All 337 pages of this Cnh Industrial Cursor 11 Service Manual (OEM #47608463) cover the F3GFE613A*B001 and F3GFE613B*B001 engine variants, focused entirely on the aftertreatment system: DEF/AdBlue dosing modules, SCR humidity and temperature sensors, NOx sensor ECU reset procedures, and NH3 sensor specifications. You get electrical system overviews and sensor specifications including pinouts and resistance values, plus a full torque section, exploded component views, system diagrams, and test values. Torque the crankcase inner bolts to 120 N-m (89 lb ft) at Stage 2, rotate an additional 60° for Stage 3, and confirm idle oil pressure at 3 bar (43.5 psi). Chasing an SCR fault without factory data means swapping parts blindly. Pull up this bookmarked PDF on your tablet, jump straight to the NOx downstream reset procedure or DEF quality sensor spec, and get back to work.
What's Inside This Cnh Industrial F3GFE613A*B001, F3GFE613B*B001, Cursor 11 Manual
| System | Pages | Key Topics |
|---|---|---|
| Ammonia (NH3) Sensor - General Specification | - | Heater Resistance, Heater Control Frequencies, Isolation Between Sensor Circuit and Housing, Isolation Between Heating Element and Sensor Housing, Internal Leak |
| Diesel Exhaust Fluid (DEF)/AdBlue® Dosing Module - General Specification | - | Electric Power Requirements, Hydraulic Capability, Normal Circulation and No Injection, Maximum with the Small Urea Injector, Maximum with the Large Urea Injector |
| Diesel Exhaust Fluid (DEF)/AdBlue® Dosing Module - Overview | - | Valve Keeper DEF/AdBlue® Connector, Coolant Connections, Heat Shield, Cooling Adapter, Electrical Connector, Dosing Valve |
| Diesel Exhaust Fluid (DEF)/AdBlue® Quality Sensor - Cleaning | - | Locking Tabs, DEF/ADBLUE® Quality Sensor, DEF/ADBLUE® Quality Sensor Cover |
| Diesel Exhaust Fluid (DEF)/AdBlue® Quality Sensor - Overview | - | DEF Fluid Quality, DEF Quality Sensor |
| Diesel Exhaust Fluid (DEF)/AdBlue® Supply Module - Overview | - | Supply Module, DEF Inlet From Tank, Coolant Connector, DEF Backflow to Tank, DEF Outlet to Dosing Module, Main Filter |
| Diesel Exhaust Fluid (DEF)/AdBlue® Tank Level and Temperature Sensor - General Specification | - | Working Temperatures, Maximum Ratings, Voltage, Current, Power, Temperature Resistance |
| Diesel Exhaust Fluid (DEF)/AdBlue® Tank Level and Temperature Sensor - Overview | - | Level and Temperature Sensor Connection, Coolant Heater Coil Connections, Urea Suction and Return Connections, Level Sensor, Temperature Sensor, Coolant Heater Coil |
| Nitrogen Oxides (NOx) Sensor - Configure - Reset ECU Data (Downstream Sensor) | - | Electronic Service Tool (Est) Connection, Configuration Icon, Replacement of Nox Downstream Sensor, Configure Selected Item Button, Reset Button |
| Nitrogen Oxides (NOx) Sensor - Configure - Reset ECU Data (Upstream Sensor) | - | Electronic Service Tool (Est) Connection, Configuration Icon, Replacement of Nox Upstream Sensor, Configure Selected Item Button, Reset Button |
| Nitrogen Oxides (NOx) Sensor - Dynamic Description | - | NOx Sensor Components, Processor, Engine Control Unit (ECU), Engine CAN Data Bus, Upstream NOx Sensor, Down Stream NOx Sensor |
| Selective Catalytic Reduction (SCR) Humidity Sensor - General Specification | - | Voltage Supply, Current Consumption, Humidity Operating Range, Temperature Operating Range, Output Voltage Range, Resistance |
| Selective Catalytic Reduction (SCR) Humidity Sensor - Overview | - | Intake Air Humidity Sensor, Inlet Air Plumbing, Air Filter, Turbocharger, Controlled Emissions, Engine Control Unit (ECU) |
| Selective Catalytic Reduction (SCR) Temperature Sensors - General Specification | - | Grey Wire, White Wire, Operational Current, Pull-Up Voltage, Temperature, Sensor Resistance |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Crankcase Under block outer hex bolts (Stage 1) | 30 Nm (22 lb ft) | p. 32 |
| Crankcase Under block inner bolts (Stage 2) | 120 Nm (89 lb ft) | p. 34 |
| Engine Displacement | 11120 cm³ | p. 20 |
| Engine Oil Pressure - Idling (Warm engine) | 3 bar (43.5 psi) | p. 20 |
| Thermostat (Start of opening) | 81 °C (177.8 °F) | p. 20 |
| Intake Valve Lash Setting (cold engine) | 0.35 - 0.45 mm (0.01 - 0.02 in) | p. 20 |
| Injection Pressure | 2000 bar (29000 psi) | p. 20 |
| Cylinder Liner Protrusion | 0.080 - 0.140 mm (0.003 - 0.006 in) | p. 20 |
| Crankshaft End Play | 0.10 - 0.30 mm (0.0039 - 0.0118 in) | p. 21 |
| Common Rail Volume | 28.6 cm³ | p. 154 |
| Maximum Allowable Rail Pressure | 2400 bar (34800 psi) | p. 154 |
| Oil Pressure Valve - Overpressure Valve Start of Opening Pressure | 9 - 11 bar (131 - 160 psi) | p. 204 |
Cnh Industrial F3GFE613A*B001, F3GFE613B*B001, Cursor 11 Common Problems This Manual Covers
CNH Industrial Cursor 11 engine losing power under heavy load and throwing low rail pressure codes. p. 174
Inspect the common rail relief valve for damaged threads or a compromised bite edge. If replacing the valve, torque the new component to 110 N·m (81 lb ft) as shown on page 174. Verify the maximum allowable rail pressure does not exceed 2400 bar (34800 psi).
