Need the factory operating reference for your Case 1594 diesel tractor? This 235-page Case 1594 Tractor Operator Manual covers both 2WD and MFD configurations, with and without cab, across Synchromesh and Power Shift transmission variants. Inside: a full safety section with pre-start checklists, operation rules, and service warnings, plus a complete lubrication chart mapping every grease fitting, oil change interval, and fluid capacity from the engine sump to the MFD front hubs. You also get tire load and pressure tables for rear and front tires, wheel tread position diagrams for every axle configuration, and tractor speed charts split by transmission type and PIN cutoff. The 5.4-litre diesel peaks at 329 Nm; reference the brake disc diameter at 222 mm when inspecting system condition. Your machine won't wait on forum guesses. Grab the PDF, pull it up on your phone or tablet, and search any spec by keyword the moment you need it.
What's Inside This Case Case Tractor Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| To the Owner | 3-4 | - |
| Safety | 5-19 | - |
| Hand Signals | 20-21 | Start the Engine, This Far to Go, Stop the Engine, Move Out, Move Toward Me - Follow Me, Come to Me |
| Decals | 22-26 | - |
| Serial Numbers | 27 | Model Number, Product Identification Number, Engine Serial Number, MFD Axle Serial Number, Cab Serial Number, ROPS Serial Number |
| Diesel Engine Specifications | 28-30 | General, Piston and Rod, Main Bearings, Cooling System |
| General Specifications | 31-34 | Electrical System, Brakes, Steering, Power Takeoff (PTO), Three Point Linkage, Drawbar |
| Approximate Tractor Speeds | 35-38 | Synchromesh Transmission (Prior to P.I.N. 11221501), Synchromesh Transmission (From P.I.N. 11221501), Power Shift Transmission (Prior to P.I.N. 11219488) |
| Fuel Specifications | 39 | A.P.I. Gravity, Pour Point, Distillation, Flash Point, Kinematic Viscosity, Cetane Number |
| Approximate Measurements | 40-43 | 2WD Tractor Without Cab, MFD Tractor Without Cab, 2WD Tractor with Cab, MFD Tractor with Cab, Approximate Transport Weight |
| Tire and Wheel Equipment | 44-45 | Tire Sizes, Loads and Pressures, Table of Rear Loads and Pressures, Notes, Rear Tire Mounting |
| Tire Arrangements - MFD | 46 | Synchromesh Transmission, Power Shift Transmission |
| Front Wheel Tread Positions - 2WD | 47 | 2 Wheel Drive Tractor |
| Front Wheel Tread Positions - MFD | 48-50 | MFD Tractors Prior to P.I.N. 11221501 with W12 X 24 Wheels Fitted |
| Rear Wheel Tread Positions | 51 | - |
| Power Adjust Rear Wheel Tread Positions | 52 | - |
| Lubrication | 53-56 | Engine Hourmeter, Diesel Engine Oil, Capacities and Approved Lubricants, Lubrication Chart, Grease Fittings, Engine Oil Change, Engine Oil Filter Change |
| Operating Controls Tractor Without Cab Instrument Panel | 64-68 | - |
| Cab Air Flow Arrangements | 69-73 | - |
| Control Levers Tractor with Cab Left-Hand Side | 74-77 | - |
| Control Levers Tractor with Cab Right-Hand Side | 78-193 | - |
| Compressor Belt Replacement | 194-235 | - |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Brake Disc Diameter | 222 mm (8.75 inch) | p. 31 |
| Engine Bore | 100.5 mm | p. 28 |
| Engine Stroke | 114.3 mm | p. 28 |
| Piston Displacement | 5.4 litre | p. 28 |
| Maximum Engine Torque | 329 Nm | p. 28 |
| Engine Valve Clearance (Cold) | 0.25 mm | p. 28 |
| Cooling System Capacity | 16 U.S. quarts | p. 28 |
| Engine Oil Capacity | 13 U.S. quarts | p. 29 |
| Fuel Tank Capacity (With Cab) | 36 U.S. gallons | p. 29 |
| PTO Output Shaft Diameter | 34.9 mm | p. 30 |
Case Case Tractor Common Problems This Manual Covers
Case Tractor rear brakes locking up or making grinding noises after 100 hours of operation p. 30
Inspect the brake linkages for proper movement and clearance. Measure the brake disc diameter to ensure it meets the 222 mm (8.75 inch) specification found on page 30. Clean the power star brake assembly and verify the pedal free play is set correctly before returning the machine to service.
Manual Section: Diesel Engine SpecificationsPower take-off shaft will not attach to the implement and collar slides forward loosely
Pull back on the spring-loaded PTO release collar instead of pushing it forward. Verify the implement driveline matches the 34.9 mm (1-3/8 inch) output shaft diameter. Clean any packed dirt from the splines and apply a light coat of grease before attempting to connect the shaft.
Manual Section: General SpecificationsEngine will not turn over or start when turning the ignition key in the operator cab p. 29
Verify the PTO lever is fully disengaged and the transmission is in neutral. Check the dipstick to ensure the crankcase is filled to the 12.5 litres (13 U.S. quarts) capacity shown on page 29. Inspect the neutral start switch for corrosion or a damaged switch ball.
Manual Section: Diesel Engine SpecificationsEngine overheating and coolant temperature gauge reading high during heavy field operations p. 28
Check the coolant level in the radiator recovery tank before starting a cold engine. Drain and flush the cooling system, refilling it to the 15.3 litres (16 U.S. quarts) capacity detailed on page 28. Inspect the radiator fins for blockages and clear any packed dirt.
Manual Section: Diesel Engine SpecificationsFrequently Asked Questions
What are the replacement specifications for Fuel filters?
Fuel filters should be replaced with new elements every 400 hours of service. After replacing the fuel filters, it is necessary to remove air from the system and ensure there is a minimum of 9 litres (2 gal) of fuel in the tank.
How do you fix case Tractor rear brakes locking up or making grinding noises after 100 hours of operation?
Inspect the brake linkages for proper movement and clearance. Measure the brake disc diameter to ensure it meets the 222 mm (8.75 inch) specification found on page 30. Clean the power star brake assembly and verify the pedal free play is set correctly before returning the machine to service.
How do you fix power take-off shaft will not attach to the implement and collar slides forward loosely?
Pull back on the spring-loaded PTO release collar instead of pushing it forward. Verify the implement driveline matches the 34.9 mm (1-3/8 inch) output shaft diameter. Clean any packed dirt from the splines and apply a light coat of grease before attempting to connect the shaft.
How do you fix engine will not turn over or start when turning the ignition key in the operator cab?
Verify the PTO lever is fully disengaged and the transmission is in neutral. Check the dipstick to ensure the crankcase is filled to the 12.5 litres (13 U.S. quarts) capacity shown on page 29. Inspect the neutral start switch for corrosion or a damaged switch ball.
How will I receive this Case Tractor Operator Manual?
A 235-page Operator Manual in searchable PDF format, available the moment you complete checkout. View on computer, tablet, or phone, with no shipping wait.
Can I print specific sections of this Case Tractor Operator Manual?
Yes, print as many copies as you want, and there are no restrictions. Many mechanics print the section they need and bring it to the shop floor.
