Rebuilding a Ford 6000? This 336-page Ford 6000 Service Manual PDF (OEM #40600010) walks you through the whole tractor: engine, planetary gear transmission with bands and servos, PTO, rear axle, brakes, power steering, and the complete hydraulic system down to the accumulator and draft sensing plunger. You get wiring diagrams for chasing electrical gremlins, hydraulic schematics tracing every valve and circuit, a full troubleshooting section, and step-by-step teardown procedures from cylinder head to control valve. Torque the cylinder head bolts to 95-105 lb-ft dry, then bench-test your starter: 85 amps no load, 175 amps under cranking load. Old iron, no dealer support, and a transmission nobody at the parts counter remembers. That is exactly why this manual exists. Bookmarked PDF opens on any device; carry your tablet out to the tractor and start wrenching.
What's Inside This Ford 6000 Manual
| System | Pages | Key Topics |
|---|---|---|
| Part One - Power Plant | 5-138 | Engine Removal, Cylinder Head, Valves, Oil Pump, Oil Filter, Connecting Rods, Pistons, Crankshaft |
| Part Two - Transmission, Power Take-Off, Rear Axle and Brakes | 139-258 | Planetary Gear Train, Bands, Servos, Clutch Packs, Control Valve, Transmission Pump, Power Take-Off, Rear Axle |
| Part Three - Steering, Front Axle, Wheels, and Tires | 259-276 | Power Steering Pump, Steering Control Valve, Steering Motor, Steering Gear, Front Axle, Wheel Bearings, Wheel Spacing, Tires |
| Part Four - Hydraulic System | 277-336 | Accumulator, Hydraulic Pump, Unload Valve, Brake Valve, Hydraulic Lift, Draft Sensing Plunger, Remote Control Valve |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| fuel weight | 7 lbs. per gallon | p. 6 |
| Cylinder Head Bolts (Diesel) | 95-105 Lbs. Ft. | p. 48 |
| Cylinder Head Bolts (Gasoline) | 95-105 Lbs. Ft. | p. 49 |
| Gas starter motor no load max amperes | 85 amperes | p. 87 |
| Gas starter motor ampere load cranking | 175 amperes | p. 87 |
| Hydraulic Pump Rate | 4.0 gpm | p. 332 |
| Cylinder Head Bolt Final Torque | 115 ft. lbs. | p. 13 |
| Transmission Fluid Capacity | 12 quarts | p. 147 |
| Power Steering Pump Working Pressure | 1350 psi | p. 258 |
| Front Axle to Center Axle Bolt Torque | 180 ft. lbs. | p. 264 |
Ford 6000 Common Problems This Manual Covers
Ford 6000 diesel cranks slowly or will not turn over, clicking from starter when key is turned
Check battery voltage and clean both cable connections before condemning the starter. A healthy diesel starter draws about 250 amperes at 9.5 volts while cranking and must spin the engine at least 150 rpm, per the specs on page 87. If cranking speed falls short with a fully charged battery, pull the starter and bench test it.
Manual Section: Electrical System Troubleshooting p. 87Hydraulic lift raises slowly or drops under load, implements sag within minutes of shutdown
Check the transmission case fluid level first; it doubles as the hydraulic reservoir and holds 12 quarts. Then verify pump output: you need 4.0 gpm minimum at 1650 engine rpm, spec listed on page 332. If flow tests low, inspect suction lines for air leaks before pulling the pump, and trace the circuit on the schematic.
Manual Section: Hydraulic System Troubleshooting p. 332Engine loses power under load, black exhaust smoke when pulling uphill or working ground
Replace the fuel filters and pull the air cleaner element before digging deeper. Inspect the intake and exhaust manifold for leaks at the gasket faces; a loose manifold lets the engine breathe unfiltered air. Retorque the manifold bolts evenly to 40-50 ft. lbs. as listed on page 116, then run the engine under load and recheck.
Manual Section: Engine Troubleshooting p. 116Steering wheel hard to turn at idle, little or no power assist in either direction
Test pump output with a gauge before replacing parts. Working pressure should fall between 1100 and 1350 psi, listed on page 258. If pressure reads low, check reservoir level and inspect hoses for collapse or leaks. If pressure is good but assist stays weak, move on to the steering control valve.
Manual Section: Power Steering Troubleshooting p. 258Transmission slips out of gear, grinding noise from clutch area under heavy load
Drain the transmission and check the old oil for metal, which points to worn clutch packs or bands. Refill with fresh fluid; the case holds 12 quarts, per page 147. Run the pressure checks in the diagnostic procedures and adjust the band linkage before committing to splitting the tractor for internal repairs.
Manual Section: Transmission Troubleshooting p. 147Frequently Asked Questions
What are the torque specifications for the Ford 6000 cylinder head bolts?
The cylinder head bolts must be tightened in three progressive steps. The final torque specification is 105-115 ft. lbs. p. 13
What are the torque specifications for the rear wheel hub-to-axle bolts?
The torque for the rear wheel hub-to-axle bolts depends on the grade of the bolt. Grade No. 5 bolts require 300-350 ft. lbs., while Grade No. 8 bolts require 450-500 ft. lbs. p. 236
What is the recommended service interval for the air cleaner on the diesel engine?
The air cleaner should be serviced every 100 hours of operation to prevent engine wear and excessive oil consumption. p. 103
What is the correct valve lash adjustment for the diesel engine?
The valve lash should be adjusted to 0.015 inch on a warm engine. p. 14
What is the capacity of the hydraulic system reservoir?
The hydraulic fluid reservoir for the transmission case has a capacity of 12 quarts. p. 147
What do I get after purchasing this Ford 6000 manual?
You get a 336-page scanned PDF that downloads instantly after checkout. Open it on your laptop, tablet, or phone, and bring it right to the shop floor.
Can I print specific sections of this Ford 6000 Service Manual?
Absolutely. No DRM or copy protection. Print the whole manual or just the pages you need. Any home or office printer works.