Manual Section: Common rail Relief valve - InspectLow engine oil pressure warning light stays illuminated after morning startup or during extended idle. p. 214
Check the engine oil pressure at idling on a warm engine, which should be 3 bar (43.5 psi). If pressure is low, replace the oil filter. Torque the new engine oil filter casing to 55 - 65 N·m (41 - 48 lb ft) according to page 214.
Manual Section: Engine oil filter - ReplaceExcessive top end ticking noise coming from the cylinder head area on a cold engine. p. 115
Adjust the valve clearance for the rocker arms. Set the intake valve lash on a cold engine to 0.35 - 0.45 mm (0.01 - 0.02 in) following the specifications on page 20. Lock the adjustment by tightening the rocker arm adjusting screw locknut to 34 - 44 N·m (25 - 32 lb ft) on page 115.
Manual Section: Rocker arm - AdjustHeavy knocking sound from the bottom end during acceleration or when climbing steep grades. p. 97
Measure the connecting rod bearings for excessive wear. When reassembling, tighten the connecting rod cap bolts to an initial 70 N·m (52 lb ft) as shown on page 97. Follow up with an additional 60 degree turn for the final torque sequence detailed on page 114.
Manual Section: Connecting rod and piston - MeasureFrequently Asked Questions
What are the torque specs for the cylinder head bolts on CNH F3GFE613A engine?
For the cylinder head bolts, the installation process involves multiple stages. First, torque to 60 N·m (44.3 lb ft), then to 120 N·m (88.5 lb ft). Follow this by tightening an additional 120° and then another 60°.
How to check torque specs for F3GFE613A engine bolts on CNH tractor
To check torque specifications for F3GFE613A engine bolts, refer to the 'Torque - Minimum tightening torques for normal assembly' tables. These tables provide values for metric non-flanged and flanged hardware, covering bolt sizes from M4 to M24 and property classes 8.8 and 10.9, with torques specified in N·m, lb·in, and lb·ft.
How do you fix CNH Industrial Cursor 11 engine losing power under heavy load and throwing low rail pressure codes?
Inspect the common rail relief valve for damaged threads or a compromised bite edge. If replacing the valve, torque the new component to 110 N·m (81 lb ft) as shown on page 174. Verify the maximum allowable rail pressure does not exceed 2400 bar (34800 psi).
How do you fix low engine oil pressure warning light stays illuminated after morning startup or during extended idle?
Check the engine oil pressure at idling on a warm engine, which should be 3 bar (43.5 psi). If pressure is low, replace the oil filter. Torque the new engine oil filter casing to 55 - 65 N·m (41 - 48 lb ft) according to page 214.
How will I receive this Cnh Industrial F3GFE613A*B001, F3GFE613B*B001, Cursor?
Immediate download of the complete 337-page searchable Service Manual. Access it on any device, from a laptop at your desk to a phone in the field.
Is this Cnh Industrial F3GFE613A*B001, F3GFE613B*B001, Cursor 11 manual?
Absolutely. No DRM or copy protection. Print the whole manual or just the pages you need. Any home or office printer works.
Does this Cnh Industrial F3GFE613A*B001, F3GFE613B*B001, Cursor 11 manual?
This manual includes electrical system overviews and sensor specifications, including pinouts and resistance values for the Cnh Industrial F3GFE613A*B001, F3GFE613B*B001, Cursor 11. It does not contain complete wiring diagrams for the entire engine or machine.
