This is the factory service manual for the New Holland T5.100, T5.110 and T5.120 Electro Command tractors, part number 51487926. All three run the 16x16 Semi-Powershift Electro Command transmission and a Selective Catalytic Reduction exhaust system, and the manual links each model to its FPT engine type by market. It works through the tractor system by system, and the electrical section takes almost half the book: harness drawings, the emissions and machine control circuits, and the fault-code tables with the guided test behind each code.
What's Inside This New Holland T5.100 Electro Command, T5.110 Electro Command, T5.120 Electro Command Manual
| System | Pages | Key Topics |
|---|---|---|
| Introduction and Standard Torques | 11-26 | How to Use the Manual, Shop Safety, Standard Tightening Torques, Approved Fluids, The Product-To-Engine Link Table by Market |
| Engine | 27-326 | Engine and Crankcase, Fuel System and Filtration, Air Cleaner and Intake, Exhaust with Selective Catalytic Reduction Aftertreatment, Cooling System and Fan Drive, Engine Overhaul |
| Clutch | 327-434 | Clutch Assembly and Release Mechanism, Pedal Free Play, Clutch Removal and Overhaul |
| Transmission | 435-728 | 16x16 Semi-Powershift Electro Command Transmission, Shuttle and Range Units, Control Valves and Clutch Packs, Pressure Testing and Overhaul |
| Four-Wheel Drive (4WD) System | 729-824 | 4WD Clutch and Its Control, Drive Shaft and Supports, 4WD Engagement Testing and Overhaul |
| Front Axle System | 825-1084 | Driven Front Axle, Bevel Drive and Differential, Hub Reduction, Steering Knuckles and Pivots, Axle Rebuild |
| Rear Axle System | 1085-1278 | Rear Bevel Gear Pair and Differential, Differential Lock, Final Drives, Bearing Preload and Backlash |
| Power Take-Off (PTO) | 1279-1564 | Rear PTO Clutch and Brake, Hydraulic PTO Clutch Control, Speed Selection and Shaft Change, PTO Overhaul |
| Brakes and Controls | 1565-1990 | Wet Disc Service Brakes, Parking Brake, Trailer Brake Valve, Pedal Adjustment, Bleeding the Brake Circuit |
| Hydraulic Systems | 1991-2318 | High Pressure and Steering Pumps in Both Fitments, Relief Valve Settings, Rear Lift and Draft Control, Remote Control Valves, Hydraulic Schematics and Pressure Testing |
| Hitches, Drawbars and Implement Couplings | 2319-2442 | Rear Three-Point Hitch and Lift Links, Front Hitch, Drawbars and Pick-Up Hitch, Implement Coupling and Setting |
| Frames and Ballasting | 2443-2460 | Chassis and Frame, Front and Wheel Ballast, Weight Fitting |
| Steering | 2461-2540 | Hydrostatic Steering Unit and Circuit, Steering Control Valve and Cylinder, Steering Column, Fault Finding |
| Wheels | 2541-2562 | Wheel and Tyre Fitment, Track Width Adjustment, Wheel Nut Torques |
| Cab Climate Control | 2563-2744 | Heating, Ventilation and Air Conditioning, Compressor and Condenser, Refrigerant Handling, Charging and Leak Testing |
| Electrical Systems: Harnesses and Connectors | 2745-3340 | Complete Wire Harness Drawings, Connector Component Diagrams, Fuse and Relay Layouts, Pin-Out Tables, Component Location |
| Electrical Systems: Machine and Emissions Circuits | 3341-4074 | Battery and Charging, Selective Catalytic Reduction Control, Front Axle Control System, Satellite Navigation, External Lighting, Warning Indicators, Alarms and Instruments |
| Electrical Systems: Fault Codes and Diagnostics | 4075-5112 | Fault-Code Index and Tables Including ECU Internal Diagnostic Faults, Guided Diagnostic Test Procedures |
| Front Loader and Bucket | 5113-5130 | Loader Arms, Lift and Bucket Cylinders, Loader Valve and Controls, Attachment Mounting |
| Accessories | 5131-5138 | Fitted Accessories and Their Service Points |
| Platform, Cab, Bodywork and Decals | 5139-5489 | Cab and Platform Assembly, Bodywork Panels, Hood and Grille, Glazing, Decals, Component Removal |
| Special Tool Index | 5490-5495 | Part Numbers of the Special Service Tools Each Procedure Calls for |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| T5.100 Electro Command | ||
| Engine type | F5GFL413W*C001 | |
| T5.110 Electro Command | ||
| Engine type | F5GFL413V*C001 | |
| T5.120 Electro Command | ||
| Engine type | F5GFL413U*C002 | |
| Standard fitment | ||
| High pressure pump | 25 cm3, 65.0 L/min (14.3 UK gpm) at 2300 rpm | |
| Steering pump | 14 cm3, 37 L/min (8 UK gpm) at 2300 rpm | |
| High-capacity fitment | ||
| High pressure pump | 32 cm3, 84.0 L/min (18.5 UK gpm) at 2300 rpm | |
| Steering pump | 16 cm3, 43 L/min (9 UK gpm) at 2300 rpm | |
| High pressure circuit | ||
| Relief pressure | 190 bar (2755 psi) | |
| Steering circuit | ||
| Relief pressure | 170 bar (2465 psi) | |
| All models | ||
| Transmission | 16x16 Semi-Powershift Electro Command | |
| Emissions aftertreatment | Selective Catalytic Reduction (SCR) | |
New Holland T5.100 Electro Command, T5.110 Electro Command, T5.120 Electro Command Common Problems This Manual Covers
The hydraulics or the steering feel down on flow compared with another tractor.
