Part of the New Holland Repair Manuals.
New Holland service manual S5HS0014E01 is the factory book for the E55Bx Tier 3 compact excavator, canopy and cab, applicable machines PS03-05001 and up. It has the hydraulic circuit diagrams, the six-sheet electric circuit diagram and the Yanmar TNV DI engine service manual, all in one binding.
This book covers the pump, control valve, swing and travel motors, swivel joint and cylinders. It then walks the hydraulic and electrical troubleshooting charts through to a fix. Undercarriage work is covered too, from rollers and idler to sprocket and swing bearing.
It prints the figures you work to, such as 75L (20 gal) fuel tank capacity and 181 N-m (133 lbf-ft) for the travel motor mounting capscrews.
What's Inside This New Holland E55Bx Manual
| System | Pages | Key Topics |
|---|---|---|
| Safety and Specifications | 1-55 | Safety Precautions, Machine and Engine Specifications, Machine and Attachment Dimensions, Transport, Crawler Shoes, Buckets |
| Tools and Performance Standards | 56-107 | Fastener Torques, Hydraulic Fittings, Special Tools, Lifting Jigs, Maintenance Standards, Engine Speed Measurement, Hydraulic Pressure Tests |
| Mechatro Controller (Option) | 108-133 | Multi-Display, Self-Diagnosis, Service Diagnosis, Failure History, Maintenance Schedule, Adjustments |
| Hydraulic System | 134-169 | Hydraulic Circuit Diagrams, Device Model Numbers, Travel Circuit, Swing Circuit, Attachment Circuits, Combined Operations, Nibbler and Breaker Circuits |
| Electrical System | 170-219 | Electric Circuit Diagrams, Electrical Equipment, Harness List, Operator Controls, Engine Controls, Lighting, Alarm |
| Components System | 220-301 | Hydraulic Pump, Pilot Valves, Control Valve, Swing Motor, Travel Motor, Swivel Joint, Cylinders |
| Air-Conditioner System | 302-331 | Air Cycle, Heater and Cooler, Component Structure, Blower Motor, Unit Disassembly, Wiring Diagrams, Troubleshooting |
| General Disassembly and Assembly | 332-369 | Assembly Procedures, Specified Torques, Bucket, Quick Hitch, Arm and Boom, Boom Swing, Dozer, Hydraulic Cylinders |
| Upper Structure | 370-517 | Canopy and Cab, Counterweight, Fuel and Hydraulic Tanks, Engine Removal, Hydraulic Pump and Control Valve Overhaul, Swing Motor, Swivel Joint |
| Travel System | 518-591 | Crawler, Upper and Lower Rollers, Front Idler, Idler Adjuster, Sprocket, Travel Motor, Swing Bearing |
| Troubleshooting (Hydraulic and Electrical) | 592-625 | Hydraulic Diagnosis, Attachment, Travel and Swing Failures, Pump Malfunction, Electrical Diagnosis, Starting Trouble, Horn and Lighting |
| Troubleshooting by Error Codes (Option) | 626-643 | Site Inspection, Failure Classification, Controller Fuse, Error Code List, Pressure Sensors, Angle Potentiometers, CAN Communication |
| Engine Manual: General and Maintenance | 644-777 | TNV Engine Service Manual Introduction, Safety, General Service Information, Fluid Specifications, Periodic Maintenance |
| Engine Overhaul | 778-885 | Cylinder Head, Valve Train, Camshaft and Timing Gears, Crankshaft and Bearings, Pistons and Rings, Cylinder Block, Special Torques |
| Engine Fuel System | 886-929 | Injection Pump, Stop Solenoid, Cold Start Device, Fuel Pump, Electronic Governor, Injection Timing, Fuel Injectors |
| Engine Cooling and Lubrication | 930-963 | Cooling Diagram, Coolant Pump, Cooling Checks, Lubrication Diagram, Oil Pressure Checks, Trochoid Oil Pump Overhaul |
| Turbocharger, Starter and Alternator | 964-1021 | Turbocharger Troubleshooting and Inspection, Starter Motor and Tests, Alternator, Dynamo, Charging Wiring |
| Engine Troubleshooting | 1022-1037 | Compression Pressure Measurement, Compression Reference Values, Corrective Actions, Failure Diagnosis Tables, Representative Electrical Wiring |
Quick Reference Specifications
| Specification | Value | Page |
|---|---|---|
| Fuel tank capacity | 75L (20 gal) | p. 392 |
| Hydraulic tank capacity (reference oil volume) | 28L (7 gal) | p. 394 |
| Cooling water capacity, max / engine | 6.4 / 2.7 liter (1.69 / 0.71 gal) | p. 31 |
| Engine model | 4TNV88-B | p. 31 |
| Engine rated output | 28.3 kW (38.5 PS) at 2400 rpm | p. 31 |
| Engine maximum torque | 131.1 N•m (96.7 lbf•ft) at 1440 min-1 | p. 31 |
| Engine total displacement | 2.189 liter (134 cu•in) | p. 31 |
