All 120 pages of this Kubota MX4800, MX5200, and MX5800 operator manual zero in on one job: running and maintaining your tractors the way Kubota engineered them. You get daily pre-operation checklists, instrument panel warning indicators, complete DPF regeneration procedures, 3-point hitch position and draft control, PTO operation, and auxiliary hydraulics setup covering all three models. Packed into 47 pages of periodic service procedures, you'll find interval schedules from daily walkarounds to 3000-hour DPF muffler cleaning, plus engine and powertrain troubleshooting tables with error code display. Torque your front 4WD wheel bolts to 124.0-147.0 N-m (91.5-108.4 ft-lbs); rear bolts want 196.0-225.0 N-m (144.6-166.0 ft-lbs). No more chasing service intervals on the wrong page. Bookmarked by section, so pull it up on your phone, walk to the tractor, and work through it.
What's Inside This Kubota MX4800, MX5200, MX5800 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| Servicing of Tractor | 21-22 | Tractor identification plate, Tractor serial number, Engine serial number, ROPS identification plate, Diesel Particulate Filter serial number |
| Specifications | 23-25 | Specification table, Engine, Capacities, Dimensions, Traveling speeds, Hydraulic unit |
| Implement Limitations | 26-27 | Tread (max. width), Lower link end max. lifting capacity, Max. Drawbar Load, Trailer loading weight |
| Instrument Panel and Controls | 28-31 | Warning indicators, Gauges, Shift levers, Pedals, Control levers, Switches |
| Pre-Operation Check | 32 | Daily check, Walk around inspection, Engine oil level, Transmission oil level, Coolant level, Water separator |
| Operating the Engine | 33-46 | Exhaust Aftertreatment Devices (Diesel Particulate Filter Muffler, Main Gear Shift Lever), Range Gear Shift Lever (Handling Points, DPF Regeneration Process) |
| Operating the Tractor | 47-64 | Operating New Tractor (Do Not Operate The Tractor At Full Speed For The First 50 Hours, Changing Lubricating Oil For New Tractors), Boarding And Leaving The Tractor |
| PTO | 65-66 | PTO Operation (PTO Clutch Control Switch, To Turn ON, To Turn OFF), PTO Clutch Control Switch, Stationary PTO, PTO Shaft Cover And Shaft Cap |
| 3-Point Hitch & Drawbar | 67-71 | Top link, Lower link, Telescopic stabilizers, Check chains, Drawbar, Lifting rod |
| Hydraulic Unit | 72-76 | 3-Point Hitch Control System (Position Control, Draft Control, Mixed Control, Float Control, 3-Point Hitch Lowering Speed), Auxiliary Hydraulics (Hydraulic Block Type Outlet) |
| Tires, Wheels and Ballast | 77-82 | Tires (Inflation Pressure, Dual Tires), Wheel Adjustment (Front Wheels, Rear Wheels), Ballast (Front Ballast, Rear Ballast, Liquid Ballast In Rear Tires) |
| Maintenance | 83-87 | Service intervals, Lubricants, fuel and coolant, Periodic service, Daily check, Lubricating grease fittings, Replacing filters |
| Periodic Service | 88-114 | How To Open The Hood (Side Cover) |
| Storage | 115 | Tractor Storage, Battery Storage Procedures, Removing The Tractor From Storage |
| Troubleshooting | 116-117 | Engine Troubleshooting, Power Train Trouble Shooting, Error Code Display |
| Options | 118 | Engine Block Heater, Front End Weights, Front Bumper, Rear Wheel Weights, Sunshade, Front Grill Guard, Double Acting Remote Hydraulic Control Valve With Float Position |
| Appendices | 119-120 | Index, 3-Point Hitch Lowering Speed, Air Cleaner Primary Element |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Wheel bolt torque (Front wheels, 4WD) | 124.0 to 147.0 N-m (91.5 to 108.4 ft-lbs) | p. 79 |
| Wheel bolt torque (Rear wheels) | 196.0 to 225.0 N-m (144.6 to 166.0 ft-lbs) | p. 80 |
| Air cleaner primary element cleaning compressed air pressure | under 205 kPa (2.1 kgf/cm², 30 psi) | p. 77 |
| Air cleaner primary element replacement interval | Once every 1000 hours or yearly, whichever comes first | p. 77 |
| Fuel filter tightening | additional 1/2 turn only (by hand) | p. 84 |
| Fuel filter replacement interval | every 400 Hr | p. 83 |
| Engine oil filter tightening | additional 1/2 turn only (by hand) | p. 103 |
| Engine oil filter replacement interval | every 400 Hr | p. 83 |
| Hydraulic oil filter tightening | additional 1 turn only (with filter wrench) | p. 103 |
| Hydraulic oil filter replacement interval | every 400 Hr | p. 83 |
| Fan belt tension (deflection) | 12 mm (0.48 in.) | p. 77 |
| Fan belt tension (force) | 68.6 N (7 kgf, 15.4 lbs) | p. 77 |
Kubota MX4800, MX5200, MX5800 Common Problems This Manual Covers
Kubota MX4800 engine overheating indicator flashes during heavy bush-hogging and coolant boils over into the overflow reservoir. p. 89
Stop the engine, but don't stop it suddenly; allow it to idle for about 5 minutes. Then, inspect the radiator screen and grille for grass or debris buildup. Check the radiator hoses for leaks, as they require replacement every 4 years per the schedule on page 89. Refill the coolant reservoir once the engine cools.
