |
| Disassembly & Reassembly Torque Converter and Transmission Group | 133-182 | Torque Converter and Transmission Assembly (Tightening Torque, Removing and Installing), Torque Converter Assembly (Bolt Tightening Torque, Disassembling and Assembling) |
| Service Standard Torque Converter and Transmission Group | 183-188 | Transmission Assembly, Torque Converter Gear Pump (Gear Pump Specifications), Gear Train and Number of Teeth (Clutch Specifications), Clutch Oil Pressure |
| Disassembly & Reassembly Hydraulic Group | 189-268 | Hydraulic Parts Removal and Installation Warning, Hydraulic Parts Disassembly and Assembly Cautions, Hydraulic Pump Assembly (Removing and Installing, Disassembling and Assembling) |
| Service Standard Hydraulic Group | 269-274 | Hydraulic Cylinder, Pilot Valve, Steering Valve |
| Disassembly & Reassembly Brake Group | 275-310 | Unloader Valve (Removing and Installing, Disassembling and Assembling), Manifold Valve Assembly (Removing and Installing |
| Service Standard Brake Group | 311-318 | Brake Valve, Service Brake, Parking Brake |
| Disassembly & Reassembly Operator Station Group | 319-330 | Air Conditioner (Removing and Installing, Disassembling and Assembling, Compressor V-Belt) |
| Service Standard Operator Station Group | 331-345 | Air Conditioner (Periodical Inspection/Servicing, Tightening Torque) |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Boom cylinder weight | 360 kg (790 lbs) | p. 198 |
| Bolt (8) torque for hydraulic tank | 765 N-m (78.0 kgf-m) (562 lb-ft) | p. 32 |
| Air pipe insertion amount | 45-50 mm (1.8-2 in) | p. 71 |
| Air cleaner insertion amount | 25-32 mm (1-1.26 in) | p. 71 |
| Gear pump (double) weight | 40 kg | p. 137 |
| Clutch pressure at low idle | F1, F2, F3, F4, N1, N2, R1, R2, R3 in MPa (kgf/cm2) (psi) | p. 141 |
| Clutch pressure at high idle | F1, F2, F3, F4, N1, N2, R1, R2, R3 in MPa (kgf/cm2) (psi) | p. 141 |
| Bolt (Boom cylinder) torque | 843 N-m (86.0 kgf-m) (622 lb-ft) | p. 205 |
| Fuel Tank Capacity | 425 L | p. 29 |
| Hydraulic Tank Capacity | 150 L | p. 31 |
| Transmission Oil Capacity | 55 L | p. 135 |
| Front Axle Oil Capacity (Total) | 100 L | p. 80 |
Kawasaki 95ZV Common Problems This Manual Covers
Kawasaki 95ZV transmission main, low, high, reverse or speed clutch oil pressure reading below standard
Record clutch oil pressure at low idle and high idle in each range from F1 through R3 on the table on page 141. At high idle, main, low, high, reverse, 2nd and 3rd clutch readings must fall within 2.6 to 2.9 MPa (384 to 427 psi), and the 1st clutch within 2.5 to 2.8 MPa (370 to 412 psi), per page 188.
Manual Section: Service Standard Torque Converter and Transmission Group p. 188Rebuilt transmission 1st clutch or high clutch with piston stroke measuring outside the standard
Measure piston stroke on the 1st clutch against 4.5 ± 0.5 mm following page 175, then check the high clutch against 2.5 ± 0.5 mm on page 179. If either stroke falls outside standard, disassemble the clutch again and correct it before the transmission goes back in. Recheck clutch oil pressure on page 188 once installed.
Manual Section: Disassembly & Reassembly Torque Converter and Transmission Group p. 175Axle differential reassembled with ring gear and drive pinion backlash outside standard
Measure ring gear and drive pinion backlash following page 125 and set it within 0.30 to 0.41 mm (0.0118 to 0.0161 in) before closing up the differential. When servicing the front axle, fill to the 100 L total oil capacity on page 80 before the machine goes back to work.
Manual Section: Disassembly & Reassembly Power Group p. 125Boom and bucket cylinder piston nut torque varying by serial number during cylinder rebuild
Torque the boom cylinder piston nut to 6,669 N-m (4,920 lb-ft) following page 206. Check the bucket cylinder serial number first: S/N ~0272 and ~9065 take 4,217 N-m (3,111 lb-ft), while S/N 0273~ and 9066~ take 5,900 N-m (4,353 lb-ft). Torque the boom cylinder bolt to 843 N-m (622 lb-ft) on page 205.
Manual Section: Disassembly & Reassembly Hydraulic Group p. 206Steering cylinder rod cover and piston nut needing correct torque values on cylinder reassembly
Torque the steering cylinder rod cover to 1,765 N-m (1,302 lb-ft) following page 209, and run the piston nut to 1,275 N-m (941 lb-ft) as listed on page 206. Both values are high, so line up the torque tooling before you pull the cylinder apart.
Manual Section: Disassembly & Reassembly Hydraulic Group p. 209Kawasaki 95ZV center pin needing shim adjustment and bearing cover installation on reassembly
Add shims so that the center pin clearance is 0.1 ± 0.05 mm (0.0039 ± 0.0020 in), then install the bearing cover, following page 52. When fitting the lower center pin bearing outer ring, set its split perpendicular to the front-rear line of the machine as shown on page 53, and check linkage pin standard clearance values on page 51 while the frame is apart.
Manual Section: Service Standard Chassis Group p. 52Frequently Asked Questions
How do I troubleshoot low clutch oil pressure on a Kawasaki 95ZV?
To troubleshoot low clutch oil pressure, refer to the 'Clutch Oil Pressure' table on page 188. This table provides the expected pressure range of 2.6 ~ 2.9 MPa (27 ~ 30 kgf/cm2) (384 ~ 427 psi) for most clutch positions when the engine is at high idle. If pressures are outside these specifications, check the transmission hydraulic system for leaks or pump issues. p. 188
What is the tightening torque for the fuel tank retainer bolt on the Kawasaki 95ZV?
The retainer bolt for the fuel tank must be tightened to a torque of 765 N-m (78.0 kgf-m) (562 lb-ft). p. 29
What is the procedure for bleeding air from the service brake system?
To bleed the service brake system, connect a clean vinyl tube to the air bleeder nipple and place an oil can to receive the oil. Slightly loosen the air bleeder nipple, press the brake pedal several times until oil flows, then close the nipple. Repeat this process until no air remains in the oil, ensuring each wheel is completely bled. p. 78
What is the standard clearance for the boom cylinder piston rod on the Kawasaki 95ZV?
The standard clearance for the boom cylinder rod is 0.096 to 0.285 mm (0.0037 to 0.0112 in). p. 271
What is the tightening torque for the transmission assembly mounting bolts on the Kawasaki 95ZV?
The transmission assembly mounting bolts (3) and (4) must be tightened to 230 N-m (23.5 kgf-m) (170 lb-ft). p. 67
How quickly can I access this Kawasaki 95ZV manual after buying?
A 345-page Shop Manual in searchable PDF format, available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Am I free to print this Kawasaki 95ZV Shop Manual?
Yes. It prints from any PDF reader, so run off the pages you need for your own repair work.
