A skipped fuel filter service will stop a diesel in the field faster than most worn parts, and this Ford 1510 owner's manual PDF exists to keep that from happening: 64 pages of the factory operator manual for your 1510 tractor, OEM ID 42151010. Lubrication and maintenance fills close to half the book, with separate service charts for two-wheel and four-wheel drive, fuel and lubricant procedures, and storage prep. Instrument panel indicators, shuttle shift and PTO controls, wheel tread settings, ballast, and tire pressures each get their own section, plus break-in and differential lock operation. Rinse the fuel filter every 100 hours, replace it at 200, and never crank the starting motor longer than 30 seconds. A guessed tire pressure ruins a set of rears fast. Print what the job calls for, let the sheets get greasy on the bench, and keep the bookmarked, text-searchable file ready before the weather turns.
What's Inside This Ford 1510 Manual
| System | Pages | Key Topics |
|---|---|---|
| International Symbols | 5 | Engine Speed, Engine Oil Pressure, Power Take-Off, Differential Lock, Remote Cylinder, Transmission Oil Pressure |
| Safety Precautions | 6-7 | The Tractor |
| Controls and Instruments | 8-14 | Seat, Light and Engine Controls, Lighting, Instrument Panel, Throttle Controls, Brake Controls, Differential Control, Transmission and PTO Controls |
| Operation | 15-26 | Break-In Procedures, Starting the Engine, Stopping the Engine, Operating the Transmission, Four-Wheel Drive and PTO, Towing the Tractor, Operating the Differential Lock |
| Lubrication and Maintenance | 27-50 | Lubrication and Maintenance Chart (Two-Wheel Drive, Four-Wheel Drive), Fuel and Lubricants, Fuel and Lubricant Service Procedures, Tractor Storage |
| Specifications | 51-54 | Engine, Cooling System, Electrical System, Fuel System, Hydraulic Lift System, Power Take-Off |
| Safety Decals | 55 | Drawbar, Starter Solenoid |
| Instruction Decals | 56-58 | Four-Wheel Drive Control Lever, Creeper Range Lever, PTO Control Lever, Shuttle Shift Lever, Flow Control Valve, Remote Control Lever |
| Predelivery and 50-Hour Service | 59-64 | Tire Pressure, Air Cleaner, Radiator Coolant, Fan Belt, Battery, Hydraulic System |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Starting motor engagement time | 30 seconds | p. 15 |
| Cold-start aid indicator time | 20 seconds | p. 13 |
| Hydraulic oil filter tightening | 3/4 of a turn by hand | p. 36 |
| Fuel filter cleaning interval | 100 hours | p. 33 |
| Diesel fuel filter replacement interval | 200 hours | p. 32 |
| Injector retaining nut torque | 43-51 lbs. ft. (58-69 N.m) | p. 37 |
| Injector line fitting torque | 18-22 lbs. ft. (24-29 N.m) | p. 37 |
| Fan belt deflection | 7/16 to 9/16 inch (10 to 15 mm) | p. 38 |
| Thermostat Start to Open | 160°F (71°C) | p. 52 |
| Water Pump Belt Deflection | 7/16 to 9/16 in. (10-15 mm) | p. 52 |
| Engine Oil Change Interval | 100 hours | p. 33 |
| Engine Oil Filter Change Interval | 200 hours | p. 33 |
Ford 1510 Common Problems This Manual Covers
Ford 1510 three-point hitch lifts slowly, drops the implement, or bounces in neutral
Check the rear axle and transmission oil level first; low oil starves the lift circuit. The combined case holds 26 liters, so top up before condemning anything. Change the hydraulic filter every 300 hours, tightening the new filter 3/4 of a turn by hand past gasket contact as shown on page 36.
Manual Section: Lubrication and Maintenance p. 36Engine cranks but will not fire, or starts hard on frosty fall mornings
Verify the cold-start aid indicator shows red before cranking; turn the key to heat and hold it about 20 seconds, per the procedure on page 13. Never run the starter more than 30 seconds at a stretch; let it rest between attempts. If it still will not fire, check for winter-grade fuel and a full tank.
Manual Section: Engine Starting Troubleshooting p. 15Engine stalls under load, loses power, or dies and refuses to restart in the field
Drain water from the fuel filter bowl and clean the element by rinsing it in clean diesel every 100 hours, following the procedure on page 33. Replace the element every 200 hours. After any filter work, bleed the system as shown in the fuel system section before cranking, and confirm the tank shutoff valve is fully open.
Manual Section: Fuel System Troubleshooting p. 33Charge indicator light glows at working speed and the battery runs down sitting overnight
Check fan belt tension first; a loose belt slips on the alternator pulley. Correct deflection is 7/16 to 9/16 inch (10 to 15 mm) under thumb pressure midway between pulleys, per page 38. Then verify electrolyte sits 1/4 inch (6.35 mm) above the plates in each cell, and clean any corrosion off the terminals.
Manual Section: Electrical System Troubleshooting p. 41Temperature gauge climbs into the red while baling or working on hot afternoons
Check coolant level cold and inspect the radiator screen for chaff before the next pass; a plugged core overheats fast in dusty hay. Test fan belt deflection at 7/16 to 9/16 inch (10 to 15 mm), shown on page 38. If the gauge still climbs, suspect the thermostat; it should start opening at 160°F (71°C).
Manual Section: Cooling System Maintenance p. 38Differential lock pedal stays engaged or releases only with a hard kick after turning
Check that you fully back off the throttle and steer slightly before expecting the pedal to release; the lock holds under torque. Review the operating steps starting on page 15. If it still hangs up, change transmission and rear axle oil on the 300 hour interval and refill with the full 26 liters so the linkage stays lubricated.
Manual Section: Operation p. 15Frequently Asked Questions
What are the torque specifications for the front wheel disc-to-hub bolts on a Ford 1510 tractor?
For a two-wheel drive model, the front wheel disc-to-hub bolts should be torqued to 43-54 lb. ft. (58-73 N.m). For a four-wheel drive model, the torque specification is 68.6-86.7 lb. ft. (93-117 N.m). p. 53
What is the recommended valve clearance for the intake and exhaust valves on the Ford 1510 engine?
The valve clearance for both the intake and exhaust valves should be set to .008 inches (.2 mm) with the engine cold. p. 40
What is the engine oil capacity for the Ford 1510 when changing the filter?
When performing an engine oil change that includes replacing the filter, the engine oil capacity is 4.2 U.S. quarts (4 Liters). p. 52
How often should the engine oil and engine oil filter be changed on the Ford 1510?
The engine oil should be changed every 100 hours, and the engine oil filter should be changed every 200 hours. p. 33
What is the correct fan belt tension for the Ford 1510?
A correctly tightened fan belt will deflect 7/16 to 9/16 inch (10 to 15 mm) when 20 to 25 pounds (9 to 11 kg) of thumb pressure is applied midway between the belt pulleys. p. 38
How is this Ford 1510 Owner's Manual delivered?
One searchable PDF covering 64 pages, delivered instantly. No disc, no shipping, no waiting on the post.
Are there any print restrictions on this Ford 1510 manual?
Zero restrictions. The PDF is DRM-free. Print whatever sections you need to take out to the shop. Standard letter or A4 paper works.
