This is the factory service manual for the New Holland T4 orchard and low-profile tractors: the T4.80F, T4.90F, T4.100F and T4.110F orchard models and the T4.80LP, T4.90LP, T4.100LP and T4.110LP low-profile models, part number 51523358. It follows the CNH product structure, so you work from the system rather than a chapter number, and it identifies each model by serial number and by whether it has a cab. More than half the book is electrical, and most of that is harness drawings, connector diagrams and the fault-code tables with the guided test behind each code.
What's Inside This New Holland T4.80-T4.110 F and LP Series Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction and Standard Torques | 11-36 | How to Use the Manual, Shop Safety, Standard Tightening Torques, Approved Fluids, Model and Serial-Number Identification for Cab and Cabless Builds |
| Engine | 37-306 | Engine and Crankcase, Pump Drives, Fuel Tank and Filters, Air Cleaner and Lines, Intake and Exhaust Manifolds, EGR Exhaust Treatment, Cooling System, Fan Drive, Aftercooler |
| Clutch | 307-366 | Clutch Assembly and Release Mechanism, Pedal Free Play, Clutch Removal and Refitting |
| Transmission | 367-536 | Gearbox, Shuttle and Range Units, Synchronisers and Shift Forks, Control Valves and Clutch Packs, Transmission Overhaul |
| Four-Wheel Drive (4WD) System | 537-574 | 4WD Engagement Clutch and Control, Drive Shaft and Supports, 4WD Testing and Overhaul |
| Front Axle System | 575-688 | Driven Front Axle, Bevel Drive and Differential, Hub Reduction, Steering Knuckles and Pivots, Axle Rebuild |
| Rear Axle System | 689-736 | Rear Bevel Gear Pair and Differential, Electro-Hydraulic Differential Lock, Final Drives, Bearing Preload and Backlash |
| Power Take-Off (PTO) | 737-794 | Rear PTO Clutch and Brake, Hydraulic PTO Clutch Control, Speed Selection and Output Shaft Change, PTO Overhaul |
| Brakes and Controls | 795-904 | Wet Disc Service Brakes, Parking Brake, Pedal Adjustment, Bleeding the Brake Circuit |
| Hydraulic Systems | 905-1096 | Fixed Displacement Pumps, Hydraulic Schematics for Each Transmission and Lift Build, Rear Lift with Mechanical Draft Control, Open-Centre Rear Control Valves, Relief Valve Settings and Pressure Testing |
| Hitches, Drawbars and Implement Couplings | 1097-1192 | Rear Three-Point Hitch and Lift Links, Front Hitch, Drawbars and Pick-Up Hitch, Implement Coupling and Setting |
| Frames and Ballasting | 1193-1200 | Chassis and Frame, Front and Wheel Ballast, Weight Fitting |
| Steering | 1201-1268 | Hydrostatic Steering Unit and Circuit, Steering Control Valve and Cylinder, Steering Column, Fault Finding |
| Wheels | 1269-1284 | Wheel and Tyre Fitment, Orchard and Low-Profile Track Settings, Wheel Nut Torques |
| Cab Climate Control | 1285-1442 | Heating, Ventilation and Air Conditioning, Compressor and Condenser, Refrigerant Handling, Circuit Charging and Leak Testing |
| Electrical Systems: Harnesses and Connectors | 1443-2099 | Complete Wire Harness Drawings, Connector Component Diagrams, Fuse and Relay Layouts, Pin-Out Tables, Component Location |
| Electrical Systems: Engine and Cab Control Circuits | 2100-2644 | Cab Engine Controls, Engine Control System, Starting and Charging Circuits, Electronic Control Modules, Lighting and Instruments |
| Electrical Systems: Fault Codes and Diagnostics | 2645-3352 | Fault-Code Index and Tables Including Solenoid Energizing-Time Comparison Faults, Guided Diagnostic Test Procedures |
| Accessories | 3353-3362 | Fitted Accessories and Their Service Points |
| Platform, Cab, Bodywork and Decals | 3363-3565 | Cab and Platform Assembly, Bodywork Panels, Hood and Grille, Glazing, Decals, Component Removal |
| Special Tool Index | 3566-3575 | Part Numbers of the Special Service Tools Each Procedure Calls for |
