Kawasaki Mule 3000, 3010, 3020 (KAF620) Service Manual (incl. Wiring)

Name: Kawasaki Mule 3000, 3010, 3020 (KAF620) Service Manual (incl. Wiring)
Author: Kawasaki

$29.99

Type: Utility Vehicle

Years: 2001

Serial: JK1AFCE1X1B500001 | JK1AF620EEB600001 | JK1AFCF1X1B500001 | JK1AFCG1X1B500001 | JK1AF620GGB600001

331 Pages·48 MB·Searchable PDF·English·Print-Ready

✓ Wiring Diagrams
✓ Torque Specs
✓ Bookmarks

Preview Sample Pages (PDF)

Hunting for a Kawasaki Mule 3000 service manual PDF that actually came from the factory? This 331-page Kawasaki Service Manual (OEM 99924-1262-01) walks you through the 2001 Mule 3000, 3010, and 3020 utility vehicles, including the KAF620 E, F, and G variants. Inside: full electrical wiring diagrams, a factory troubleshooting guide, torque and locking agent tables, and step-by-step procedures for the KAF620 engine, converter drive belt, transmission, final drive, and brakes. You get cable, wire, and hose routing charts plus valve seat repair and carburetor rebuild instructions. Torque the cylinder head bolts to 22 N-m (16 ft-lb) and the carburetor cover bolts to 8.8 N-m (78 in-lb); the numbers are right there in print. No more chasing electrical gremlins with a test light and a hunch. Bookmarked and text-searchable; pull it up on your phone next to the machine and get wrenching.

What's Inside This Kawasaki Mule 3000, 3010, 3020 (KAF620) Manual

System	Pages	Key Topics
General Information	1-40	Quick Reference Guide, List of Abbreviations, Emission Control Information, Torque and Locking Agent, Cable, Wire, And Hose Routing
Fuel System	41-64	Throttle Pedal and Cable, Governor Link Mechanism, Carburetor, Air Cleaner, Fuel Pump and Fuel Filter, Fuel Tank
Cooling System	65-82	Coolant Level Inspection, Coolant Draining, Pressure Testing, Water Pump, Radiator and Radiator Fan, Thermostat
Engine Top End	83-100	Cylinder Head Compression, Valve Clearance Adjustment, Valve Seat Repair, Valve Stem Diameter, Rocker Arm/Shaft Wear, Spark Arrester Cleaning
Converter System	101-120	Air Cleaner Housing Removal, Drive Belt Deflection, Drive Pulley Disassembly, Spider/Wear Guide Clearance, Driven Pulley Inspection, Bushing Installation
Engine Lubrication System	121-132	Engine Oil Level Inspection, Oil and/or Filter Change, Oil Pump and Relief Valve, Oil Screen Cleaning/Inspection, Oil Pressure Switch
Engine Removal / Installation	133-136	Engine Removal, Engine Installation, Engine Positioning Plate
Engine Bottom End	137-152	Camshaft and Tappets, Cylinders and Pistons, Crankshaft and Connecting Rods, Breather Valve
Transmission	153-182	Transmission Oil Level, Transmission Case Splitting, Shift Lever Position Adjustment, Differential Gears and Shift Mechanism, Bearings and Oil Seal
Wheels / Tires	183-190	Wheel Alignment, Toe-In Adjustment, Wheel (Rim) Inspection, Tire Removal, Tire Installation, Tire Inspection
Final Drive	191-224	Front Final Gear Case Oil Change, Lsd Clutch Torque Inspection, Pinion Gear Unit Assembly, Bevel Gear Adjustment, Propeller Shafts, Drive Shaft and Axles
Brakes	225-244	Brake Fluid Changing, Master Cylinder Disassembly, Brake Hoses and Pipes, Brake Drums, Brake Panel Assemblies, Parking Brake Lever and Cables
Suspension	245-252	Strut (Front Shock Absorber), Strut Spring Replacement, Rear Shock Absorber, Front Suspension Arms, Leaf Springs and Dampers
Steering	253-262	Steering Wheel Position Adjustment, Steering Wheel Free Play, Steering Gear Assembly, Tie-Rod Length Adjustment, Dust Boot Inspection, Steering Knuckles
Frame	263-276	Seat and Seat Belts, Control Panel, Front Cargo Compartment, Cargo Bed, Front and Rear Bars, Front Fender Assembly, Rear End Sub-Frame
Electrical System	277-321	Battery Charging, Ignition System, Electric Starter System, Fuel Pump and Relay, Lighting System, Switches, Fuses, Wiring Diagram
Appendix	322-331	Troubleshooting Guide, General Lubrication, Bolt and Nut Tightening, Unit Conversion Table, Model Application

Quick Reference Specifications

Specification	Value	Page
Carburetor cover bolts	8.8 N-m (0.9 kg-m, 78 in-lb)	p. 16
Cylinder head bolts	22 N-m (2.2 kg-m, 16 ft-lb)	p. 12
Carburetor bolt torque	2.0 N·m (0.2 kg·m, 18 in·lb)	p. 43
Cover Mounting Bolts	2.9 N-m (0.3 kg-m, 26 in-lb)	p. 43
Float valve needle tip condition	smooth, without any grooves, scratches, or tears	p. 59
Intake Pipe Bolts Torque	8.8 N·m (0.9 kg-m, 78 in-lb)	p. 66
Cylinder Head Bolts Torque	22 N·m (2.2 kg-m, 16 ft-lb)	p. 88
Engine Oil Drain Plug Torque	22 N-m (2.2 kg-m, 16 ft-lb)	p. 88
Engine Oil Grade	API SF or SG class API SH or SJ with JASO MA class	p. 126
Transmission Oil Type	API "GL-5" Hypoid gear oil	p. 158
Transmission Oil Viscosity	SAE90: above 5°C (41°F)	p. 158
Front Final Gear Case Oil Type	API "GL-5 or GL-6" hypoid gear oil for LSD (Limited Slip Differential gears)	p. 194

Brand	Kawasaki
Model	Mule 3000, Mule 3010, Mule 3020, KAF620-E1, KAF620-F1, KAF620-G1, KAF620E, KAF620F, KAF620G
Machine Type	Utility Vehicle
Manual Type	Service Manual
Language	English
Format	Searchable PDF (Digital Download)
Pages	331
File Size	48 MB
Year Range	2001
Manual No.	99924-1262-01
Serial Range	JK1AFCE1X1B500001, JK1AF620EEB600001, JK1AFCF1X1B500001, JK1AFCG1X1B500001, JK1AF620GGB600001
Wiring Diagrams	Yes
Hydraulic Schematics	No
Torque Specifications	Yes
Bookmarked / Indexed	Yes
