All 951 pages of this McCormick F Series Training Manual (OEM #3676090M1) focus on one job: keeping your F 60, F 70, F 75, F 80, F 85, F 95, and F 105 tractors, including GE, XL, and GT variants, at factory spec. You get full hydraulic schematics for both orchard and vineyard circuit configurations, Speedfive and Powershuttle wiring diagrams with sensor, solenoid, and instrument breakdowns, plus a complete troubleshooting chapter with alarm codes, autodiagnosis procedures, and calibration sequences for clutch pedal and secondary clutch limit adjustment. Set clutch pedal free travel to 3.5-4 cm; torque the 11-inch clutch fixing screws to 23 Nm and the 12-inch to 66 Nm. No more guessing which wire feeds which solenoid on a vineyard-spec machine. Bookmarked by chapter, searchable by keyword; bring it up on your tablet before you crack the first cover bolt.
What's Inside This McCormick Landini F60-F105 Series Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction | 3-67 | Manual Structure, Tractor Identification, Working in Safety, Pre-Delivery Inspections, Conversion Tables, Sealants, Driving Torques, General Assembly Instructions |
| Engine | 68-87 | Safety Recommendations, Technical Specifications, Driving Torque Values, Engine Tuning, Injection Pump Timing |
| Clutch | 88-103 | Safety Warnings, Assembly Drawings, Operation Description, Technical Specifications, Inspection and Overhaul, Adjustment |
| Transmission | 104-289 | Safety Recommendations, General Description (Speedfive, Powershuttle, 2WD/4WD), Technical Specifications, Driving Torques and Sealants, Disassembly/re-assembly |
| Wd Front Axle | 290-323 | Safety Recommendations, General Description, Technical Specifications, Driving Torques and Sealants, Disassembly/re-assembly, Bevel Gear Adjustments |
| Rear Power Take-Off | 324-361 | Safety Recommendations, Independent PTO Operation, Proportional PTO Operation, Technical Specifications, Driving Torques and Sealants, Disassembly/re-assembly |
| Hydraulic Circuit - Orchard Tractors | 362-551 | Safety Warnings, Low Pressure Circuit, High Pressure Circuit, Hydraulic Braking System (Operation, Bleeding, Adjustment), Auxiliary Control Valves, Operating Pressure Tests |
| Mechanical Power Lift | 552-589 | Safety Recommendations, Operating Modes (Position, Draft, Mixed, Float), Valve System Components, Operating Phases, Technical Specifications, Driving Torques, Hydraulic Tests |
| Electrical System - Orchard Tractors | 590-849 | Safety Recommendations, Basic Electrical Concepts, Wiring Diagrams (Speedfive, Powershuttle), Sensors and Potentiometers, Solenoid Valves, Switches and Buttons, Instrument |
| Calibration | 850-871 | Safety Warnings, Calibration Introduction, Components Involved, Calibration Procedure (Clutch Pedal, Secondary Clutch Limit, Main Clutch Limit) |
| Troubleshooting | 872-907 | Safety Warnings, Autodiagnosis, Conventional Troubleshooting, Alarm Codes, Terminal Involvement, Remedies |
| Special Tools | 908-951 | Clutch Centering Tools, Shaft Assembly Supports, Spring Compressors, Bearing Adjustment Tools, Wrench for Ring Nuts, Pressure Measuring Unions, Pivot Pin Extractors |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All Models | ||
| Clutch pedal free travel (clearance) | 3.5-4 cm | p. 101 |
| Gearbox clutch plate material (replacement value) | cerametallic | p. 97 |
| PTO clutch plate material (replacement value) | organic | p. 97 |
| Hydraulic Pump Max Operating Pressure | 180 bar | p. 393 |
| Mechanical Power Lift Max Lift Capacity (with two auxiliary cylinders) | 4200 kg | p. 571 |
| 11" clutch | ||
| Clutch fixing screws torque (torque value) | 23 Nm | p. 131 |
| F 60, F 75, F 85 | ||
| Engine Compression Ratio | 19.3:1 | p. 16 |
| F 70, F 80, F 95, F 105 | ||
| Engine Compression Ratio | 18.2:1 | p. 16 |
| F 60-70-80-75 | ||
| Clutch Plate Size (Gearbox/PTO) | 11" | p. 97 |
| F 85-95-105 | ||
| Clutch Plate Size (Gearbox/PTO) | 12" | p. 97 |
| all 4WD models | ||
| Front Brakes Total Braking Area | 955.18 cm2 | p. 130 |
McCormick Landini F60-F105 Series Common Problems This Manual Covers
McCormick F-series clutch pedal spongy or dragging, gear changes grinding or incomplete
Check clutch pedal free travel at the pad; correct clearance is 3.5-4 cm (page 101). Inspect the cerametallic gearbox disc and organic PTO disc for glazing or wear (page 97). On F 60-70-80-75 models the plate is 11"; F 85-95-105 uses 12". Torque clutch fixing screws to 23 Nm (11" clutch) or 66 Nm (12" clutch) per page 131.
