Landini issued this book as OEM document 3549054 M2, the factory Workshop Manual for the Legend range, and all 380 pages cover ten tractor variants from the 105 through the 165, Legend badging included. If you searched for a Landini 105 workshop manual PDF, this is the genuine article, not a retyped summary. Hydraulic schematics trace the circuit from the power pack through the power steering and remote valves, wiring diagrams map the electronic power lift and the full electrical system, and the transmission chapter alone takes up roughly a sixth of the book. When the lift starts hunting, check filtration first: 40 micron on intake, 20 micron on delivery, then refill the gearbox with 85 liters after a split. Nobody else is coming out to the shed tonight. This bookmarked, text-searchable PDF rides on whatever screen you carry to the tractor, so it is with the machine when the weather window opens.
What's Inside This Landini 105, 115, 130, 145, 165 Legend Manual
| System | Pages | Key Topics |
|---|---|---|
| Working in Safety | 4-15 | Essential Rules for Accident Prevention, Rules of a General Character |
| Introduction to the Legend Range | 16-44 | Legend Range Overview, Legend Top Instruments and Controls |
| Engine | 45-67 | Technical Specifications, Combustion System |
| Clutch | 68-80 | Single-Plate Clutch, Double-Plate Clutch |
| Transmission | 81-141 | General Description, Gearbox Drive Shaft, Gearbox |
| Power Take-Off | 142-151 | Technical Specifications, Hydraulic Power Take-Off |
| Dana 4WD Axle | 152-162 | General Description, Axle Adjustments |
| Carraro 4WD Axle | 163-176 | General Description, Axle Adjustment |
| Hydraulic Circuit | 177-236 | General Hydraulic Circuit, Power Steering System, Hydraulic Power Pack |
| Mechanical Power Lift | 237-269 | Description of External Controls, Description of Lever Operation |
| Electronic Power Lift and Electrical System | 270-342 | Electronic Power Lift Control, Functional Tests of the Commands, General Electrical System |
| Air Conditioning System | 343-380 | Basic Principles, Operating Principle of a Cooling Cycle |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Double cartridge filter on intake | 40 micron | p. 181 |
| Filter on delivery | 20 micron | p. 181 |
| Engine Oil Capacity | 16.6L | p. 40 |
| Fuel Tank Capacity | 190L | p. 40 |
| Gearbox Oil Capacity | 85L | p. 40 |
| Brake Circuit Oil Capacity | 0.5L | p. 40 |
| Clutch Circuit Oil Capacity | 0.5L | p. 40 |
| Maximum Engine Power Rate | 2200 RPM | p. 47 |
| 105-115 | ||
| Front Axle Differential Housing Oil Capacity | 10L | p. 40 |
| Front Final Drive Oil Capacity (each) | 1.6L | p. 40 |
| 130-145-165 | ||
| Front Axle Differential Housing Oil Capacity | 11L | p. 40 |
| Front Final Drive Oil Capacity (each) | 1.8L | p. 40 |
Landini 105, 115, 130, 145, 165 Legend Common Problems This Manual Covers
Landini Legend 130 hydraulics sluggish once oil warms up, rear lift slow, remotes weak under load
Check the transmission oil level first; the gearbox and hydraulic circuit share the same 85 L fill. Replace both hydraulic filters, the 40 micron cartridge on the intake and the 20 micron element on delivery, listed on page 181. If the lift stays slow warm with fresh filters, test pump output per the Hydraulic Circuit section starting on page 177.
Manual Section: Hydraulic Circuit p. 177Power shuttle engages harshly, delays going into forward or reverse, response differs between directions
Verify gearbox oil level before chasing electronics; the transmission holds 85 L and low oil starves the shuttle clutch packs. Check the clutch pedal limit switch adjustment and the shuttle lever contacts, then trace the Hall effect sensor wiring using the diagram. Stop the tractor fully before reversing; shuttling on the move wears the clutch fast.
Manual Section: Transmission p. 81PTO drops out under load or throws false overspeed and seat switch alarms
Check the seat switch and its wiring first: codes 002818 (no operator detected) and 001883 (PTO overspeed) appear in the electronic fault-code table on page 323. Inspect the PTO speed sensor tip for metal debris and test its connector per the Power Take-Off section starting on page 142. Keep engine speed at or below the 2200 RPM rated maximum while load testing.
Manual Section: Power Take-Off p. 142Engine down on power under load with black exhaust smoke and heavy fuel use
Replace the fuel filter and drain any water from the 190 L tank, then service the air filter; a starved or choked engine smokes black under load. Work through the insufficient power and exhaust fumes charts on page 63. If smoke continues, check valve clearance and confirm the engine still pulls to its 2200 RPM rated speed.
Manual Section: Engine Troubleshooting p. 63Clutch slips under heavy load or wears out again soon after a fresh replacement
Check clutch pedal free play and bleed the hydraulic circuit; it holds only 0.5 L, so one small leak puts air in fast. Inspect the disc, pressure plate, and release bearing per the Clutch section starting on page 68. Stop completely before using the shuttle; reversing on the move is what kills these clutches before harvest ends.
Manual Section: Clutch p. 68Frequently Asked Questions
What are the torque specifications for the Landini cylinder head fixing bolts?
The cylinder head fixing bolts must be torqued to 110 Nm using the angular method. When replacing the gasket, ensure the bolts are in good condition and the sequence is correct. p. 55
What is the correct valve clearance for the Landini engine when hot?
For the engine when hot, the intake valve clearance is 0.20 mm and the exhaust valve clearance is 0.45 mm. p. 47
What is the procedure for bleeding air from the rear brake circuit?
To bleed the rear brake circuit, fill the reservoir with clean brake fluid, attach a tube to the bleed screw, and place the end in a transparent vessel. Fully depress the left brake pedal, unscrew the bleed screw by half a turn to let air and oil out, then tighten the screw before releasing the pedal. Repeat until no air bubbles remain. p. 136
What is the capacity of the fuel tank for the Legend tractor?
The fuel tank capacity for the Legend tractor is 190 liters. p. 27
What is the correct pressure setting for the maximum valve on the Landini hydraulic power lift?
The maximum valve setting for the electro-hydraulic control valve system on the power lift is 170 bar. p. 293
What format is this Landini 105 manual in?
This is a 380-page searchable PDF ready for immediate download. Works on any device, so pull it up on your phone while you're under the hood. No shipping, no waiting.
Can I print just the pages I need from this Landini 105 manual?
Yes, printing is unrestricted: a single page, a chapter, or the lot, on letter or A4.
