Need the factory service data for your Yanmar B110W wheeled excavator? This 903-page manual puts the complete Deutz TCD 3.6 L4 workshop manual, full articulated boom hydraulics, and vehicle electrics in a single file. Inside: hydraulic schematics covering the boom in standard and options configurations, wiring diagrams with cable colors and relay assignments, and the full SerDia 2010 SPN/FMI error code library for diagnosing every fault the machine can throw. You also get setting instructions for the SX14 and DPX100/6+1 control valves, pilot control procedures, AdBlue/DEF installation, and an inspection plan with measurement protocol. DKO hydraulic hose fittings (M22 x 1.5, zinc-nickel) torque to 70 Nm for both initial and repeat assembly. Every hour your machine sits costs money. Bookmarked by section and searchable by keyword: pull it up on your tablet and start working.
What's Inside This Yanmar B110W Manual
| System | Pages | Key Topics |
|---|---|---|
| General | 3-46 | Foreword / User Instructions, Safety and Accident Prevention, Safety Signs, Tightening Torques of Pistons or Piston Nuts, Tightening Torques of Guide Bushings, Pictograms |
| Technical Data | 47-60 | Drift Values |
| Diesel Engine | 61-562 | Operating Manual Td / Tcd 3.6 L4, Workshop Manual Td / Tcd 3.6 L4, Bleeding the Fuel System, AdBlue – DEF Installation |
| Hydraulics | 563-574 | ► 0156 Articulated Boom - Standard, ► Xxxx Articulated Boom - Standard, ► 0156 Articulated Boom - with Options, ► Xxxx Articulated Boom - with Options |
| Setting Instructions | 575-624 | Hydromatik Tightening Values, Travel Hydraulics, Control Valve SX14, Control Valve DPX100/6+1, ► 0156 Pilot Control Unit, ► Xxxx Pilot Control Unit, Working Hydraulics |
| Function Description | 625-634 | Pilot Control Device 4TH6, Grip Options - Joystick |
| Electrics | 635-728 | Cable Colors, Vehicle Electrics TW110 SCRT_0104-_V0.1.4 From Serial-No.: TW11040104 to TW1104XXXX, Monitoring Displays, Heating Und Climate Regulator, Relay Assignment |
| Maintenance | 729-742 | Specification for Fuels, Lubricants and Coolants, Inspection Plan, Measurement Protocol |
| Operation | 743-780 | Keypad Operation, Instructions for Using the Combo-Tool |
| Options | 781-800 | Pressure Setting, Front Dozer Blade, Exhaust Gas After-Treatment System – Diesel Particle Filter Replacement, Auto-Idling System |
| Repair Instructions | 801-820 | Fitting Hydraulic Screw Connections, Adhesive Kit – Cab Windows, Tilting the Cab |
| Diagnosis / Tools | - | Special Tools - Purchased Parts, Actia - Diagnostic Messaging Specification, SerDia 2010 - Diagnoses- and Error Codes Spn / Fmi, Diagnostics and Programming Port - Purchased Parts |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Hydraulic hose fittings tightening torque (DKO hose, Zinc-nickel surface protection, L15 M22 x 1.5) | 70 Nm (initial assembly), 50 Nm (repeat assembly) | p. 813 |
| Lubricating oil filter tightening torque | 10 Nm - 12 Nm | p. 117 |
| Coolant hose clip tightening torque | 1.5 Nm | p. 812 |
| Coolant hose spring band clip positioning clearance (Dimension X) | 2 +/- 1 mm | p. 357 |
| Spring band clip tightening torque (Coolant pipes) | 1.5 Nm | p. 812 |
| Crankcase breather spring band clip positioning clearance (Dimension X) | 3 mm | p. 142 |
| Working pump standby pressure | 22 +1 bar at 2,150 min-1 | p. 52 |
| Main pressure relief valve pressure (upper idle) | 380 bar | p. 53 |
| Permissible continuous coolant temperature | max. 110 °C | p. 142 |
| Coolant temperature warning threshold | above 110°C | p. 707 |
| Engine Output (ISO 3046) | 85 / 116 kW/HP | p. 49 |
| Total Engine Displacement | 3621 cm³ | p. 49 |
Yanmar B110W Common Problems This Manual Covers
Yanmar B110W excavator loses hydraulic power and boom response slows under heavy load. p. 52
Test the working pump standby pressure on page 52 to ensure it reads 22 +1 bar at 2,150 min-1. Check the main pressure relief valve pressure at upper idle. Adjust the relief valve to 380 bar if it falls below specification. Clean the hydraulic filters.
Manual Section: Technical DataEngine overheating warning activates and cooling performance drops during sustained trenching operations. p. 114
Inspect all cooling hoses for damage or dry rot. Renew if damaged as outlined on page 114. Check the coolant temperature warning threshold on page 707 to verify the sensor triggers above 110°C. Secure any loose connections and torque the coolant hose clips to 1.5 Nm.
Manual Section: Diesel EngineVisible hydraulic fluid leaks around cylinder fittings found during daily walk-around inspection. p. 813
Inspect the DKO hose connections with zinc-nickel surface protection. Clean the area around the leak. Torque the L15 M22 x 1.5 hydraulic hose fittings to 70 Nm for both initial and repeat assembly, as specified on page 813. Check cylinders for scored rods.
Manual Section: Repair InstructionsBoom assembly slowly lowers while holding a heavy load in the raised position. p. 59
Measure the boom cylinder drop rate with a dial indicator. Verify the boom cylinder TPA drift value does not exceed 3.5 mm/min according to page 59. Inspect the control valve spools for excessive wear or scoring. Replace the cylinder seals if the drift exceeds the maximum limit.
Manual Section: Technical DataFrequently Asked Questions
How do I reset the YANMAR B110W error code?
To reset the error code, rectify all errors. For some errors, it is necessary to switch off the ignition, wait 30 seconds, and then switch back on the ignition. The diagnostics lamp will go out once all errors are rectified.
How do I reset the hydraulic pressure settings on a YANMAR B110W?
Hydraulic pressure settings can be reset by adjusting the relevant screws. For instance, to adjust the pressure cut-off of the travel pump, screw in/out the setting screw (07) on the travel pump to increase or reduce pressure. For slewing drive pressure, unscrew the lock nut (2) and turn the pressure adjusting screw (1) clockwise to increase pressure or counter-clockwise to reduce it, then tighten the lock nut (2) against the connection nozzle (3).
What does the YANMAR B110W fault code mean?
The YANMAR B110W fault codes are listed in the 'ACTIA - Diagnostic Messaging Specification' and 'DTC-List-EMR4' sections. These lists provide the DTC Code (Hex), DTC Type, SPN-Value, Failure type, Function/Module, Number, and a detailed Description of the fault.
How do I clear the alarm on a YANMAR B110W?
The warning buzzer is activated under various fault conditions, such as low fuel level, high coolant temperature, or soiled air filter. To clear the alarm, the underlying fault condition must be resolved. For example, if the quick-attach function alarm sounds, it will stop once the function is deactivated.
Is this Service Manual a digital download?
Instant PDF download. You get the full 903-page searchable Service Manual immediately after payment. Open it on your laptop, tablet, or phone right in the shop.
Are there any print restrictions on this manual?
There are no print restrictions. The PDF is DRM-free — print whatever sections you need for the shop. Standard letter or A4 paper works.
Does this Service Manual have electrical diagrams?
Yes, this Yanmar B110W Service Manual includes complete electrical wiring diagrams, wire routing, and connector pinouts.
