Skipped lubrication intervals kill more compact tractors than hard work ever will, and the Ford 1700, 1900 operator manual PDF exists to stop that: 62 factory pages, OEM ID 42190011, covering operation and maintenance for both diesel models. Lubrication and maintenance takes up over a third of the book, with separate service charts for two-wheel and four-wheel drive, fuel and lubricant procedures, and a storage routine for the off season. Controls coverage walks the instrument panel and international symbols, then operation runs from break-in and starting through the transmission, PTO, differential lock, hydraulic lift, wheel tread settings, and ballast. Set your clutch pedal free-travel between 3/4 and 1-3/16 inches, and change the hydraulic filter every 600 hours. Second-guessing a tread-change torque with rain coming is a miserable way to lose an afternoon. Bookmarked and text-searchable, the PDF goes where you and the tractor do: cab, shop, or the far field.
What's Inside This Ford 1900, 1700 Operator Manual
| System | Pages | Key Topics |
|---|---|---|
| International Symbols | 10 | Engine Speed, Alternator Charge, Power Take-Off, Engine Oil Pressure, Differential Lock, Rock Shaft |
| Safety Precautions | 11 | Rollbar, Seat Belt, Cooling System, PTO, Parking Brake, Drawbar |
| Controls and Instruments | 12-18 | Seat, Light and Engine Controls, Lighting, Instrument Panel, Throttle Controls, Brake Controls, Differential Control, Transmission and PTO Controls |
| Operation | 19-28 | Break-In Procedures, Starting the Engine, Stopping the Engine, Operating the Transmission, Four-Wheel Drive and PTO, Towing the Tractor, Operating the Differential Lock |
| Lubrication and Maintenance | 29-50 | Lubrication and Maintenance Chart (Two-Wheel Drive, Four-Wheel Drive), Fuel and Lubricants, Fuel and Lubricant Service Procedures, Tractor Storage |
| Specifications | 51-53 | Capacities |
| Safety and Instruction Decals | 54-58 | Caution Decal, Warning Decal, Cold Start Aid, Hand Throttle Control, PTO Control, Fuel Injection Pump Service |
| Predelivery and 50-Hour Service | 59-62 | Tire Pressure, Air Cleaner, Radiator Coolant, Fan Belt, Battery, Hydraulic Lift Control |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Wheel disc to hub bolts | 43-54 lbs.ft. (58-73 N.m) | p. 26 |
| Side axle adjusting bolts | 177-199 lbs.ft. (240-270 N.m) | p. 26 |
| Hydraulic filter service interval | 600 hours | p. 36 |
| Clutch Pedal Free-Travel | 3/4-1-3/16 in. (1.9-3.0 cm) | p. 45 |
| Thermostat Starts to Open | 159.8° F. (71°C.) | p. 51 |
| Thermostat Fully Open | 185° F. (85°C.) | p. 49 |
| Standard PTO Speed | 540 rpm | p. 21 |
| Maximum Engine Speed (High Idle) | 2900-2950 rpm | p. 51 |
| Valve Clearance (Intake/Exhaust) | 0.012 in. | p. 51 |
| Battery Rating | 12-volt, 100 amps | p. 51 |
| Front Wheel Toe-In | 0-13/64 in. | p. 51 |
| Engine Oil Change Interval | 100 hours | p. 33 |
Ford 1900, 1700 Common Problems This Manual Covers
Ford 1900 diesel cranks slowly and won't fire on cold mornings, glow plugs seem inactive
Check battery condition first; the system needs a fully charged 12-volt, 100 amp battery, listed with the specs on page 51. Follow the cold start aid procedure shown on the decal, and use the starting instructions beginning on page 19. Crank in short bursts and let the starter cool between attempts.
Manual Section: Engine Starting Troubleshooting p. 19Engine temperature gauge climbs into the red after 20 minutes of mowing in warm weather
Inspect the radiator core for chaff and blow it clean with compressed air; check coolant level with the engine cold. Verify fan belt tension, then test the thermostat if the gauge still climbs. It should start opening at 159.8 F (71 C), the spec listed on page 51. Replace it if it stays shut.
Manual Section: Cooling System TroubleshootingThree-point hitch drops or loader loses lift when both hydraulic circuits work at once
Check hydraulic oil level first, then service the suction screen and filter; a plugged element starves both circuits at once. The filter change interval is 600 hours, listed on page 36. Verify position and draft control lever settings before running the loader and hitch together, and watch for foamy oil that means air on the suction side.
Manual Section: Hydraulic System Troubleshooting p. 36PTO shaft grinds or clatters when engaging the lever with the engine running
Engage the PTO at low idle with the clutch pedal fully down, then bring speed up to the rated 540 rpm shown on page 21. Measure clutch pedal free-travel; it should be 3/4 to 1-3/16 in. (1.9 to 3.0 cm). Adjust the linkage if travel is out of range; a dragging clutch keeps the shaft turning.
Manual Section: Transmission and PTO Troubleshooting p. 21Engine surges, loses power, or dies under load after the tractor sat all winter
Drain and clean the fuel filter, then bleed air from the fuel system before condemning the injection pump. Refill with fresh diesel. While the tractor is down, change engine oil if you are near the 100 hour interval listed on page 33, and check the maintenance schedule on page 29 for anything coming due.
Manual Section: Fuel System TroubleshootingFrequently Asked Questions
What are the torque specifications for the front wheel disc-to-hub bolts on a Ford 1900, 1700 tractor?
For the two-wheel drive model, the front wheel disc-to-hub bolts should be torqued to 43-54 lbs. ft. (58-73 N.m). p. 26
What is the correct valve clearance for the intake and exhaust valves on the Ford 1900, 1700 tractors?
The valve clearance for both the intake and exhaust valves on the Ford 1900 should be 0.012 inches (0.30 mm) when the engine is cold. p. 40
What is the fuel tank capacity for the Ford 1900?
The fuel tank capacity for the Ford 1900 is 7.7 U.S. gallons (6.4 Imperial gallons or 29 liters). p. 51
How often should the engine oil and filter be changed?
The engine oil should be changed every 100 hours, and the engine oil filter should be changed every 200 hours. p. 33
What exactly do I receive with this Ford 1700 Operator Manual?
This is a 62-page searchable PDF ready for immediate download. Works on any device, so pull it up on your phone while you're under the hood. No shipping, no waiting.
Is printing allowed for this Ford 1700 Operator Manual?
Yes. No DRM, nothing blocks printing, so run off the pages you need on whatever printer you have.
