Track roller worn oval, idler shot, and the dealer wants a part number before the counter will talk? The Takeuchi TB36 parts catalog PDF, 152 pages under OEM PUB. 4, answers that for every assembly on this compact excavator. Exploded views break the undercarriage down into lower frame, crawler belt, front idler, track spring and track gearbox, each bubble tied to its own number and quantity. The hydraulic device group runs long, the biggest block in the book, covering swivel joint, control valves, joy stick lever, boom and arm cylinders, travel motor, slew motor and hydraulic pump. Steel and rubber crawler track rollers carry separate listings, and extension arm machines get their own hoe, bucket and cylinder pages so you order what your machine actually wears. One wrong digit costs a day of rental. Bookmarked and searchable, this download gets the right part on the truck and the machine back on the dirt.
What's Inside This Takeuchi TB36 Parts Manual
| System | Pages | Key Topics |
|---|---|---|
| Lower Machinery | 13-26 | Lower Frame, Crawler Belt, Track Roller, Front Idler, Track Spring, Track Gearbox, Blade, Piping; Lower |
| Upper Machinery 1 | 27-40 | Slew Gearbox, Turntable, Travel Lever, Operation Lever, Switching Lever |
| Upper Machinery 2 | 41-56 | Engine & Accessories 1, Engine & Accessories 2, Control Box, Engine Control, Electrical 1, Electrical 2, Electrical |
| Upper Machinery 3 | 57-72 | Grease Piping, Valve & Accessories 1, Valve & Accessories 2, Piping; Upper 1, Piping; Upper 2, Piping; Upper 3, Pump Drive, Hydraulic Tank |
| Upper Machinery 4 | 73-86 | Cover 1, Cover 2, Seat, Cabin 1, Cabin 2, Canopy, Heater |
| Hoe Attachment | 87-102 | Hoe, Bucket, Piping; Hoe 1, Piping; Hoe 2 |
| Others | 103-110 | Sticker, Tool |
| Hydraulic Device | 111-144 | Swivel Joint, Control Valve 1, Control Valve 2, Control Valve; Sub, Joy Stick Lever, Selector Valve, Boom Cylinder, Arm Cylinder |
| Option | 145-152 | Bucket, Mirror |