| Engine compression pressure | 3.43 ± 0.1 MPa (500 ± 14 psi) at 250 min-1 | p. 31 |
| Complete machine mass, kg (lb), rubber shoe, canopy | 4,900 (10,810) | p. 24 |
| Complete machine mass, kg (lb), rubber shoe, cab | 5,020 (11,070) | p. 24 |
| Complete machine mass, kg (lb), iron shoe, cab | 5,160 (11,380) | p. 24 |
| Travel speed, km/h (mph), rubber shoe, low (1st) | 2.1 (1.3) | p. 22 |
| Travel speed, km/h (mph), rubber shoe, high (2nd) | 4.0 (2.5) | p. 22 |
| Swing speed, min-1 {rpm} | 8.8 {8.8} | p. 22 |
| Gradeability, % (degree) | 58(30) | p. 22 |
| Boom swing angle, right | 59 degrees | p. 22 |
| Boom swing angle, left | 70 degrees | p. 22 |
| Travel motor working pressure, MPa (psi) | 23 (3335) | p. 260 |
| Travel motor mounting capscrew torque | 181 N-m (133 lbf-ft) | p. 554 |
| Idler adjuster grease nipple torque | 73.5 N-m (54.2 lbf-ft) | p. 549 |
New Holland E55Bx Common Problems This Manual Covers
Hydraulic pump is noisy and the hydraulic oil looks cloudy white
The hydraulic troubleshooting chart in the Troubleshooting (Hydraulic and Electrical) chapter traces this to a shortage of hydraulic oil. Replenish the hydraulic oil to the correct level before you condemn the pump. Then run the machine again and listen for the noise.
Manual Section: 42. TROUBLESHOOTING (HYDRAULIC SYSTEM) p. 603Machine deviates (walks off line) in travel independent operation
Before you blame a travel motor, the hydraulic troubleshooting chart sends you to the undercarriage. Check whether the shoe tension on each track is within the reference value. If it is not, adjust shoe tension at the idler adjuster as shown in the Travel System chapter. That chapter gives 73.5 N-m (54.2 lbf-ft) as the tightening torque for the idler adjuster grease nipple. Then test straight-line travel again.
Manual Section: 42. TROUBLESHOOTING (HYDRAULIC SYSTEM) p. 601Swing does not work but the dozer still operates
The swing operational failure chart first asks whether the dozer is operable; with a yes it moves on to the swing circuit. Check whether the swing relief valve is normal. If it is not, replace the swing relief valve. The Components System chapter covers the swing motor if you need to see how it is built before you open it up.
Manual Section: 42. TROUBLESHOOTING (HYDRAULIC SYSTEM) p. 602Horn does not sound even though 12V is present at the horn
The electrical troubleshooting chart for the horn has you press the horn switch and measure voltage between the brown-red and black harness wires. If you read 12V there, the switch and harness are doing their job. The horn itself has failed, so replace the horn and test it again.
Manual Section: 43. TROUBLESHOOTING (ELECTRICAL SYSTEM) p. 609Frequently Asked Questions
Which New Holland excavator does this service manual cover?
It covers the New Holland E55Bx Tier 3 compact hydraulic excavator in both canopy and cab versions. This is service manual S5HS0014E01, printed in English in April 2014, for applicable machines PS03-05001 and up. p. 1
What are the fuel, hydraulic tank and coolant capacities on the New Holland E55Bx?
The fuel tank holds 75L (20 gal). Hydraulic tank capacity, given as a reference oil volume, is 28L (7 gal). Cooling water capacity is 6.4 liter (1.69 gal) maximum, with 2.7 liter (0.71 gal) of that in the engine. p. 392
What travel speeds does the E55Bx have?
On rubber shoes the E55Bx travels at 2.1 km/h (1.3 mph) in low (1st) and 4.0 km/h (2.5 mph) in high (2nd). With the optional iron shoes, low stays at 2.1 km/h (1.3 mph) and high is 3.7 km/h (2.3 mph). p. 22
What engine does the E55Bx use and how much power and torque does it make?
It runs a Yanmar 4TNV88-B with a total displacement of 2.189 liter (134 cu•in). Rated output is 28.3 kW (38.5 PS) at 2400 rpm. Maximum torque is 131.1 N•m (96.7 lbf•ft) at 1440 min-1. p. 31
Does the manual include wiring diagrams, hydraulic circuit diagrams and error codes?
Yes. The electrical system chapter has the electric circuit diagram on six sheets. The hydraulic system chapter has circuit diagrams for the standard, nibbler and breaker, air conditioner and quick hitch specifications. The optional troubleshooting by error codes chapter lists codes such as H081 - Water temperature sensor, ground short failure and H093 - Fuel sensor, disconnection failure. The bound-in Yanmar TNV engine manual adds engine overhaul and troubleshooting. p. 172
