Getting the right part on order the first time is what the 148 pages of this Landini Atlas 100 and Atlantis 100 parts catalog PDF are built for, from the front weight frame to the rear handbrake. Exploded views break the 1004-40T Green engine down plate by plate (cylinder head, timing gear, balancer unit, injection equipment), with part numbers keyed to each callout so you can identify a component before it comes off. Hydraulics and linkage fill one of the largest sections, tracing the lift distributor, auxiliary cylinder lines and draft, position and intermix controls, while the electrical harness pages list the wiring components. Before you order, check which pump your tractor carries: the Bosch and Danfoss double-body units are listed separately, as are the Marelli and Iskra starter kits. A clutch job stalls fast when the wrong Luk kit shows up. Bookmarked and text-searchable, the PDF gets the tractor running again while the weather holds.
What's Inside This Landini Atlas 100, Atlantis 100 Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Accessories Mechanical | 1-7 | Weight Frame and Weights - Front Hook - Up to Serial N., Hitch Connections - Without Hitch, Rear Hook - Adjustable - C Type, Hook Pull - Rear, Drawbar - Lineare - Heavy Duty |
| Engine | 8-24 | Assembly - 1004-40T Green Engine, Cylinder Block - Plate D - 1004-40T Green Engine, Crankshaft, Pistons and Connecting Rods - Plate B - 1004-40T Green Engine |
| Engine Ancillary Equipment | 25-34 | Alternator - Iskra, Alternator Positioner, Starter Motor - Component Kit - Marelli Type, Starter Motor - Component Kit - Iskra Type, Oil Filter |
| Fenders Footsteps and Platform | 35-48 | Fenders - Front - 2 Wheel Drive, Fenders - Front - 4 Wheel Drive, Front Fenders Kit - 4 Wheels Drive, Fenders and Platform, Floor Platform - Rails Ladder |
| Front Axle and Steering | 49-71 | Front Wheels - Hoops and Tyres, Front Axle 2 Wheel Drive - Axle Support, Front Axle 4 Wheel Drive, Front Axle 4 Wheel Drive - Housing and Supports - with Differential Hydrolock |
| Hydraulics and Linkage | 72-103 | Hydraulics Equipment - Pipings and Pump, Hydraulic Pump - Double Body - Bosch, Hydraulic Pump - Double Body - Danfoss Type, Lift Distributor, Hydraulic Lift - Lift Arms |
| Rear Axle and Rear Brakes | 104-122 | Rear Axle - Differential, Rear Axle - Housing and Wheel Hub - Half Shaft, Rear Axle - Housing and Wheel Hub - Final Drive, Rear Axle - Housing and Wheel Hub |
| Sheet Metal | 123-126 | - Hood, - Panels, - Hood Bracket and Instrument Panel, Side Cover - Fan Guard |
| Transmission | 127-148 | Clutch - Dual Clutch Luk - 11, Flywheel Clutch 12, Clutch Control, Clutch Pedal and Linkage, Lower Clutch P.T.O., Front Centre Housing - Drive Shaft to Trans. Case - Clutch Box |
Landini Atlas 100, Atlantis 100 Common Problems This Manual Covers
Landini Atlas 100 starter motor component kit, can't tell whether the tractor needs the Marelli or Iskra type
Check the brand marking on the starter body before ordering anything. Open the Engine Ancillary Equipment section starting on page 25, then go to the starter motor listings, which are split into a Marelli type component kit and an Iskra type kit. Match the exploded view to your unit so the right kit arrives before the weather window closes.
Manual Section: Engine Ancillary Equipment p. 25Double body hydraulic pump replacement, unsure if the tractor has the Bosch or Danfoss type fitted
Inspect the pump body for the Bosch or Danfoss marking first, because the catalog lists the double body pump both ways. Open the Hydraulics and Linkage diagram on page 72, follow the pipings and pump layout, and order only from the parts list that matches your pump. A wrong pump costs days you don't have during planting.
Manual Section: Hydraulics and Linkage p. 721004-40T Green Engine piston, ring and conrod parts hard to pick out of the engine plates
Verify the engine is the 1004-40T Green Engine before you order internals. Start at the Engine parts diagram on page 8, then work through the Crankshaft, Pistons and Connecting Rods plate (Plate B) for the piston, pin, ring, conrod and crankshaft callouts. Cross-check the cylinder block and liner plate so the rebuild parts all match.
Manual Section: Engine p. 8Clutch parts lookup, can't tell the Luk dual clutch 11 from the flywheel clutch 12 listing
Check which clutch is fitted to your tractor before ordering, since the Transmission section lists a Dual Clutch Luk 11 and a separate Flywheel Clutch 12. Open the drivetrain parts diagram on page 127 and match the exploded view to the old assembly. Pull the clutch pedal, linkage and lower clutch P.T.O. part numbers into the same order.
Manual Section: Transmission p. 1274WD front axle housing and supports, unsure which listing covers the differential hydrolock version
Verify whether your tractor is 2 wheel drive or 4 wheel drive, and whether the front axle has the differential hydrolock, before ordering. Open the Front Axle and Steering section starting on page 49, which separates the 2WD axle support, the standard 4WD axle and the 4WD housing and supports with differential hydrolock. Order from the matching parts list only.
Manual Section: Front Axle and Steering p. 49Brake pedal, linkage, master cylinder and handbrake parts hard to locate in the rear axle section
Check the Rear Axle and Rear Brakes section starting on page 104, then move past the differential and wheel hub plates to the brakes listings. The pedals, linkages, master cylinder and handbrake are grouped there with their exploded views. Match each callout to the worn part on the tractor so you order once and get back in the field.
Manual Section: Rear Axle and Rear Brakes p. 104Frequently Asked Questions
What are the fuel filter replacement specs for the Landini Atlas 100, Atlantis 100 tractor?
The fuel filter cartridge for the Landini Atlas/Atlantis 100 is part number 26561117. This cartridge is used in the low-pressure fuel system (Plate W) and is specified for replacement as part of the fuel system maintenance. p. 22
What are the engine oil filter replacement specs for the Landini Atlas 100, Atlantis 100?
The engine oil filter cartridge for the 1004-40T engine is part number 2654403. This cartridge is used in the heat exchanger and lubricating oil filter assembly (Plate Q). p. 17
What is the part number for the alternator used on the Atlas/Atlantis 100?
The alternator for the Atlas/Atlantis 100 (Iskra type) is identified by part number 3552682M92 or 3559922M91. p. 25
What is the part number for the starter motor on the Atlas/Atlantis 100?
The starter motor (Marelli type) for the Atlas/Atlantis 100 is part number 3539390M92. p. 26
Is this Landini Atlas 100 manual a PDF I download?
Delivery is instant: a 148-page searchable PDF is yours the second checkout clears. Laptop, tablet, or phone, all fine.
Is this Landini Atlas 100 Parts Catalog printable?
Yes. Print the pages you need for the job in your own shop, and bin them when they get greasy.
Is there a hydraulic diagram in this Landini Atlas 100 Parts Catalog?
The catalog includes exploded-view parts diagrams of hydraulic components for the Landini Atlas 100, Atlantis 100, Atlas- (ATLANTIS) 100, not hydraulic circuit schematics. See page 63 for an example showing the steering hydraulic lines.
