If you run a 2388 or one of its 2377, 2577 or 2588 stablemates, you already know harvest season does not wait for a dealer slot. This is the real factory book Case techs work from, part 84125893, all seven volumes and 2,021 pages of step by step repair, diagnostics and the exact capacities and torque values the machine was built to. Whether you are chasing a feeder slip clutch that will not grab, a reverser that jams in damp grain, or just setting oil and coolant capacities before a long day, it is here in factory order.
What's Inside This Case IH 2377, 2388, 2577, 2588 Manual
| System | Pages | Key Topics |
|---|---|---|
| General, Engine and Fuel System | Engine Specifications, Fuel Injection and Supply, Oil and Coolant Capacities, Special Tightening Torques, General Service | |
| Electrical | Wiring Diagrams, Charging and Starting Circuits, Lighting, Sensors, Diagnostic Fault Codes | |
| Electrical and Steering | Steering Electrical Controls, Hydrostatic Steering, Circuit Schematics | |
| Power Train | Transmission, Traction Drive, Final Drives, Hydrostatic Propulsion | |
| Brakes and Hydraulics | Service Brakes, Hydraulic Circuits, Pumps and Valves, Reservoir Capacity | |
| Chassis | Frame, Axles, Tires and Tracks, Cab, Operator Controls | |
| Harvesting and Feeder Systems | Feeder, Slip Clutch and Reverser, Rotor, Separator, Cleaning, Grain Handling and Unloading |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| All models | ||
| Fuel Capacity | 681.4 L (180 US gal) | |
| Engine Oil Capacity (with filter) | 21 L (22 US qt) | |
| Coolant Capacity | 34.1 to 42 L (36 to 42 US qt, by section) | |
| Transmission Oil Capacity | 16.2 L (17.2 US qt) | |
| Final Drive Oil Capacity | 12.3 L (13 US qt) | |
| Hydraulic Reservoir Capacity | 38 L (10 US gal) | |
| PTO Housing Oil Capacity | 13.2 L (14 US qt) | |
| Rotor Gear Case Oil Capacity | 4.7 L (5 US qt) | |
| A/C Refrigerant Capacity | 2.21 kg (4.88 lb) | |
| Engine Mount Bolt Torque | 137 to 163 Nm (100 to 120 lb-ft) | |
| Production Years | 1997 to 2006 | |
| By model | ||
| Engine | 8.3 L / 9.0 L turbocharged 6-cylinder (CNH 6TAA) | |
Case IH 2377, 2388, 2577, 2588 Common Problems This Manual Covers
Feeder slip clutch fails to slip or slips prematurely under load
Check the slip clutch spring compression and reset it to the factory dimension, then verify the slip torque falls within the specified range. Worn clutch plates that no longer hold the rated torque should be replaced as a set. The exact spring setting and procedure are in the harvesting and feeder section.
Manual Section: Harvesting and Feeder SystemsFeeder reverser jams or fails to reverse, especially in high moisture grain
Inspect the reverser housing for packed crop debris and clear it, then check the linkage pins and hydraulic actuation for wear or low pressure. Replace broken pins and confirm the reverser engages fully before returning to the field. The steps are covered in the feeder section.
Manual Section: Harvesting and Feeder SystemsRotor binds or will not turn freely when uncoupled
Trace the resistance to the feeder shaft bearing and its lubrication, since a failing bearing or a missed daily greasing point will load the rotor drive. Inspect and replace the bearing kit if it feels rough, and follow the daily maintenance lubrication schedule to prevent it recurring. The power train and feeder sections cover the procedure.