Manual Section: Clutch p. 101Engine cranks but won't fire, or turns over too slowly to start in cold weather
Verify fuel shutoff is fully open and battery terminals are clean and tight. Check injection pump timing per the engine section on page 68. Reference compression specs on page 16: F 60, F 75, and F 85 require 19.3:1; F 70, F 80, F 95, and F 105 require 18.2:1. Low numbers on cold cranking indicate ring or valve wear.
Manual Section: Engine p. 68Three-point hitch won't lift to working height or slowly drops under load
Measure hydraulic system pressure at the test port; pump maximum operating pressure is 180 bar (page 393). If below spec, inspect the relief valve and pump seals for wear or bypass. Work through the 'fails to lift,' 'slow to lift,' and 'fails to keep raised' troubleshooting table in the mechanical power lift section starting on page 552.
Manual Section: Mechanical Power Lift p. 552Alarm code 98 on the dash, clutch pedal spongy, transmission won't engage gears
Inspect the clutch pedal potentiometer connector and harness for corrosion; alarm code 98 (page 883) confirms the fault. Adjust the potentiometer per the electrical system section on page 590, then run calibration C3 on page 861. Verify pedal free travel is 3.5-4 cm (page 101) and confirm the code clears before returning the tractor to service.
Manual Section: Troubleshooting p. 883Rear PTO engages but cuts out under load without warning, shaft stops
Check PTO solenoid valve wiring for breaks or corrosion; alarm codes 80 or 81 confirm a solenoid valve fault (page 883). Verify hydraulic pump pressure reaches 180 bar (page 393). Inspect the organic PTO clutch disc (page 97) for glazing or oil contamination, and replace if slip persists after confirming good pressure and clean electrical connections.
Manual Section: Rear Power Take-Off p. 324Frequently Asked Questions
How to reset the transmission control module on McCormick F 75?
The manual does not describe a general 'reset' procedure for the transmission control module. However, if the electronic control unit (_D02) is replaced, the clutch assemblies that engage the Powershuttle unit must be calibrated. This calibration can be initiated by depressing both buttons X1 and X2 on the instrument for longer than 100 msec when the instrument is in default status, which compels the control unit to go into the parameter calibration mode. p. 828
How quickly can I access this Mccormick F 60, F 70, F 80, F 75, F 85, F 95, F?
Instant PDF download (63 MB). You get the full 951-page searchable Training Manual immediately after payment. Open it on your laptop, tablet, or phone right in the shop.
Can I print this Mccormick F 60, F 70, F 80, F 75, F 85, F 95, F 105, F 60 GE?
Yes, print as many copies as you want, and there are no restrictions. Many mechanics print the section they need and bring it to the shop floor.
Can I find wiring schematics in this Mccormick F 60, F 70, F 80, F 75, F 85, F?
Yes, this Mccormick F 60, F 70, F 80, F 75, F 85, F 95, F 105, F 60 GE, F 70 GE, F 80 GE, F 85 GE, F 95 GE, F 105 GE, F 75 XL, F 85 XL, F 95 XL, F 105 XL, F 85 GT, F 95 GT, F 105 GT, F 60-70-80, F 75-85-95-105 GE-XL Training Manual includes a wiring diagram for the electrical system.