Identify the pump fitment before you test, because two are offered and they are not interchangeable in expectation. The standard circuit gives 65.0 L/min from a 25 cm3 pump with 37 L/min of steering flow from a 14 cm3 pump, while the high-capacity circuit gives 84.0 L/min from a 32 cm3 pump with 43 L/min of steering flow. Both are measured at 2300 rpm. Then check the relief settings, 190 bar on the high pressure circuit and 170 bar on the steering circuit.
Manual Section: Hydraulic SystemsThe tractor derates and the dash reports an emissions or ECU fault.
Read the code and work the fault-code section, which covers the ECU internal diagnostic faults alongside the Selective Catalytic Reduction control faults. Each code carries its conditions and a guided diagnostic naming what to measure and where. When the test points at a circuit, use the harness drawing and the connector component diagram to reach the exact pin rather than replacing a module or a dosing component on suspicion.
Manual Section: Electrical Systems: Fault Codes and DiagnosticsThe Electro Command transmission shifts harshly, slips under load, or will not shuttle cleanly.
Treat it as hydraulic and electrical together. The transmission section covers the 16x16 Semi-Powershift with its control valves and clutch packs and gives the clutch pressure test procedure, so you can tell a failing pack from a solenoid that is never commanded. Pull any stored code first, check the pressures second, then strip the box. The electrical section carries the transmission circuits and their connector diagrams.
Manual Section: TransmissionFrequently Asked Questions
Which tractors does this manual cover?
The T5.100, T5.110 and T5.120 Electro Command. The front matter links each model to its FPT engine type and the market it was built for: F5GFL413W*C001 on the T5.100, F5GFL413V*C001 on the T5.110 and F5GFL413U*C002 on the T5.120. All three carry the 16x16 Semi-Powershift Electro Command transmission.
Which hydraulic pumps are fitted and what do they flow?
There are two fitments and the manual gives both. The standard circuit uses a 25 cm3 high pressure pump giving 65.0 L/min (14.3 UK gpm) at 2300 rpm with a 14 cm3 steering pump giving 37 L/min (8 UK gpm). The high-capacity circuit uses a 32 cm3 high pressure pump giving 84.0 L/min (18.5 UK gpm) with a 16 cm3 steering pump giving 43 L/min (9 UK gpm). Relief is 190 bar (2755 psi) on the high pressure circuit and 170 bar (2465 psi) on the steering circuit.
Does it cover the SCR emissions system?
Yes. The exhaust with Selective Catalytic Reduction is covered in the engine section, and its control circuits sit in the electrical section alongside the battery and charging, the front axle control system, the satellite navigation, the lighting and the warning indicators. The fault-code tables then carry the codes each of those systems raises, including ECU internal diagnostic faults.
How much of the manual is electrical?
Almost half. Harness drawings, connector diagrams and pin-out tables run from page 2745 to page 3340, the machine and emissions control circuits from 3341 to 4074, and the fault-code index and guided diagnostics from 4075 to 5112. The front loader, accessories and cab sections follow after that.
How big is the manual and can I search it?
It runs to 5495 pages in English and is a searchable, printable PDF. Search the text, print the pages you need for the bench, and keep the rest on a laptop in the workshop.
How will I receive this New Holland T5.100 Electro Command, T5.110 Electro?
Immediate download of the complete 5495-page searchable Service Manual (559 MB). Access it on any device, from a laptop at your desk to a phone in the field.
