Need the exact factory breakdowns for your 1990-1999 Ford 4130 Tractor? This 602-page Ford 4130 parts catalog pdf maps out every bolt, bracket, and gear in the machine. You get highly detailed exploded views of the entire drivetrain, complete engine block breakdowns, and detailed electrical harness and connector parts breakdowns. Inside, page after page of parts lists provide the exact OEM numbers and cross-references required to secure the correct components on the first try. Look up the precise internal pieces for the DPA Rotary fuel injection pump or verify the exact gear arrangement for the 16x8 synchronized transmission before you visit the parts counter. Wasting days waiting for the wrong parts to arrive costs you money. Grab this text-searchable, bookmarked file, pull it up on your phone in the shop, and order exactly what your machine needs.
What's Inside This Ford 4130 Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Fuel System | Fuel Tank, Fuel Injection Pump, Fuel Sedimenter & Filter, Fuel Injector, Tube & Clamp, Air Cleaner, Fuel Primer | |
| Cooling System | Radiator, Water Pump, Radiator Shell | |
| Engine | Crankshaft, Camshaft, Pistons & Connecting Rods, Oil Pump & Oil Pan, Gasket Kits, Oil Coolers, Lubrication Equipment | |
| Electrical System | Rear Wiring, Inset Headlamp, Headlamp, Lamp, Rear Lamp, Lamp Assembly & Mounting, Battery & Battery Support, Starter Motor | |
| Clutch & Transmission | Transmission Handbrake, Synchronized Transmission, Clutch Input Shaft, Shift Levers, Transmission, Ipto Clutch, PTO Clutch Valves, Clutch | |
| PTO | PTO Shaft & Gears, PTO Cover, Ipto Cover, PTO Shift Control, Ipto Control Lever, Ipto Handle, PTO Guard | |
| Rear Axle, Differential & Brakes | Standard Rear Wheels, Rear Wheel Weight Kit, Brakes, Brake Controls & Related Parts (Nh-E), Brake Controls, Trailer Brakes (Nh-E), Rear Axle Center Housing, Rear Axle Final Drive Differential | |
| Front Axle & Steering | Front Wheel & Hubs, Front Wheel, Front Axle, Steering Gear, Steering Column, Power Steering Pump & Reservoir, Power Steering Cylinder, Power Steering Motor | |
| Hydraulics & 3-Point Hitch | Auxiliary Service Control Valve, Auxiliary Service Control Pipe & Coupler, Lift Control & Draft Control, Flow Control Valve, Flow Control Valve Components, Hydraulic Manifold, Lift Arms & Shafts, Lift Cover | |
| Body & Operator Station | Rear Cover, Front Cover, Seat, Engine Covers, Crown Fenders, Flat Top Fenders, Front Fenders, Rear Fenders | |
| Decals & Accessories | Tool Box, Decals, Tool Kit | |
| Other Components | Power Adjustable Wheel, Rear Weights, Weights, Axle Shaft & Planetary Assemblies, Ring Gear, Drive Shaft & Shield, Front Transfer Case, Transfer Case & Controls |
Ford 4130 Common Problems This Manual Covers
Leaking Ford 4130 Tractor hydraulic lift cylinder requires exact replacement seal kit part numbers for a rebuild.
Inspect the exploded view to identify specific o-rings and wipers. Verify the hardware size using the metric conversion chart on page 601 for any 50 mm (1.96 inches) retaining bolts. Match the cylinder part number to your exact serial number break before ordering components.
Manual Section: Hydraulic Lift ControlMissing part numbers for the synchronized transmission gear shift controls and broken internal linkage forks.
Review the drivetrain layout to find the exact shift fork assembly. Look up the corresponding 12 mm (0.47 inches) linkage pins in the parts list. Cross-reference the main shaft bearings with the master index to ensure you order the right hardware.
Manual Section: TransmissionTrying to identify missing wiring harness connectors and starter motor mounting hardware after an engine fire.
Check the main wiring layout for the starter circuit pigtails. Confirm the exact part number for the main harness. Measure replacement terminal ring sizes and use the conversion table on page 601 to convert 8 mm to 0.31 inches for proper fitment.
Manual Section: Electrical SystemMissing the water pump mounting bolts and thermostat housing gasket during a major engine block overhaul.
Examine the engine components to locate the water pump group. Find the part numbers for the mounting bolts and verify they are M8x1.25 thread pitch. Check the abbreviations guide on page 587 to decipher any specific hardware grade requirements listed in the description column.
Manual Section: Engine CoolingFrequently Asked Questions
What are the recommended service intervals for the tractor?
The lubrication and maintenance service intervals are detailed in the chart on page 547. The chart specifies maintenance items that should be checked, cleaned, lubricated, or adjusted at regular intervals, including a 1200-hour service interval. p. 547
What is the torque specification for the cylinder head bolts?
The cylinder head bolts (part number 87802206) should be tightened to the specified torque. There are 10 bolts required for the cylinder head assembly, each measuring 9/16"-12 UNC 2A x 5-1/32". p. 198
What is the correct part number for the engine oil filter?
For the NHNA market, the engine oil filter assembly is part number 86546614 or 86546614DS. For the NH-E market, the engine oil filter assembly is part number 87800068. p. 197
What is the specification for the intake valve insert?
The standard intake valve insert is part number D4NN6056A. Oversize inserts are also available, such as part number 87802103 (.010"/.254mm O/S) and 87802104 (.020"/.508mm O/S). p. 195
What is the part number for the fuel injection pump for a 4630 tractor?
The fuel injection pump for the 4630 tractor is part number E9NN9A543FA. This assembly includes all items on Figure 9D2, except for Switzerland models with two hydraulic pumps and a fuel lift pump. p. 347
What do I get after purchasing this Ford 4130 manual?
Instant PDF download. You get the full 602-page searchable Parts Catalog immediately after payment. Open it on your laptop, tablet, or phone right in the shop.
Can I print specific sections of this Ford 4130 Parts Catalog?
Yes. The PDF has no DRM restrictions, so print any page or section you need for your shop. Works with any standard printer.