Manual Section: TroubleshootingDPF regeneration warning light stays illuminated and soot accumulates rapidly when operating at low RPM. p. 33
Run the engine at the rated 2700 rpm to raise exhaust temperatures for auto regeneration as detailed on page 33. Check the exhaust aftertreatment devices. If the indicator flashes while in inhibit mode, move to a safe area and initiate a parked regeneration cycle.
Manual Section: Operating the EngineEngine cranks slowly or clicks repeatedly but will not start during freezing temperatures in the morning. p. 100
Test the battery voltage and ensure it meets the 600 A CCA minimum rating listed on page 100. Inspect the terminals for corrosion and clean if necessary. If the battery shows a white indicator window on page 99, replace it with a new 80D26R type.
Manual Section: Periodic ServiceLoader responds slowly and three-point hitch struggles to lift heavy implements when the fluid is warm. p. 24
Verify the transmission case fluid level is correct and holds the required 44.0 L (11.6 U.S.gals.) capacity. Inspect the transmission filter for restrictions. Verify the implement weight does not exceed the maximum lift force of 1300 kg (2870 lbs.) at the lift points shown on page 24.
Manual Section: SpecificationsFrequently Asked Questions
What do Kubota MX4800/MX5200/MX5800 error codes mean?
The Kubota MX series tractors display specific error codes on the liquid crystal display if there is a power train issue. For example, E-20 indicates a "Communication trouble", E-31 means "Meter's part code and ECU model setting not compatible", and E-95 signifies "Solenoid (PTO) is in trouble." If any error code appears, the manual advises contacting your local KUBOTA Dealer for repairs.
What is the torque spec for Kubota MX series wheel lug nuts?
For the front wheels (4-wheel drive), the wheel mounting bolts should be tightened to 124.0 to 147.0 N-m (91.5 to 108.4 ft-lbs). For the rear wheels, the wheel rim and/or disk mounting bolts should be tightened to 196.0 to 225.0 N-m (144.6 to 166.0 ft-lbs). After initial tightening, recheck torque after driving 200 m and 10 times of shuttle movement.
How to reset Kubota MX5800 warning light
For DPF regeneration warning lights, the indicator will turn "OFF" once the regeneration cycle is complete. This can happen automatically in "Auto Regeneration Mode" or by performing a "Parked Regeneration" procedure, which involves parking the tractor in a safe area and initiating the cycle. For other general warning lights, resolving the underlying issue will cause the light to turn off.
What are the replacement specifications for Air cleaner primary element?
The air cleaner primary element should be replaced once every 1000 hours or yearly, whichever comes first. If the machine is operated in dusty conditions, it should be cleaned more often. The replacement procedure is detailed in the "Cleaning Air Cleaner Primary Element" section.
What are the replacement specifications for Fuel filter?
The fuel filter should be replaced every 400 hours. The replacement procedure involves removing the old filter, applying clean fuel to the rubber seal of the new filter, tightening it, and then bleeding the fuel system as described in the "Replacing Fuel Filter" section.
Is this Kubota MX4800, MX5200, MX5800 Operator Manual a digital download?
This is a 120-page searchable PDF ready for immediate download. Works on any device — pull it up on your phone while you're under the hood. No shipping, no waiting.
Am I able to print pages from this Kubota MX4800, MX5200, MX5800 manual?
None at all — the PDF is DRM-free. Print whatever sections you need to take out to the shop. Standard letter or A4 paper works.
